Prepared By:
Brian Nelson
Created Date:
August 2020
Initial Console Setup
Console Adjustments and Options
Important Access Codes:
Enter 3002 Enter - First Time Setup (FTSU)
Enter 3001 Enter - Machine Settings
Things to know:
Wi-Fi is an optional feature on LED (TM749) consoles which means consoles may not be equipped with
•
Wi-Fi boards installed.
If the console is purchased with optional Wi-Fi feature the Wi-Fi boards will be pre-installed
•
configuration file to automatically connect to a network named MXWireless.
If connected to a network other than MXWireless, follow this setup instruction but you will also need to
•
reference a document called Creating a Wi-Fi Configuation File
Without connecting the console to a wireless or wired network, the following features will not be able to
•
function.
o Automatic software updates
o Asset Management reporting
o RFID login (touchless login for xID)
o Workout Tracking/Community 360 and Personal Trainer/Engage 360 features
o Bluetooth connectivity (user must sign in with xID for feature to use feature)
Console Setup Instruction :
Matrix LED Console
Console Model: TM749
Revision Date:
January 18, 2024

Table of Contents

Section 4 - Connecting to Wi-Fi (Optional)
Machine Type
Manual Serial Number Upload Process
Machine Settings Menu
Table of Contents
Adjusting Console Beeps
Bulletin Number:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TM749 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matrix Fitness TM749

Summary of Contents for Matrix Fitness TM749

  • Page 1: Table Of Contents

    Enter 3002 Enter – First Time Setup (FTSU) Enter 3001 Enter – Machine Settings Things to know: Wi-Fi is an optional feature on LED (TM749) consoles which means consoles may not be equipped with • Wi-Fi boards installed. If the console is purchased with optional Wi-Fi feature the Wi-Fi boards will be pre-installed •...

  • Page 2: Navigating The Console

    Navigating the Console Section 1 - First Time Setup (FTSU) If the console is new it may come to FTSU screen when powered on for the first time. If so, go to Step 2 otherwise from the Welcome Screen, enter FTSU by pressing Enter 3002 Enter on the keypad 1.
  • Page 3 b. Use the numeric keypad on the bottom overlay to enter the customers unique Club ID. If no Club ID is known, enter “60” then press Enter Wi-Fi will be displayed a. Press Enter when Wi-Fi is displayed. b. Import USB Wi-Fi config file will be displayed. Press Enter. The display will show “processing” then “No USB”.
  • Page 4 add a letter to the model type, use the + and – keys to scroll through the alphabet. Double check console serial number sticker for accuracy. Note: Console serial numbers may have a letter after the prefix (Ex. CTM749B). This is part of the serial number to help identify hardware and derivative models when ordering parts.

  • Page 5: Section 2 - Incline Motor Calibration

    5. Cycle power to save the changes. Section 4 - Connecting to Wi-Fi (optional) Refer to the Creating a Wi-Fi Config File document if connecting to a Wi-Fi network or visit the Matrix Fitness YouTube channel for a video resource > Link Here - https://youtu.be/QBJUOP-Cy5g?si=nzNnyrhIq9_DsLKP.
  • Page 6 Machine Type Frame Model Machine Type Performance Plus T-PP-F Performance T-PS-F Treadmill Endurance T-ES-F Lifestyle T-LS-F Performance A-PS-F Ascent Performance Lower Body ALB-PS-F Performance E-PS-F Elliptical Endurance E-ES-F Lifestyle E-LS-F Performance C-PS-F ClimbMill Endurance C-ES-F Lifestyle C-LS-F Performance U-PS-F Upright Endurance U-ES-F Lifestyle...

  • Page 7: Check Current Software Version

    Machine Settings (enter 3001 enter) There are multiple categories of settings where different aspects of the console’s setup & operations are configured. Machine Settings for LED Console (TM749) can be found on the menu below. Check Current Software Version Console software controls all console functions, including communication with the frame. Updating software is a powerful troubleshooting &...

  • Page 8: Out Of Order

    4. Access Machine Settings by pressing ✓3001✓ and navigate to ‘Software’. 5. Scroll through available menus & choices with the Speed/Resistance +/- keys. 6. Navigate to ‘Update’ and choose UCB to view console software version. 7. Insert USB stick into USB port on console. 8.

  • Page 9: Adjusting The Entertainment Volume

    Adjusting the Entertainment Volume To adjust the default (starting volume) for MYE TV or Wireless Audio, follow the steps in this section. 1. Use the numeric keypad and press ✓ 3001 ✓ to get into the Machine Settings. 2. Scroll through available menus & choices with the Speed/Resistance +/- keys. 3.
