Adcon 5 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A440 Wireless Modem
Series 5
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Adcon 5 Series

Summary of Contents for Adcon 5 Series

  • Page 1 A440 Wireless Modem Series 5 User Guide...
  • Page 2 OTT Hydromet GmbH Business Unit ADCON Telemetry Inkustraße 24 · 3400 Klosterneuburg Austria Phone +43 2243 38280-0 Document Release 1.0, 07.2017 Fax +43 2243 38280-6 Copyright (c) by OTT Hydromet GmbH info@adcon.at www.adcon.at We reserve the right to make technical changes and improvements without notice.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents Introduction ............. 5 About the A440 Series5 Wireless Modem ....5 Compliance Statement and Warnings ......5 Conventions ..............6 Using the A440 Series 5 Wireless Modem ..7 Before Field Installation ..........7 Installing the outdoor unit ..........
  • Page 4 Table of Contents PMP ....................17 ANLG .....................18 DATA ....................21 FDEV ....................23 INFO ....................23 PORT .....................25 RX ....................27 TX ....................28 B .....................28 BLST ....................28 VER ....................29 SDI ....................29 DATASDI ..................30 DEL ....................32 DEV ....................32 MASTER ..................33 REPL ....................33 ROUTE ...................33 Notifications ............... 34 Returned errors list ...........

  • Page 5: Introduction

    The A440 Series 5 Wireless modem will be operated in conjunction with an Adcon A850 Telemetry Gateway. 1.2 Compliance Statement and Warnings The A440 must not be used with any antenna other than the one supplied by Adcon (or an antenna with identical technical specifications).

  • Page 6: Conventions

    Conventions A minimum distance of 18 cm to the antenna is required in order to guarantee compliance with basic safety restrictions. In conformity with the EC Parliament recommendations 1999/519/EG 28V/m is the reference value for the frequency range used. By adhering to any and all recommended reference levels, the compliance to basic restrictions serving the protection of the general public against electromagnetic fields is ensured.

  • Page 7: Using The A440 Series 5 Wireless Modem

    Gateway is limited, for the complete Base Station. If the A850 is used in combination with one or several Adcon Wireless Modem(s) A440, the Base Station configuration will consist in an indoor unit (the A850) and one (or several) outdoor unit(s), the A440(s).

  • Page 8: Installing The Outdoor Unit

    Note: The cable for the outdoor unit delivered with the system is by default 30 m (about 100 ft) long. If necessary, however, you can increase the distance between your indoor and your outdoor unit up to 75 m by using special cables which can be provided upon request by Adcon.

  • Page 9: Maintaining And Servicing The A440

    WARNING We highly recommend to only use the low attenuation RS-485 cables provided by Adcon with a total length of up to 75 m because attempts to make extensions using other cables could make your Wireless Modem inoperable, due to the voltage loss on the additional cable length.

  • Page 11: Performing Advanced Functions

    Performing Advanced Functions 3 Performing Advanced Functions Do not try to configure your A440 devices if you are not sure what to do—the unit may not communicate with the remote measuring station. Tampering with parameters for the A440 devices may void your warranty or damage the device.

  • Page 12: Setting Up A Radio Network

    Setting up a Radio Network WARNING If you use a different power supply than the A850, this must be limited to a maximum of 3A and a maximum of 10 V. 3.2 Setting up a Radio Network After you have installed the A440 Series 5 Radio Modem and connected it to the A850 Gateway, you can proceed with the radio network setup by using the A850’s Configurator GUI.

  • Page 13: General Format Of An Answer

    Performing Advanced Functions • Command is the command proper, which can be composed of a variable string of characters (for example, ). Each node can implement a set of SLOT commands depending on the functionality of the node itself. However, as a minimum requirement, a node recognizes the CMDS command, which returns a list with the commands recognized by the node.
  • Page 14 Serial communication protocol CRCProtectedRequest ::= OptionalLinkID UnprotectedRequest '~' CRC LineDelimiter ; OptionalLinkID ::= IdNumber WhiteSpace | WhiteSpace ; IdNumber ::= <number from 1 to 65534> ; WhiteSpace ::= WhiteSpaceCharacter | WhiteSpaceCharacter WhiteSpace ; WhiteSpaceCharacter ::= <SPACE> | <TAB> | <CR> | <LF> ; CRC ::= 4 * HexNumber HexNumber ::= '0'..'9' | 'a'..'f' | 'A'..'F' ;...

  • Page 15: Using Terminal Commands

    Performing Advanced Functions ignored. When an optional link ID is given, then the reply will also be prefixed with the link ID. In order to detect if an A440 is capable of using this protocol enhancement should check (an unknown) A440 for its capability of handling this protocol by either deciding based on the version number of the A440 or by sending over '>~b9c3' to the A440.

  • Page 16: Rssi

    Using terminal commands Do not change the frequency of your device without reason: apart from the fact it AUTION may not communicate in the network anymore, you may also violate the applicable radio-communications laws in your country. Depending on the destination country, some models may also return an error message.

  • Page 17: Slot

    Performing Advanced Functions 445 ID 445 0 SLOT Changing these parameters may adversely affect the ability of the remote device to AUTION operate for extended periods under low solar radiation conditions. Remote only. COPE Sets the node’s sampling interval and rate. ESCRIPTION The interval (10 - 65535) and rate (0 - 255).

  • Page 18: Anlg

    Using terminal commands 31215 PMP 0 ANLG Remote only. COPE Sets/returns various parameters of the analog subsystem (for example, the ESCRIPTION sampling/averaging method used for individual data acquisition channels). A control byte specifying the command and the analog input channel number the ARAMETERS command is acting on: Command Code...
  • Page 19 Performing Advanced Functions Code Parameters Returns Description store the arithmetic average of all sampled values 0101SSMCA – Set Sampling Method to The channel number Result (OK or ERROR) Circular Average. The specified ana- log channel will be instructed to store the circular average of all sampled values.
  • Page 20 Using terminal commands Code Parameters Returns Description The channel number Result (OK or ERROR) 1110ENOL – Enable Notify if Out of Limits and the limit values (16 bit value), first the lower and then the higher limit. 1111ENIL – Enable Notify if Inside the The channel number Result (OK or ERROR) and the limit values (16...

  • Page 21: Data

    Performing Advanced Functions The general behavior is that an ANLG command issued on a certain input channel EMARKS will override any previous ANLG commands affecting that channel. Yes. EMOTE For RSM XAMPLE 31215 ANLG 0 31215 ANLG 0 5 5 5 5 5 5 5 5 4 4 5 5 0 For SSMAA (on channel 4) 31215 ANLG 68 31215 ANLG 68 0...
  • Page 22 Using terminal commands The data block returned will typically contain a number of data frames (telegrams). The structure of a block is as follows: dd mm yyyy hh mm ss si ft d1 d2 ... dn dd mm yyyy ... dn cs where: •...

  • Page 23: Fdev

    Performing Advanced Functions I/O D Cabling 1 I/O D Cabling 2 I/O D Cabling 3 Figure 4, Frame 37 (left) and Frame 38 (right) description Dig6 Dig5 Dig4 Dig3 Dig2 Dig1 Dig0 SC-Battery Charge (0-off, 1-on) Dig n – Digital I /O n Figure 5, The Digibyte The remote version is limited to a single frame.
  • Page 24 Using terminal commands ID INFO rf_in rf_out date time ver clk stack cop batt temp days_uptime hr:min_uptime rssi pmp_low pmp_high type slot samples po module_rx_time module_tx_time module_off_time err_level The formats for the above parameters are as follows: • rf_in and rf_out as a decimal •...

  • Page 25: Port

    Performing Advanced Functions • po is the power output of the device during the last frame sent; this value is relative (500 mW corresponds to a value of approx. 120) • module_rx_time the time the radio module was in receive mode in seconds •...
  • Page 26 Using terminal commands Code Description Parameters Returns 0010 CAI – Configure the port specified by The port number Result (OK or ERROR). Port Number as input (acts upon the Data Direction Register). 0011 CAO – Configure the port specified by The port number Result (OK or ERROR).
  • Page 27 Performing Advanced Functions Code Description Parameters Returns 1110 MVFR – Multivibrator function, start with the The port number, the ON Result (OK or ERROR). specified bit in OFF state (reset). and the OFF times (in seconds), both as 16-bit integers. 1111 MVFS –...

  • Page 28: Blst

    Using terminal commands EMOTE XAMPLE 444 RX 0 Local only. COPE Switches the unit to transmit mode (for tuning purposes). ESCRIPTION None (sends an unmodulated carrier), 1 (sends a 1 kHz modulated carrier), 0 (sends ARAMETERS a 2 kHz modulated carrier) or 5 (sends a mixed 1 + 2 kHz modulated carrier). Nothing.

  • Page 29: Ver

    The full extend of the commands is not given here as the configuration of the SDI-12 subsystem is done via the wireless link by means of the GUI configurator in the A850 Telemetry Gateway. Additional information can be obtained from Adcon Telemetry upon request.

  • Page 30: Datasdi

    Using terminal commands • m/M — Measurement command started: m no measurement is being done, M a measurement is in progress; • v/V — Values for storage available: v no values are available, V values are available for local storage; •...
  • Page 31 Performing Advanced Functions A733 A732 / A731 RF incoming RF incoming RF outgoing RF outgoing Digibyte Digibyte I/O A Pulse I/O A Pulse Counter Counter I/O B Pulse I/O B Pulse Counter Counter I/O C Pulse Battery Counter I/O D Pulse I/O A Cabling 1 Counter Battery...

  • Page 32: Del

    Using terminal commands For additional information on the significance of the SDI address, method and index, please see also the SDI-12 standard specification (http:// www.sdi-12.org). The digibyte is similar to the DATA command: Dig6 Dig5 Dig4 Dig3 Dig2 Dig1 Dig0 SC-Battery Charge (0-off, 1-on) Dig n –...

  • Page 33: Master

    Performing Advanced Functions MASTER Local only. COPE Lists the current device table and master status or changes the master flag for the ESCRIPTION specified RTU. The RTU must already be inserted into the device table. When the master flag for an RTU is set to 1, then the A440 will synchronize the clock of the RTU when it was not set before or the RTU returns a data telegram with a timestamp of 1/1/1970 00:00:00 for a data request (see DATA).

  • Page 34: Notifications

    Notifications 3.6 Notifications Notifications are frames sent asynchronously by devices that are otherwise slaves. The notifications are received by a device closest to the host and then sent to the host. If the host is not available, the receiving device will store the notification and wait until it is questioned by the host.

  • Page 35: Real Time Clock

    Performing Advanced Functions 16 — time-out (the handler blocked or is busy) 17 — internal error 18 — attempt to insert a reserved device ID number (0 or 65535) 3.7.3 Real time clock 20 — incorrect time supplied (conversion to time_t was not possible) 3.7.4 Radio interface 30 —...

  • Page 36: Specifications

    Returned errors list 4 Specifications The A440 was intended to fulfill the specification of the EN 300 220-1, and ETSI 300 113, as well as the FCC Part 90, Subpart J of the CFR 47. Fehler! Verweisquelle konnte nicht gefunden werden. shows the main operational parameters of the A440.
  • Page 37 Specifications Transmitter Parameter (50 Ohm resistive Unit Load) Output Power 26.5 Spurious Emission (0 to 862 MHz) (c) Spurious Emission (862 MHz to 3.6 GHz) Adjacent Channel Power (12.5 KHz) Adjacent Channel Power (25 KHz) Occupied Bandwidth (12.5 KHz) Occupied Bandwidth (25 KHz) Operating Current 0.77 a.

  • Page 39: Index

    Index Index Advanced Functions ......11 Operating Frequency ......36 Operating Temperature ...... 36 cable ............8 Class Protection ........36 Power Supply Current limit ....36 commands ........... 15 Compliance Statement ......5 Relative Humidity ........ 36 connector ..........11 RS232 ..........
