Disconnect blade
Skid
Figure 1� Pole-unit on skid�
Yellow
(Open)
Figure 2� Interrupter Target�
8
S&C Instruction Sheet 711-510
Instructions in water-
resistant envelope
Brain
Container for shunt-trip
insulated operating shaft
Gray
(Closed)
Figure 3� Gas-pressure target indicator�
Interrupter
Box for hardware
Gas-pressure
indicator (gray)
Pole-unit
base
