Location of Safety Labels

K
Reorder Information for Safety Labels
Location Safety Alert Message
A WARNING
Instruction
B
C
CAUTION
Instruction
D
NOTICE
E
F CAUTION
G WARNING
H
CAUTION
I
CAUTION
J
WARNING
K
CAUTION
● Temporary tag� Remove after installation�
■ Shunt-trip option only�
▲ For 161 kV Circuit-Switchers only�
G
F
A
D
Interrupter pressurized to 38 PSI� Install protective shields prior to removal�
Interrupter Part Number� Replace with catalog number���
This shield must be removed during installation-- but only when indicated���
Do not lift here�
After the shunt-trip insulated operating shaft has been installed���
This insulator mounting flange position bolt contained in this bag must be used���
Do not lift the brain and interrupting unit by attaching slings to the disconnect blade�
Before putting the switch into service, the interrupters must be closed���
The high-energy solenoid in this housing is designed for intermittent duty���
DO NOT remove steel outer wrapper until installation is complete�
Instructions for lifting 161-kV Circuit-Switcher pole-unit skid���
H E
I
B
Description
S&C Instruction Sheet 711-510
Safety Information
J
C
Part Number
G-9686
G-6376
G-6043 ●
G-3824
G-4602 ■
G-4766 ●
G-4093 ●
G-4512 ●
G-4947 ■
G-5993
G-5990R1 ▲
