Page 1: User Manual
Innovative LCD Display User Manual 32" wide LCD AP-32W Front aluminum LCD panel NAP-32W Front NEMA4 / IP 65 LCD panel DP-32W Stylish front aluminum cover LCD panel OP-32W Open frame LCD panel Options : - TV tuner... -
Page 2: Table Of Contents
LCD panel Package Contents.............3 Structure Diagram ................. Dimension Diagram ..............Mounting Method................Chapter 3 NAP-32W front NEMA4 / IP 65 LCD panel Package Contents.............7 Structure Diagram ................. Dimension Diagram ..............Mounting Method................10 Chapter 4 DP-32W stylish front aluminum cover LCD panel Package Contents............11... - Page 3 On-screen Display Operation........20 On-screen Menu............21 Chapter 8 LCD Specifi cations ..........22 Chapter 9 TV Tuner Options TV Tuner Options............23 How to Use Remote Controller.........24-25 Chapter 10 Troubleshooting ............26 Chapter 11 Dimensions ..............27 Chapter 12 Cleaning 12.1 Cleaning the LCD display..........28 12.2...
-
Page 4: Important Safeguards
Chapter 1 1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover ■ Any product, on which the serial number has been defaced, modifi ed or removed. -
Page 5: Before Installation
■ The surface for placing and fi xing the LCD Display should be stable. ■ Make sure the place has good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. ■... -
Page 6: Front Aluminum Lcd Panel 2.1 Package Contents
Chapter 2 2.1 AP-32W series Package Contents LCD display x 1 pc 6' VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc S-Video cable x 1pc RCA cable x 1 pcs... -
Page 7: Structure Diagram
Chapter 2 2.2 AP-32W series Structure Diagram Front View Rear View Rear case LCD membrane SAMSUNG LCD panel Wall-mount bracket 6mm aluminum front bezel... -
Page 8: Dimension Diagram
Chapter 2 2.3 AP-32W series Dimension Diagram UNIT : mm 1mm = 0.03937 inch Front View Rear View... -
Page 9: Mounting Method
Chapter 2 2.4 AP-32W series Mounting Method UNIT : mm 1mm = 0.03937 inch Wall mounting Remarks ■ Hardware and M5*8pcs for Wall mounting is not provided 100mm VESA standard Remarks ■ Hardware and M6*8pcs for VESA mounting is not provided... -
Page 10: Front Nema4 / Ip 65 Lcd Panel 3.1 Package Contents
Chapter 3 NAP-32W series Package Contents LCD display x 1 pc 6' VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc S-Video cable x 1pc RCA cable x 1 pcs... -
Page 11: Structure Diagram
Chapter 3 NAP-32W series Structure Diagram Front View Rear View Rear case 6mm aluminum front bezel SAMSUNG LCD panel LCD membrane 4mm protective glass (Front Nema 4 / IP 65 protection) Wall-mount bracket... -
Page 12: Dimension Diagram
Chapter 3 NAP-32W series Dimension Diagram UNIT : mm 1mm = 0.03937 inch Front View Rear View... -
Page 13: Mounting Method
3.4 NAP-32W series Mounting Method UNIT : mm 1mm = 0.03937 inch Wall mounting Remarks ■ Hardware and M5*8pcs for Wall mounting is not provided 100mm VESA standard Remarks ■ Hardware and M6*8pcs for VESA mounting is not provided P.10... -
Page 14: Stylish Front Aluminum Cover Lcd Panel 4.1 Package Contents
Chapter 4 4.1 DP-32W series Package Contents LCD display x 1 pc 6' VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc S-Video cable x 1pc RCA cable x 1 pcs... -
Page 15: Structure Diagram
Chapter 4 4.2 DP-32W series Structure Diagram Front View Rear View Rear case 1.2mm front aluminum cover SAMSUNG LCD panel LCD membrane P.12... -
Page 16: Dimension Diagram
Chapter 4 4.3 DP-32W series Dimension Diagram UNIT : mm 1mm = 0.03937 inch Front View Rear View P.13... -
Page 17: Mounting Method
Chapter 2 3.4 DP-32W series Mounting Method UNIT : mm 1mm = 0.03937 inch 100mm VESA standard Remarks ■ Hardware and M6*8pcs for VESA mounting is not provided P.14... -
Page 18: Open Frame Lcd Panel 5.1 Package Contents
Chapter 5 5.1 OP-32W series Package Contents LCD display x 1 pc 6' VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc S-Video cable x 1pc RCA cable x 1 pcs... -
Page 19: Structure Diagram
Chapter 5 5.2 OP-32W series Structure Diagram Front View Rear View Rear case Universal open frame mounting SAMSUNG LCD panel LCD membrane P.16... -
Page 20: Dimension Diagram
Chapter 5 5.3 OP-32W series Dimension Diagram UNIT : mm 1mm = 0.03937 inch Front View Rear View P.17... -
Page 21: Mounting Method
3.4 OP-32W series Mounting Method UNIT : mm 1mm = 0.03937 inch 100mm VESA standard Remarks ■ Hardware and M6*8pcs for VESA mounting is not provided Universal open frame mounting Remarks ■ Hardware for fixing the LCD display is not provided P.18... -
Page 22: Chapter 6 Connection
LCD Display. Before attempting to connect anything to the LCD Display, we suggest that turn off power to all devices before connecting them. Apply power to connected devices again only after the LCD Display re- ceiving power.The company is not responsible for damage caused in this way. -
Page 23: On-Screen Display Operation
Display the OSD menu Scrolls through menu options and adjusts the displayed control Exit the OSD screen Shortcut key to auto adjustment by pressed the button for 5 seconds Toggle analog, digital & video connection (DVI-D and video options only) P.20... -
Page 24: On-Screen Menu
To enter into the scheme, brighness, contrast, saturation, hue, sharpness, advanced and reset scheme sub-menu Display: To enter into the auto auto AR, aspect ratio and PIP sub-menu To enter into the 5 band graphic equalizer Clock / Timer: To enter into sleep timer... -
Page 25: Chapter 8 Lcd Specifi Cations
Analog RGB Display Input Signal DB15 connector Connection Auto-sensing 100 to 240VAC, 50 / 60Hz Power Input Power Consumption Multi-platform - Mix PCs, SUNs, IBMs, HPs & DELLs. Compatibility Options Environmental Operation 0˚ to 50˚C Degree Storage -5˚ to 65˚C Degree... -
Page 26: Chapter 9 Tv Tuner Options
Chapter 9 9.1 TV Tuner Options Audio in with speaker Component Video Connector Power Input Device HDMI S-Video Video Audio-R Audio-L Remarks ■ Package includes a remote controller P.23... -
Page 27: How To Use Remote Controller
9.2 How to Use Remote Controller POWER MUTE INPUT DISPLAY CLEAR SELECT BACK MENU EXIT ENTER AUDIO FREEZE ZOOM ASPECT ADJUST SOURCE SWAP POSITION SLEEP AUDIO ASPECT P.24... -
Page 28: How To Use Remote Controller
SLEEP Turn on or off the speaker MUTE Select the Main Channel input source INPUT Press this button will hide the current input source name on the Top- Left position CLEAR Return to the previous channel watched BACK Exit the menu or cancel... -
Page 29: Chapter 10 Troubleshooting
1. The membrane button power light is not ON ■ Press the power On /Off on LCD membrane button to check if the monitor is in the ON mode. ■ Check the power cord is properly connected to the LCD display and power outlet. -
Page 30: Chapter 5 Op-32W
Gross Model Net Weight (W x D x H) (W x D x H) Weight 850 x 125 x 520 mm 963 x 240 x 632 mm 23 kg 39 kg AP-32W series 33.5 x 4.9 x 20.5" 37.9 x 9.4 x 24.9"... -
Page 31: Cleaning The Lcd Display
12.2 Cleaning 1. Use a soft cloth for cleaning 2. If it is heavilystained, soak a soft cloth in a mixture of water and detergent and squeeze it dry before wiping off the stains. 3. Use a soft, dry cloth for fi nal cleaning. - Page 32 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2007 Austin Hughes Electronics Ltd. All rights reserved.
