IQ DIMMER QUICK INSTALL GUIDE
FEATURES & OVERVIEW
The IQ Dimmer can be used to turn any outlet into a smart outlet to turn lamps On,
Off, or control dimming of any lamps with dimmable light bulbs. Each Z-Wave device
also serves as a repeater in the Z-Wave network, extending and improving the mesh
network in the installed location.
SmartStart. You can now add this device securely and with ease using QR code on the
product.
Use Locations:
Kitchen
Living Room
Basement
Bedrooms
Garage
WARNING: Do not install to control a motor-operated
Appliance, a non-dimmable fluorescent lighting fixture, or a
transformer-supplied appliance. The lighting devices connected
to this Z-Wave module must not exceed 2.5A, 300W
incandescent, 150W dimmable CFL/LED, 120VAC 60Hz
This is a quick guide for experienced installers only. Refer to http://dealers.qolsys.com (login required)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
SPECIFICATIONS
(CFL), or LED lighting
8
150W Dimmable LED/CFL
code on bottom of device)
Functions as a Z-Wave signal repeater
Indoor Use Only
Class II
Purpose of control: Operating Control;
Construction of control: Portable Direct Plug In Type;
Type 1 Action;
Pollution Degree: 2
Impulse Voltage: 1500 V
Not Suitable for Appliances which only allowed to be
plugged into wall outlet or a single outlet circuit, such as
room heaters and window air conditioners.
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). Son fonctionnement est
