  • Page 1 FreeSpace FS2C & FS4CE Retrofit Kit Installation Guide . . . . . . . . . . . . . . . . . . . . . . . 2 Monteringsveiledning .

  • Page 2: Package Contents

    WARNINGS/CAUTIONS: All Bose Professional products must be installed in accordance with local, state, federal and industry regulations. It is the installer’s responsibility to ensure installation of the loudspeakers and mounting system is performed in accordance with all applicable codes, including local building codes and regulations. Consult the local authority having jurisdiction before installing this product.

  • Page 3: Product Dimensions

    Installation Product Dimensions FreeSpace FS2C FreeSpace FS4CE 0.72 kg (1.59 lb) 0.86 kg (1.90 lb) 162 mm 265 mm 6.38 in 10.43 in 365 mm 249 mm 14.37 in 9.80 in 644 mm 25.35 in 644 mm 25.35 in 0.10 kg (0.22 lb) 0.20 kg (0.44 lb)
  • Page 4 Choose a mounting position, method, and hardware consistent with local building codes and regulations. Bose Professional recommends using (1) a safety wire as a secondary securing mechanism. See the diagram for safety attachment points. Follow the manufacturer’s instructions for any secondary securing mechanism implemented.

  • Page 5: Installation

    For visual representations of the FreeSpace loudspeakers installed with retrofit kits (no wiring), see the following figures: A. FreeSpace FS2C with small ring. Intended for replacing and matching the diameter of FreeSpace DS 16F. B. FreeSpace FS2C with wide ring.

  • Page 6: Descripción General

    ADVERTENCIAS/PRECAUCIONES: Todos los productos Bose Professional deben instalarse conforme a las leyes locales, estatales, federales y del sector. Es responsabilidad del instalador garantizar que la instalación del sistema de soporte y los altavoces se realice conforme a los códigos aplicables, incluidos los códigos y las reglamentaciones de construcción locales. Consulte a la autoridad local competente antes de instalar este producto.

  • Page 7: Dimensiones Del Producto

    Instalación Dimensiones del producto FreeSpace FS2C FreeSpace FS4CE 0.72 kg (1.59 lb) 0.86 kg (1.90 lb) 162 mm 265 mm (6.38") (10.43") 365 mm 249 mm (14.37") (9.80") 644 mm (25.35") 644 mm (25.35") 0.10 kg (0.22 lb) 0.20 kg (0.44 lb)
  • Page 8 Bose Professional recomienda utilizar un alambre de seguridad (1) como mecanismo secundario de fijación. Consulte el diagrama para conocer los puntos de fijación de seguridad.
