Table of Contents

Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . 2
Important Safety Instructions. . . . . . . . . . . . 34
Table of Contents / Setup Information . . . . . . . 5
HCS6600 Product Description . . . . . . . . . . . . 6
Transcoder Product Description . . . . . . . . . . . 7
Card Description . . . . . . . . . . . . . . . . . . . . . . . 8
Installing CodePlus Transcoder Cards . . . . . . . 9
Setup Information
This document provides installation and setup support only for an HCS6600 transcoder card. Cable
TV service and a Cable TV STB receiver must be installed and operating before you can proceed to
set up the HCS6600. LG recommends that the system be professionally installed.
Check the items listed below before you begin the HCS6600 installation and setup procedures.
Cable Set-top Box (STB)
__ Refer to the documentation provided with the
Cable TV STB, and carefully follow the sys-
tem setup procedures. (The Cable TV STB
receiver provides the IEEE-1394 signal input
for the HCS6600.)
__ Authorization is required for HD channels.
Contact your local Cable TV provider to get
subscription programming authorization for
the Cable TV STB receiver.
ASI Output (Optional)
__ If applicable, install the DTV modulator and
upconverter that will receive the ASI output
signal from the HCS6600. Refer to the man-
ufacturer's documentation.
206-4119
Table of Contents / Setup Information
Cable TV STB Receiver & HCS6600
Initialization & Setup Connections . . . . . . . . . 10
System Setup . . . . . . . . . . . . . . . . . . . . . .1112
Configuration Options . . . . . . . . . . . . . . . 1315
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 16
Specifications . . . . . . . . . . . . . . . . . . . . . . . . 17
Document Revision History / Notes . . . . . . . 18
Warranty . . . . . . . . . . . . . . . . . . . . . Back Cover
HCS6600
__ If the HCS6600 will be used with a unique
feature card (Example: HCS6300) in the
card frame CONTROLLER slot, you will also
need a copy of the Installation & Setup
Guide for the feature card in order to com-
plete the HCS6600 system setup.
__ For HCS6600 Service Port connections, you
must use an FTDI TTL-USB cable (P/N TTL-
232R-5V-AJ).
