Summary of Contents for Seada SD-WCS
- Page 1 WIRELESS CONFERENCE SYSTEM SD-WCS USER MANUAL...
-
Page 2: Table Of Contents
Table of contents Before you start Introduction ………………………………... 1 Caution: Features ………………………………………. 1 1.This equipment shall be used within working temperature(-10℃ Product overview ~45℃). Controller front panel.…………………..2 2.The minimum installation gap for the main controller shall be Controller rear panel..…………………..2 Chairman unit ……………………………..3 20CM &... -
Page 3: Before You Start
Before you start Product overview This is a wireless system provides flexible solution for multi-purpose meeting Controller Front Panel application. It’s a quick & easy to setup the system with its user-friendly touch screen operation on the main controller , its simply elegant microphone unit produces high quality mbre for meeting purpose. -
Page 4: Chairman Unit
Product overview Product overview Chairman unit Microphone display 1. Condenser microphone capsule Detachable design, to pickup audio signal from speaker C:10-001 2. Mic indicator To indicate the working status of microphone 3. Display To show the working state 4. Func on key - YES/NO/ABST 5. -
Page 5: System Connec On Diagram
Product overview Operation System connection diagram Controller system interface Home Control Setup Vote camera CHANNEL Indicate the current working channel group of the system. UHF STATE To indicate the occupancy status and signal level of each channel. Chairman Unit When appears and shown in blue color, that means the channel is occupied by the units and communica on established. -
Page 6: Control
Operation Operation Control Mode Quit Mode Config Setup Vote Home Control FIFO LIFO Unit ID Limit Chairman Off All Off Shutdown LIMIT : No more microphone units can be switched ON when the active mic no. reached the OPEN MIC QTY. UNIT ID Input the microphone ID needed for the opera on. -
Page 7: Camera
Operation Operation UNIT VOL Tracking To unify the gain level of all the microphone units connected to the system. Note: User can press ENTER + > for 5 sec. to enter gain adjustment menu on each Camera Tracking Quit microphone if needed. Speed+ Speed- Unit ID... -
Page 8: Preset
Operation Operation Preset Operation: 1) Specific microphone ID config Camera Preset Advance Quit Info Config - Power ON the unit and ensure it connected to the host on the same channel. System Config - Input the ID number, and press “Start” . Preset1 - Units connected the system will receive the config command, and message will show on Mode:FIFO... -
Page 9: Signal
Operation Operation Time Signal Time FREQ Quit ID Config Signal ID Config Signal Time FREQ Quit 2022 604.800M 607.100M 602.000M 623.500M Off Off Off Off This menu allows user to set the time for the system, and this is related to the timing displayed on each microphone unit. -
Page 10: Vote
Operation Operation The system can start a quick voting directly from the controller . Vote By pressing the Vote bu on to kick off the process, a endees select YES,NO or ABSTAIN from Setup Vote Home Control the microphone then press ENTER to upload their selection. Online Info Sign-in Info Vote Info...
