ZooZ ZW1505 User Manual

Z-Wave on/off control of up to 5 electrical devices
Ÿ
On/off (charging/charged) reports from USB ports to the hub (no Z-
Ÿ
Wave control) - turn off the charging device for best results
Energy monitoring for each of the 5 outlets
Ÿ
Built-in overload protection and ETL certification
Ÿ
Z-Wave Plus signal repeater to extend network range
Ÿ
S2 security protocol and the latest 500 Z-Wave chip for faster and safer
Ÿ
wireless communication
Model Number: ZW1505 VER. 3.0
Ÿ
Z-Wave Signal Frequency: 908.40 MHz,908.42 MHz,916MHz,912MHz,
Ÿ
920MHz
Power: 120 VAC
Ÿ
Maximum Load: 15 A total (between 5 outlets)
Ÿ
Maximum Load for USB ports: 2.1 A total (between 2
Ÿ
Cord Length: 2 feet
Ÿ
Range: Up to 100 feet line of sight
Ÿ
Installation and Use: Indoor only
Ÿ
CAUTION
This is an electrical device - please use caution when installing and
operating the power strip. Remote control of appliances may result in
unintentional or automated activation of power. Do NOT use this Z-Wave
device to control electric heaters or other appliances which produce the
risk of fire, burns, or electrical shock when unattended.
Plug the Power Strip into any standard grounded 110 V receptacle. Do
NOT connect any devices to the strip at this point. Turn the power
switch on (the RESET side) and click each of the channels control
buttons to see if the LED indicators come on and off. If the LED
indicators don't light up at all, please try a different receptacle. If they're
still off, please make sure the power switch is on. If the problem persists,
please get in touch with our support team: ask@getzooz.com
BEFORE YOU PLUG ANYTHING IN
Make sure the load you are about to connect does NOT exceed 15 A
in power. This Power Strip can hold up to 15 A in total. It means that the
power of all appliances connected to your ZW1505 at a given time can
NOT exceed 15 A. It doesn't matter if this is just one device connected to
one of the outlets or 5 small appliances plugged into all of the Strip's
outlets.
Connecting heavy duty equipment to this Power Strip will DAMAGE
the device and may cause the connected appliance to malfunction.
Do NOT plug washers, dryers, refrigerators, or motors over 1/3 hp
to any of the outlets on the Power Strip.
S2
This product can be included and operated in any Z-Wave network with
other Z-Wave certified devices from other manufacturers and/or other
applications. All non-battery operated nodes within the network will act
as repeaters regardless of vendor to increase reliability of the network.
This product features the latest Security 2 (S2) framework to remove
smart home network hacking risks. This device supports the S2
unauthenticated security level with encrypted communication.
WARNING
This product should be installed indoors upon completion of any building renovations.
Ÿ
Prior to installation, the device should be stored in a dry, dust-and-mold-proof place.
Ÿ
Do not install the Power Strip in a place with direct sun exposure, high temperature, or
Ÿ
humidity.
Keep away from chemicals, water, and dust.
Ÿ
Ensure the device is never close to any heat source or open flame to prevent fire.
Ÿ
Ensure the device is connected to an electric power source that does not exceed the
Ÿ
maximum load power.
No part of the device may be replaced or repaired by the user.
Ÿ
This product is covered under a 12-month limited warranty. To read the
full warranty policy or file a warranty claim, please go to
USER MANUAL
S2 Z-Wave Plus Power Strip with USB Charging Ports
ZW1505
SPECIFICATIONS
INSTALLATION
WARRANTY
www.getzooz.com/warranty
CH 1 CH 2
FEATURES
Not sure if your equipment can be
safely controlled by the Power Strip?
Just ask: ask@getzooz.com
CH 3 CH 4 CH 5
ports)
