- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 602274P POWER LIFT RECLINER REVISION 0 :05/10/2024 COASTERFURNITURE.COM PAGE 1 OF 7...
-
Page 2: Parts Identification
602274P ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. - Page 3 602274P ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Insert the Chair back (②) on the Chair seat (①) . Gently push down until the back locks into position. PAGE 3 OF 7 COASTERFURNITURE.COM...
- Page 4 602274P ITEM: ASSEMBLY INSTRUCTIONS STEP 2 No.1: Wire connect the motor and the Control Panel, No.2 Wire connect the motor and ： transformer (A). No.3 Plug(B) connect the ： transformer (A) PAGE 4 OF 7 COASTERFURNITURE.COM...
- Page 5 602274P ITEM: ASSEMBLY INSTRUCTIONS STEP 3 Butterfly nut up,screw bolt down Anti- fall Brackets*2(D) Anti-fall Brackets PAGE 5 OF 7 COASTERFURNITURE.COM...
-
Page 6: Remote Instructions
602274P ITEM: REMOTE INSTRUCTIONS How to recline? Press How to get footrest latch down and stand? Press PAGE 6 OF 7 COASTERFURNITURE.COM... - Page 7 602274P ITEM: Note : Dimension tolerance ± 5% PAGE 7 OF 7 COASTERFURNITURE.COM...
