HANWHA FISHEYE CONFIGURATION QUICK GUIDE
Hanwha Fisheye Configuration
Quick Guide
To use the dewarping of the Hanwha camera in G-View, you must add the camera
to the Geutebrück Plugin Loader using the Hanwha plugin and add the camera
channels for dewarping.
Configuration in the camera web interface:
In the web interface of the camera, you can add channels to show the dewarped
video of the fisheye camera. Channel 1 is the default video for the fisheye camera.
More channels can be added to dewarp the video of fisheye camera and display it
appropriately.
1. Enter the IP address of the camera in the browser to reach the web interface
and navigate to Setup
2. In Select channel, click Add to add channels to dewarp the video of the
fisheye camera and display it accordingly.
3. In View mode, select the dewarp mode of the selected channel. Do not
select channel 1 as this is the default video for the fisheye camera.
A View mode can be assigned to only one channel. For example, if you select
Quad view for Channel 2, you can select any option other than Quad view for
the other channels.
View mode
Quad view
Double panorama
Single panorama
> Basics > Video profile.
Description
Dewarps 4 screens to fit human eyes and display
them simultaneously. Select a screen to move
the view up/down/left/right or zoom in/out.
Dewarps a 360 video and displays it as a
panorama split up/down. The Double panorama
option only appears when Ceiling is selected in
Video & Audio > Video setup > Video rotation >
Camera mounting mode.
Dewarps a video from fisheye camera and
displays it as a wall panorama.
