CL-55 User Manual
Part Number: 1033350-01
Rev Number: 1.7
© Copyright Topcon Positioning Systems, Inc.
All contents in this manual are copyrighted by Topcon Positioning Systems. All rights reserved. The
information contained herein may not be used, accessed, copied, stored, displayed, sold, modified,
published, or distributed, or otherwise reproduced without express written consent from Topcon
Positioning Systems.
Topcon Positioning Systems
shall not be held responsible for possible inaccuracies due to misprints
within this Manual;
Topcon Positioning Systems
reserves the right to modify the Manual and the
devices in appropriate ways to generally improve the product, without prejudice to its performance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CL-55 and is the answer not in the manual?

Questions and answers

Related Manuals for Topcon CL-55

Summary of Contents for Topcon CL-55

  • Page 1 Rev Number: 1.7 © Copyright Topcon Positioning Systems, Inc. All contents in this manual are copyrighted by Topcon Positioning Systems. All rights reserved. The information contained herein may not be used, accessed, copied, stored, displayed, sold, modified, published, or distributed, or otherwise reproduced without express written consent from Topcon Positioning Systems.

  • Page 2: Table Of Contents

    Table of Contents Foreword ......................3 General Information ..................3 Description ...................... 3 CL-55 variants ....................3 Hardware ......................4 Technical Specifications .................. 9 Thermal characteristics................... 9 General environmental characteristics ............10 Electrical characteristics ................10 Installation – setup ..................16 CL-55 installation ..................

  • Page 3: Foreword

    Foreword The CL-55 adds cellular and Wi-Fi capability to the X-Family consoles. It allows access to the new Topcon Agriculture Platform (TAP), which is a cloud based integrated agronomic management platform. It also provides access to the XTEND feature in the Horizon console operating system.

  • Page 4: Hardware

    • CL-55 GLOBAL SDF • CL-55 +RADIO GLOBAL SDF The versions for European market are CL-55 3G and CL-55 LTE EU and the corresponding LITE and +RADIO versions and all GLOBAL models. CL-55 3G BG and all “SDF” are specialized versions for specific customers but identical to the standard at the technical point of view.
  • Page 5 RP-SMA Plastic front cover Satel RTK optional FAKRA Connectrs M8 3 pin Sealing standard blue M8 4 pin LED-Windows Input connector J7 Aluminum carrier & back housting Figure 1 1033350-01 Rev 1.7...
  • Page 6 Figure 2 Figure 3 Cover characteristics Back housing / aluminum carrier • Aluminum die cast • Supporting the venting membrane and the label field • Powder coating with structure, matte, RAL 9005 1033350-01 Rev 1.6...
  • Page 7 Figure 4 Plastic Front Cover • Plastic molded part, visible surfaces etched & polished, no painting • 4 overmolded or assembled LED windows • Supporting the external Satel RTK • Supporting the external WiFi-Antenna • Supporting the external GPS-Connector, 3G-4G Connector, Diversity-Antenna •...
  • Page 8 Figure 5 Mass The total mass of the CL-55 including the battery and the box is 0,3 kg. Mechanical dimensions The CL-55 has the following dimensions: L: 150,3 mm x W: 119,5 mm x H: 32,2 mm 1033350-01 Rev 1.6...

  • Page 9: Technical Specifications

    Figure 6 – CL-55 box mechanical drawing Fastening The fastening method of the CL-55 box will be in accordance with Figure 6 above with two screws or bolts/nuts. The fixation holes diameter is 5,5 mm for M5x30 mm screws/bolts. The head plane for screws has a diameter of 10mm and allows mounting with wrench socket up to 15mm diameter.

  • Page 10: General Environmental Characteristics

    Storage temperature The CL-55 can withstand an indefinite storage in an environment at a temperature range of - 40° C < Ts < +85 °C (battery excluded). The storage limit with battery inside is -20° C < Ts < +65 °C.
  • Page 11 Features Type Notes Bands: ● Five Bands UMTS (WCDMA/FDD) Bands: 800, 850, 900, 1900 and 2100 SARA-U201(U-Blox) Global coverage ● Quad-Band GSM Bands: 850, 900, 1800 and 1900 MHz Approvals: ● 3GPP Rel.7 Compliant Protocol Stack ● RED Data speed: Modem (3G version) ●...
  • Page 12 Features Type Notes LTE (FDD) 3GPP Rel.9 Compliant Protocol Stack, RX-Diversity LARA-R211 (EU) Bands LARA-R280 (AUS) ● FDD 1800 (B3) / 2600 (B7) / 800 (B20) LARA-R220 (JAP) ● Quad-Band LTE: Bands 2, 4, 5, 12 (700, 850, 1700/2100 (AWS) and 1900 Modem Approvals: MHz)
  • Page 13 Features Type Notes Bands ● LTE FDD: 12 (700 MHz) 28 (700 MHz) 13 (700 MHz) 20 (800 MHz) 18 (850 MHz) 19 (850 MHz) 26 (850 MHz) 5 (850 MHz) 8 (900 MHz) 4 (1700 MHz) 3 (1800 MHz) 2 (1900 MHz) 1 (2100 MHz) 7 (2600 MHz) Power Class 3 (23 dBm) ●...
  • Page 14 Features Type Notes 65 MHz tuning range (410-475 MHz and 902-928 MHz) Radio UHF SATELLINE-M3-TR49 Channel Bandwidth:12.5 and 25 kHz RF Output Power: 10-1000 mW ARM Cortex A7 core (see below the iMX Processor iMX6 UL (NXP) family block diagram) 8 GB in Total Flash memory e-MMC...
  • Page 15 TABLE 2 – Functional blocks TABLE 3 – Processor functional blocks 1033350-01 Rev 1.7...

  • Page 16: Installation - Setup

    Plug the CL-55 into the ethernet port on the rear of the console. Figure 7 Secure the CL-55 in a location in the cab that will prevent damage to the unit and will not cause a trip hazard (for example; under the seat).

  • Page 17: Layout Diagrams

    Layout diagrams Figure 8 Figure 9 1033350-01 Rev 1.7...

  • Page 18: Label Product

    Figure 10 Topcon Positioning Systems declines any liability for damages caused by inappropriate installation, misuse or maintenance of the device, including but not limited to damages, losses and expenses due to failure to observe the instructions contained in the present manual, or caused or due to products of other manufacturers.
  • Page 19 1033350-01 Rev 1.7...

  • Page 20: User Interface

    Label position: Figure 11 User interface The LED’s meaning is configurable and default implementation is: • Green is ON for Key-on Status and OFF in Key off • Blue is ON for connectivity (MODEM/Wi-Fi/BT) • Yellow is ON for GPS fix •...

  • Page 21: Product Warranty

    Product warranty Topcon Positioning Systems warrants that the electronic components shall be free of defects in materials and workmanship for a period of two years from the original date of shipment to the dealer. Warranty does not cover damages due to an improper use of the device and/or to the non-compliance with the indications contained in this document.

  • Page 22: Use Restrictions And Warnings (Fcc / Ised)

    1.Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2.Device model CL-55 3G: CONTAINS FCC ID: WR4-CL-55 IC: 6050B-CL55 CONTAINS: FCC ID: XPY1CGM5NNN IC: 8595A-1CGM5NNN CONTAINS: FCC ID: MRBSATEL-TA37 IC: 2422A-SATELTA37 (+RADIO)
  • Page 23 —Consult the dealer or an experienced radio/TV technician for help. 6. Responsible party’s contact located in Canada: Company: Topcon Positioning Systems, Inc. Address: 855- 2 Street SW, Suite 3500, Calgary AB T2P 4J8, Canada Contact Name: Stephen Rosenegger Contact’ s email: srosenegger@topcon.com...

  • Page 24: Rf Radiation Exposure Statement

    `Este produto não é apropriado para uso em ambientes domésticos, pois poderá causar interferências eletromagnéticas que obrigam o usuário a tomar medidas necessárias para minimizar estas interferências` CL-55 +RADIO GLOBAL, CL-55 GLOBAL Para maiores informações, consulte o site da ANATEL www.anatel.gov.br...

  • Page 25: Use Restrictions And Warnings (Australia/New Zealand)

    The radio transceiver module SATEL TR49 is only to be operated at frequencies allocated by local authorities, and without exceeding the given maximum allowed output power ratings. TOPCON Positioning Systems and its distributors are not responsible if +RADIO models are used in unlawful ways.

  • Page 26: Declaration Of Conformity

    Declaration of conformity 1033350-01 Rev 1.6...
  • Page 27 1033350-01 Rev 1.7...
