- Page 1 INSTALLATION, USE AND MAINTENANCE MANUAL HIGH EFFICIENCY HEAT RECOVERY – URC DOMO SMART V Page 1 INSTALLATION, USE AND MAINTENANCE MANUAL...
-
Page 2: Table Of Contents
INDEX GENERALITY ..................................... 3 1.1.1 INTRODUCTION ..................................3 1.1.2 FUNDAMENTAL SAFETY RULES........................3 1.1.3 SYMBOLS .......... -
Page 3: Generality
GENERALITY' INTRODUCTION 1. 1. 1 This manual was conceived with the aim of making the installation and management of your system as simple as possible. By reading and applying the suggestions in this manual, you will be able to obtain the best performance from the product purchased. We would like to thank you for the choice you made with the purchase of our product. -
Page 4: Symbols
Safety related symbols ATTENTION Warns that the operations indicated are important for the safe operation of the machines Only authorized personnel DANGER Warns that failure to comply with the instructions poses a risk of electric shock. Risk of electric shock DANGER Warns that failure to comply with the requirements entails a risk of harm to exposed people. -
Page 5: Warnings
Positioned on the filter inspection panels. These panels can be accessed to check and replace filters (as indicated in this manual). 1.1.4 WARNINGS The installation of the unit must be carried out by qualified and authorized personnel according to the regulations in force in the various countries. If the installation is not carried out it could become a dangerous situation Avoid installing the unit in very humid rooms or with large heat sources. -
Page 6: Range
CONSTRUCTION FEATURES URC DOMO SMART V is a ventilation unit complete with heat recuperator dedicated to air exchange without wasting energy. The unit is particularly suitable for commercial premises or collective residential buildings and in all cases where the nominal flow rates for air exchange do not exceed 400 m3/h. -
Page 7: Main Components Of The Unit
Each version can be completed by the dedicated control (BASIC or EVOLVED, accessory on request) The URC DOMO SMART V units are suitable for internal, ceiling or floor installation and external installation with canopy (additional accessory). Electric coils (external to the structure) and modules with heating or cooling coil (water supply fluid) are available for the URC DOMO SMART V units. -
Page 8: Disassembly And Disposal
to the unit and the indication of its weight are shown on the packaging. The materials that make up the packaging can be of various types such as wood, cardboard or polyethylene (plastic). It is good practice to send them for disposal or recycling through specialized companies to reduce their environmental impact. 1.1.12DISASSEMBLY AND DISPOSAL Do not disassemble or dispose of the product yourself. -
Page 9: Installation
INSTALLATION 2.1.1 INSTALLATION CONDITIONS The unit must be installed according to national and local regulations regulating the use of electrical devices and according to the following indications: install the unit inside residential buildings with an ambient temperature between 0°C and 45°C; avoid areas near sources of heat, steam, flammable and/or explosive gases and particularly dusty areas;... -
Page 10: Anchor Brackets
Wall Mount – Vertical Unit To mount the unit on the wall you will need: Position the unit on the wall so that the left and right sides are at least 50 cm away from the immediately adjacent walls. fix the unit to the wall, using the brackets already installed on the unit and using suitable anchoring systems (plugs, threaded bars, chains...) and check its leveling with the help of a level. -
Page 11: Condensate Drain Connection
2.1.4 CONDENSATE DRAIN CONNECTION Due to the heat recovery system (the hot expelled air is cooled by the incoming air inside the heat exchanger), the humidity contained in the internal air condenses inside the unit. For the correct functioning of the heat recuperator, it is therefore necessary to connect a condensate drain to the plumbing system (drain) of the house to the correct pipe of the unit's drain pipe protruding approximately 6 cm and made of non-toxic material. -
Page 12: Electrical Connections
The units are shown seen from above and with the front inspection part facing downwards. In the V1 and V2 versions always connect the exhaust pipe closest to theEJECTION SIDEand consequently plug the one present on the inlet duct with the appropriate cap. -
Page 13: Adjustments
4.1.2 ADJUSTMENTS Each URC DOMO SMART V unit is equipped with a type of regulation, chosen by the customer. 4.1.3 BASIC ADJUSTMENT (CNV-BPM COMMAND) The URC DOMO SMART unit is equipped with an internal compartment for the electrical connection, with connection terminal block. - Page 14 ADVANCED REGULATION The URC DOMO SMART V unit is equipped with an electronic regulation board, wired inside the unit. The panel is set up with protection fuses for all electrical components (fans, any additional accessories such as 2 or 3-way valves for batteries, electrical resistors, active type probes).
- Page 15 Check the fan speeds, both in parallel (fans at the same speed) and at differentiated speed (one of the 2 fans faster than the other). • Control the switching on and off of the URC DOMO SMART V unit according to time slots. •...
- Page 16 Below is a simplified connection diagram with accessories not connected. REMOTE CONTROL: STANDARD CABLE 10MT Connect N 230V-1F-50Hz power line Connect the 230V-1F-50Hz power supply line CM-DM CO2 SENSOR CN26 TEMPERATURE SA FR. TEMPERATURE OA TEMPERATURE CN25 TEMPERATURE RA WIFI GND - BLUE + 10VDC - RED SIGNAL...
-
Page 17: Accessory Connection Of Water Heating Coil -Bac
Thermo protector with manual reset; • Contactor; • Terminal block; URC DOMO SMART V 20 version URC DOMO SMART V 40 version BE electric battery connection diagram 4.1.6 ACCESSORY CONNECTION OF WATER HEATING COIL -BAC- The water post-heating coils are made up of two galvanized sheet metal flanges and a heat exchange coil made up of copper pipes and aluminum fins. -
Page 18: Maintenance
MAINTENANCE To always guarantee the correct and optimal functioning of the unit, it is necessary to periodically carry out all maintenance operations. 5.1.1 CLEANING OR REPLACING FILTERS To replace the filters or clean them, proceed as follows: remove power to the unit; open the filter covers using the dedicated screws;... -
Page 19: General Cleaning Of The Unit
Attention!Never touch the fins of the exchanger, handle the View of unit for exchanger removal exchanger by holding it only on the closed sides. 5.1.3 GENERAL CLEANING OF UNIT It is advisable to occasionally check and, if necessary, clean the fans, the condensate drain and the internal walls of the unit. - Page 20 Page 20 INSTALLATION, USE AND MAINTENANCE MANUAL...
-
Page 21: Alarms
ALARMS 6.1.1 GENERAL INFORMATION In the event of problems or faults, take note of the model and serial number of the unit you have (found on the identification plate attached to the side of the unit) and contact your installer. Below is the table of unit operating anomalies. -
Page 22: Notes And Maintenance Information
NOTES AND MAINTENANCE INFORMATION NOTE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... - Page 23 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
- Page 24 Air Control Srl Via Colico 10, 20158 Milan (MI) Tel. +39 0245482147 info@aircontrolclima.it www.aircontrolclima.it FOLLOW US ON SOCIAL MEDIA Page 24 INSTALLATION, USE AND MAINTENANCE MANUAL...
