M678
BATTERY OPERATED
HYDRAULIC CADAVER LIFT
CAUTION
• Inspect unit and all components
for any loosening that may have
occurred during shipping •
ATTENTION
Review entire manual before
starting assembly
ATTENTION
All images and Drawing in this manual
may not represent your model.
Refer to your particular project for
exact specifications
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
Technical Users' Manual
Installation and Operating Instructions
CAUTION
DO NOT USE CLEANERS
•
CONTAINING CHLORINE WHEN
CLEANING STAINLESS STEEL
WARNING
Biohazard Label is place on the
equipment signifying the potentially
infectiousness due to the samples
or reagents
•
Advertisement
Table of Contents
Related Manuals for MORTECH M678
Summary of Contents for MORTECH M678
- Page 1 ATTENTION or reagents All images and Drawing in this manual may not represent your model. Refer to your particular project for exact specifications Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com...
-
Page 2: Bloodborne Disease Notice
• Is unit draining properly? WARNING • Are all nuts, bolts, and pins secured in place? It is crucial that any work performed on Mortech If unit has an issue contact Mortech Manufacturing Inc. Manufacturing Inc. manufactured items are carried out... -
Page 3: Installation
M678 Battery Operated Hydraulic Cadaver Lift Installation POWER LIFT STACKER Operating Instructions and Parts Manual ATTENTION: To Ensure proper use of your Power Lift Stacker, read these instructions thoroughly before using. it is important that all personnel, involved with the installation, maintenance or operation of the stacker, read the manual. - Page 4 Operation M678 Battery Operated Hydraulic Cadaver Lift 1. Place power switch to ON position. 4. Frame assembly Check floor lock. Check safety screen and guard. 2. To raise lift, push UP button and hand control pendant. 3. To lower lift, push DOWN button.
- Page 5 M678 Battery Operated Hydraulic Cadaver Lift Parts listing POWER-LIFT STACKER PARTS LIST ITEM DESCRIPTION 56”/60” LIFT 64”/68” LIFT 76”/80” LIFT HYDRAULIC CYLINDER 051166 051164 051163 POWER UNIT 109101 109101 109101 BATTERY 109102 109102 109102 VOLTMETER 109104 109104 109104 BATTERY CABLE (NEG.)
- Page 6 Optional Accessory M678 Battery Operated Hydraulic Cadaver Lift *21A *21B *21C *21E PARTS LISTING 1. HYDRAULIC CYLINDER 2. POWER UNIT 3. BATTERY 4. VOLTMETER 5. BATTERY CABLE (NEG.) 6. BATTERY CABLE (POS.) 7. SOLENOID 8. BATTERY CHARGER (110 V) BATTERY CHARGER (220 V) 9.
- Page 7 M678 Battery Operated Hydraulic Cadaver Lift Parts listing M678 FORK INVERSION LIFT UNHOOK FORKS IN LOWER POSITION FIGURE-B FIGURE-A FORKS IN LOWER UPPER POSITION REATTACH TOP FIRST FIGURE-D FIGURE-C FORK INVERSION INSTRUCTIONS THE FORK ASSEMBLY HAS BEEN DESIGNED TO FIT THE LIFT TWO WAYS.
- Page 8 Optional Accessory M678 Battery Operated Hydraulic Cadaver Lift ROTACASTER ASSEMBLY The Rotacaster is the only multi-directional wheel technology developed primarily as an industrial and commercial floor wheel. The fixed orientation of the main wheel allows forward and reverse movement without fighting a swivel caster offset, while the peripheral rollers facilitate turning, rotational, lateral and diagonal movement.
-
Page 9: Warranty Repairs
M678 Battery Operated Hydraulic Cadaver Lift Troubleshooting TROUBLESHOOTING PROBLEM CHECK SERVICE REQUIRED Stacker does not operate. Power switch is in OFF position. Place in the ON position. (Pump does not run) Battery charger indicator lights. Charge battery until yellow or green light is lit. -
Page 10: Maintenance Record
Maintenance record M678 Battery Operated Hydraulic Cadaver Lift MAINTENANCE RECORD Date... -
Page 11: Training Record
M678 Battery Operated Hydraulic Cadaver Lift Training record TRAINING RECORD Date... -
Page 12: Warranty
Information in this Manual is subject to change without notice Labor is not warranted. Items not manufactured by Mortech and does not represent a commitment on the part of Mortech Manufacturing. Inc. will receive the manufacturer’s warranty. Manufacturing. Inc. Mortech Manufacturing. Inc. assumes no responsibility for any inaccuracies that may be contained in this Manual.
