Bredal K Series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN
MANUAL
K SERIES
BASIC
www.bredal.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K Series and is the answer not in the manual?

Questions and answers

Related Manuals for Bredal K Series

Summary of Contents for Bredal K Series

  • Page 1 MANUAL K SERIES BASIC www.bredal.com...
  • Page 2 Errors and omissions excepted. The terms and conditions of sale and delivery can be found on www.bredal.com/en/betingelser...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Foreword                                                                                                                                         5 Safety                                                                                                                                             6 Traffic safety                                                                                                                                    6 Overview of hydraulic connections                                                                                                          8...
  • Page 4 Gears                                                                                                                                            60 RT gear (computer-controlled spreaders)                                                                                                       60 KB3 gear, landwheel drive and reversing gear                                                                                                  60 Gearbox oil volume:                                                                                                                            61...

  • Page 5: Foreword

    The latest settings for the most common types of available fertilizer can be downloaded at any time from Bredal’s website. It is advisable to always do a spreading test using the type of fertilizer to be spread to test the settings recommended by Bredal.

  • Page 6: Safety

    SAFETY The safety distance from the spreading discs is at least 30 meters when these are rotating. If people or animals are within this distance, the tractor’s PTO must be disengaged. Never operate the headland gear or adjust the spreader while the spreading discs are rotating. When loading the spreader, keep foreign objects, such as stones, etc., from getting in the machine’s hopper, as they can cause damage and be very hazardous for the surroundings.
  • Page 7 CONNECTING THE SPREADER When connecting the spreader to the tractor, it is important that it stands horizontally or slightly forward to obtain the best possible spreading results. It is possible to slightly adjust the height by moving the hitch in its bolt holes on the spreader’s undercarriage. The light plug is inserted in the tractor’s light outlet.

  • Page 8: Overview Of Hydraulic Connections

    OVERVIEW OF HYDRAULIC CONNECTIONS Belt (+ any external hydraulic functions) Constant flow, 50–60 l/min. Pressure (1 red band) Return flow (2 red bands) Headland gear Engage (1 blue band) Disengage (2 blue bands) Jacks Cover, hydraulic Open (2 green bands) Close (2 black bands) Brakes, hydraulic Brakes, air...
  • Page 9 Steering axle Constant flow, 30-40 l/min. Pressure (1 yellow band) Return flow (2 yellow bands) HYDRAULIC SPREAD UNIT, OIL FROM TRACTOR Floor belt + discs, forward motion, two Constant flow, 130 l/min. total Return flow (1” coupling) “return to open tank” Drain from oil motor “return to open tank”...
  • Page 10 OVERVIEW OF HYDRAULIC CONNECTIONS Landwheel drive (spreader with mechanical landwheel drive) Green Belt-load reducer Yellow/blue Bogie lock 1/2 ball valve K-XESC External hydraulic functions and section control Constant flow, 70 l/min. Pressure (1 red with arrow) Return (2 red with arrow)

  • Page 12: Driving Dependent Belt Drive 'Kb3' (Spreaders With Mechanical Landwheel Drive)                                               12

    DRIVING DEPENDENT BELT DRIVE, KB3 (SPREADERS WITH MECHANICAL LANDWHEEL DRIVE) To connect, attach the spreader’s hydraulic hose to the tractor’s hydraulic outlet. Engaging and disengaging the application will now be done using the tractor’s hydraulic system. A pilot-operated check valve is installed. This prevents the application wheel from being accidentally engaged if there is a leak in the tractor’s hydraulic system.

  • Page 13: Spreading

    > Application principle Bredal K spreaders are configured with forced application, comprising an adjustable shutter (application door) and a wide belt in the bottom of the container that forces the application of fertilizer. The application rate (belt speed) is driving dependent and the belt on the standard model is driven by an application wheel that is interconnected with the spreader wheel.
  • Page 14 HOW TO USE THE APPLICATION CHART (FOR SPREADERS WITH MECHANICAL LANDWHEEL DRIVE) To use the application chart, you must know the preferred volume in terms of kg/ha as well as the fertilizer’s bulk density in terms of kg/liter. After this, find the setting based on the instructions below. To determine the setting, first convert the volume from kg/ha to liter/ha by dividing kg/ha by the fertilizer’s bulk density (calibration kit).

  • Page 15: Application Chart (For Mechanical Landwheel Drive)                                                                                   15

    APPLICATION CHART (FOR MECHANICAL LANDWHEEL DRIVE) 9 METERS 10 METERS 12 METERS SCALE GEAR ½ GEAR 1 GEAR 2 SCALE GEAR ½ GEAR 1 GEAR 2 SCALE GEAR ½ GEAR 1 GEAR 2 1077 1363 1230 1025 1636 1230 1476 1909 1722 1435...
  • Page 16 15 METERS 16 METERS 18 METERS SCALE GEAR ½ GEAR 1 GEAR 2 SCALE GEAR ½ GEAR 1 GEAR 2 SCALE GEAR ½ GEAR 1 GEAR 2 1148 1076 1312 1230 1094 1476 1384 1231 1640 1538 1367 1804 1691 1504 1008 1968...
  • Page 17 20 METERS 24 METERS 28 METERS SCALE GEAR ½ GEAR 1 GEAR 2 SCALE GEAR ½ GEAR 1 GEAR 2 SCALE GEAR ½ GEAR 1 GEAR 2 1107 1230 1025 1353 1128 1476 1230 1054 1599 1333 1140 1722 1435 1230 1845 1538...
  • Page 18 30 METERS 32 METERS 36 METERS SCALE GEAR ½ GEAR 1 GEAR 2 SCALE GEAR ½ GEAR 1 GEAR 2 SCALE GEAR ½ GEAR 1 GEAR 2 1066 1148 1076 1230 1153 1024 1312 1230 1092 1394 1307 1161 = AVOID THIS APPLICATION RANGE...

  • Page 20: Spreading Of Lime

    SPREADING OF LIME > mounting of lime equipment For spreading lime, attach the K discs (spreading discs for lime) and the lime downchute. Adjust the spread-unit position to setting 110 (see the next section ‘Lime spreading adjustment’). Disassemble the fertilizer distributor and screen before spreading lime. Remember that spreading discs used for spreading lime should not be used to spread fertilizer.

  • Page 21: Spreading With Reversed Spread Unit

    IF EXCESSIVE LIME IS DEPOSITED BETWEEN THE WHEEL TRACKS Adjust the spread unit away from the tractor (increase the setting). Adjust 10–20 scale steps at a time. IF EXCESS LIME IS DEPOSITED BEHIND THE SPREADER Adjust the spread unit towards the tractor (decrease the setting). Adjust 10-20 scale steps at a time.
  • Page 22 ATTACHING FERTILIZER EQUIPMENT FOR A DISCS 1. Disassemble the K discs and lime downchute. 2. Attach the fertilizer downchute. Center the downchute on the rubber belt. The distance (A=B) must be the same from the right to the left side. Measure the distance from the side element (A) to the center of the downchute (B).
  • Page 23 6. Adjust the guide plate until the distance from the guide plate to the center bolt is 40–45 mm. Do this by loosening the two bolts and then adjusting the guide plate until it touches the stainless steel top. Make sure that it is possible for the guide plates to tilt up without hitting the stainless steel top disc.

  • Page 24: Spreading Of Fertilizer

    > settings for various types of fertilizer The most precise settings are obtained by using the spreading settings for the type of fertilizer to be used from Bredal’s website www.bredal.com. It is advisable to use these spread charts wherever possible.

  • Page 25: Recommended Universal Settings

    > recommended universal settings If you are unable to find the fertilizer to be used or similar on the website, as an alternative, you can use the recommended universal settings for ordinary NPK, NS, PK and N fertilizers. Spread charts with universal settings for field spreading are found on the following pages. For spreading special fertilizers such as potash, granular urea, ammonium sulfate and N34, the downchute setting must typically be 1–3 scale steps higher than the recommended universal setting.

  • Page 26: Spreading With K Discs With Top Disc (12-24 Meters)

    > spreading with K discs with a top disc (12–24 meters) K discs with a top disc (12–24 meters) can be used instead of A discs, however. Use the lime downchute for spreading of fertilizer with K discs. If K discs are used for to spread fertilizer, it is advisable to have two sets of spreading discs if the spreader is also used for spreading lime: one set for spreading lime and one set for spreading fertilizer.

  • Page 28: Headland Spreading

    Wherever possible, use the rpm and downchute settings indicated on the spread chart on Bredal’s website or use the recommended universal setting shown in the tables below.

  • Page 29: Recommended Universal Setting For Headland Spreading

    > recommended universal setting for headland spreading If you are unable to find the fertilizer to be used or similar on the website, as an alternative, you can use the recommended universal set- tings for ordinary NPK, NS, PK and N fertilizers. Spread charts with universal settings for headland spreading are found on the following pages. For spreading special fertilizers such as potash, granular urea, ammonium sulfate and N34, the downchute setting must typically be 1–3 scale steps higher than the recommended universal setting.
  • Page 30 RECOMMENDED SETTING FOR HEADLAND SPREADING WITH HYDRAULIC SPREAD UNIT (WITHOUT GUIDE PLATES) Downchute, Disc rpm Border side left and right Field side 12 M 15 M 16 M 18 M 20 M 24 M 28 M 30 M 32 M 36 M 1000...

  • Page 32: Fertilizer Quality

    Repeat this with several granules, big and small, and then calculate the mean crushing strength. Particle size can be measured using Bredal’s sieve shaker. Fill the space above the biggest-meshed sieve, attach the lid and shake until the distribution of granules re- mains constant.

  • Page 33: Maximum Capacity Per Minute

    MAXIMUM CAPACITY PER MINUTE Lime (K discs) > To avoid overloading the transmission, do not let the application rate exceed the following: • SPC 4500-1 spread unit (1 belt): 1200 kg/min. at 540 rpm • SPC 4500-2 spread unit (2 belts): 1600 kg/min. at 540 RPM •...

  • Page 34: Fertilizer Spreading Test And Spreading Adjustment                                                                                   34

    FERTILIZER SPREADING TEST AND SPREADING ADJUSTMENT A spreading test should always be done in the field to ensure satisfactory spreading patterns. Consider the following factors when conducting a fertilizer spreading test: • Perform the test in dry conditions (field/implement). • Perform the test in a field covered with a healthy crop: approx.

  • Page 35: Fertilizer Spreading Test: Headland Spreading

    IF EXCESS FERTILIZER IS DEPOSITED BETWEEN THE WHEEL TRACKS • Set the downchute position to a lower value. Preferably set it 2 steps lower. If a subsequent test shows that two steps was too much, the difference between the two tests will indicate how much the scale needs to be moved back. IF EXCESS FERTILIZER IS DEPOSITED BEHIND THE SPREADER •...

  • Page 36: Engaging/Disengaging In Headland (Manually)                                                                                          36

    ENGAGING/DISENGAGING IN HEADLAND (MANUALLY) Engage and disengage the spreading in the headland at the right time. General rule: When the discs pass the headland’s tracks, disengage them (for working widths above 24 meters, slightly before this, however). Re-engage when the discs are one working width from the headland’s tracks.

  • Page 37: Late Application With Late Application Equipment                                                                                      37

    -150 Example: A 30-meter working width will be used. According to the settings on Bredal’s website, the PTO rpm should be set at 1000 rpm and the down- chute position at 5.0. According to the table under 30 meters, subtract 150 rpm from 1000 rpm, so that the spreader operates at 850 rpm.

  • Page 38: Driving With A Bogie

    DRIVING WITH A BOGIE For trailers with a bogie, the bogie MUST be locked at all times during road transport, because otherwise there is a risk that the vehicle will begin to sway and cause an accident. Also, the bogie MUST always be locked when driving in reverse as otherwise there is a risk of damaging the lock cylinder.

  • Page 39: Hybrid Power Unit

    HYBRID POWER UNIT Spreaders with hydraulic spread units are available with a PTO-driven hydraulic pump unit. The pump unit is a separate system whose sole purpose is to drive the discs. OPERATION PTO working range: 800–1000 rpm, depending on the disc rpm preferred. Check the following daily: The oil must be visible in the sight glass.

  • Page 40: Troubleshooting

    TROUBLESHOOTING Satisfactory spreading is contingent on the spread unit being clean and in working order and the spreading vanes being correctly mounted on the spreading discs (see ‘Other maintenance and cleaning’). General adjustment of the spreading pattern is found in ‘Spreading test and adjustment’. >...

  • Page 41: Incorrect Application Rate (Computer-Controlled Spreaders)

    The application rate is 6 % too low. Change the flow factor from 1.00 to 1.06. The application rate is 3 % too high. Change the flow factor from 1.00 to 0.97. OTHER FAULTS ON COMPUTER-CONTROLLED SPREADERS: See the ‘K Series ISOBUS’ manual.

  • Page 42: Calibrating The Spread-Unit Position                                                                                                      42

    CALIBRATING THE SPREAD-UNIT POSITION To verify whether the scale setting on a K spreader is correct, use the ‘calibration figure’ (scale 120). The ‘calibration figure’ must follow the plate for the downchute as shown in the center photo, and at the same time it must touch the disc and the edge of the cone beside the disc center.

  • Page 43: Floor Belt Adjustment

    FLOOR BELT ADJUSTMENT Normally, the belt does not need to be tightened unless it slips on the rollers and cannot keep up. In many cases, this may be necessary after the first few days of operation, as the belt stretches a little when new. If the belt needs to be tightened, tighten the bolts on both sides of the belt one revolution at a time until the belt moves with the rollers.

  • Page 44: Adjusting Scraper And Downchute                                                                                                         44

    ADJUSTING SCRAPER AND DOWNCHUTE A nylon strip is attached to the rear side of the plate for the downchute which scrapes the belt clean. Adjust the plate for the downchute so the scraper fits snugly against the belt. Do this by loosening the two bolts (A) on each side. It must not be possible for fertilizer to flow between the nylon strip and the belt.

  • Page 45: Centering The Spread Unit

    CENTERING THE SPREAD UNIT The spread unit must be centered. Set the downchute at the same scale value on each side. Make a diagonal measurement from the bolt head (A) on the cone to the bottom tip of the downchute on the opposite side (B). This dimension must be identical when measuring from the right and from the left.

  • Page 46: Checking The Rear Door And Its Basic Setting                                                                                            46

    CHECKING THE REAR DOOR AND ITS BASIC SETTING The basic setting of the rear door must be correct in order for the spreader to apply correctly. It is possible to check the setting by setting the scale at 40 and placing two 40 mm square pipes on the belt underneath the door. If the setting is incorrect, adjust the door on its tension rod. Set the rear door's scale at 40 Place two square pipes underneath the door on each side.

  • Page 48: Lubrication Points

    LUBRICATION POINTS The different lubrication points on the implement are shown below. The number of operating hours for each lubricating interval is specified at each lubricating point. > Every 50 hours Flange bearing and 6-grooved axle towards the tractor. Disassemble the PTO shaft towards the tractor so that the 6-grooved axle can be lubricated.
  • Page 49 Flange bearing at the rear axle. PTO shaft under the spreader: disassemble the PTO shaft and lubricate the 6-grooved ends with grease. Input shaft on the spread unit.

  • Page 50: Every 100 Hours

    LUBRICATION POINTS > Every 100 hours Front roller bearings (two lubrication points): it can be necessary to run the belt to access the grease nipple. The belt’s guide rollers (two lubrication points). The belt’s snap rollers (two lubrication points). Sealing on the outside of the gearbox (computer-controlled spreaders).
  • Page 51 Flange bearings for the floor belt’s powered rollers. Right and left top, just below the discs. Rear-door handle: lubricate the bushing.
  • Page 52 LUBRICATION POINTS > Every 100 hours, continued Mechanical landwheel drive: there are a total of 7 lubrication points on the mechanical landwheel drive.

  • Page 54: Every 200 Hours

    LUBRICATION POINTS > Every 200 hours Tightening device on the spread unit. Tow bar/ball hitch Seals by the rear axle’s brake toggles and drums.
  • Page 55 Weight cells front and rear. Hinges and ends of cylinder for hydraulic hopper extension. Manual jacks.

  • Page 56: Maintenance And Lubrication Of Spread Unit (Spc4500-1)                                                                            56

    MAINTENANCE AND LUBRICATION OF SPREAD UNIT (SPC4500-1) It is important to keep the spread unit properly maintained/lubricated. There is a general time interval for how often the spread unit should be lubricated. Otherwise, it is important to lubricate the headland gear, etc., especially after washing the spreader and before putting the spreader into storage for winter.

  • Page 57: Lubrication And Adjustment Of Headland Gear

    > Lubrication and adjustment of headland gear The headland gear’s claw clutch is protected by a plastic tube perforated by a 3 mm hole. Lubricate the clutch before the season begins and after every 100 operating hours by spraying a thin oil or rustproofing oil through the hole.Always lubricate if the inside of the spread unit has been washed and before putting the spreader into storage for the winter.

  • Page 58: V-Belt Tightness

    MAINTENANCE AND LUBRICATION OF SPREAD UNIT (SPC4500-2) It is important to keep the spread unit properly maintained/lubricated. There is a general time interval for how often the spread unit should be lubricated. Otherwise, it is important to lubricate the headland gear, etc., especially after washing the spreader and before putting the spreader into storage for winter.

  • Page 59: Lubrication

    > Lubrication There are two lubrication points on the inside of the spread unit. These must be lubricated every 200 operating hours. Always lubricate the spread unit after every washing of its insides and thoroughly spray the headland gear with oil. Spray the headland gear with oil on the shaft where the claw clutch slides up and down.

  • Page 60: Gears

    GEARS > RT gear (computer-controlled spreaders) The floor belt is operated by a gearbox. The oil must be visible in the sight glass. For ordinary operation, it is not necessary to replace or replenish the gear oil. A small wing screw is attached to the top of the gearbox for manual floor belt op- eration.

  • Page 61: Gearbox Oil Volume

    Landwheel drive: Reduction gear (1000/540): > Gearbox oil volume Gear type Oil volume, liters RT 300 (K45/K65) 3.5 l RT 500 (K85/K105) 5.5 l RT 800 (K135/K165) 8.5 l 1.5 l Landwheel drive bracket 0.7 l Reduction gear (1000/540) 0.7 l The spreader is filled with Castrol SP 150 gear oil ex works, but a similar gear oil of a similar make can also be used.

  • Page 62: Other Maintenance And Cleaning                                                                                                          62

    OTHER MAINTENANCE AND CLEANING > Oil filter (computer-controlled spreaders) The spreader’s hydraulic system for operating the belts is fitted with an oil filter. The filter’s replacement interval largely depends on the operating conditions, and the meticulousness with which the tractor’s hydraulic system is kept clean, but it is advisable to replace the filter every two to four years.

  • Page 64: Replacing V-Belts On Spc4500-1 With Headland Gear                                                                                 64

    REPLACING V-BELTS ON SPC4500-1 WITH HEADLAND GEAR Completely disassemble the three plastic bearings for the headland gear’s shifter shaft. If the headland gear is hydraulically shifted, screw off the hydraulic cylinder from the shifter shaft. The shifter shaft with shifter fork is now clear and can be removed.
  • Page 65 Disassemble the bottom two and then the upper two V-belts on the headland gear. Disassemble the spring for the belt tightener. Take off the belt tightener and remove the belt. The spread unit is now ready to be fitted with a new belt.
  • Page 66 First wind the belt around pulley 1. Twist the top of the belt on pulley 1 and lead it behind pulley 2. Twist the belt half a turn. Wind the belt around the pulley on the headland gear.
  • Page 67 Insert the belt tighteners into the loose ends of the belt. Then attach the spring to the belt tightener. Tighten the spring until it has a length of 91–93 mm. Attach the upper two V-belts to the headland gear.
  • Page 68 Attach the bottom two V-belts to the headland gear. Use a screw clamp to tighten the belts for the headland gear. Attach the screw for the belt tightener with a spring and tighten until the spring length is 43–45 mm. Attach the shifter shaft with shifter fork.
  • Page 69 Attach the spring to the spring guide and insert the guide into the hole. Loosely mount the plastic bearing furthest to the right. Mount the last two plastic bearings. If necessary, use a crowbar or similar to move the shifter shaft into place. Tighten all plastic bearings.
  • Page 70 REPLACING V-BELTS ON SPC4500-2 WITH HEADLAND GEAR Disassemble the spring and belt tightener. Disassemble the hydraulic cylinder or the handle for mechanical headland changeover.
  • Page 71 Disassemble the closing plate Disassemble the tighteners. Disassemble the spacer tubes under the headland gear. It is now possible to remove the bottommost belts.
  • Page 72 Remove the cotter pin and disassemble the shifter shaft. Rotate the shifting fork and disassemble.
  • Page 73 It is now possible to remove the top belts. Feed the new belts around the belt disc on the input axle. Twist the top section of the belts 90 degrees around belt disc 2 so that the inner- most belt is on top. Twist the belts 180 degrees.
  • Page 74 Guide the belts under the headland gear and around the top belt discs on the head- land gear. Guide the 2 small belts under the headland gear. Attach the shifting fork and rotate it into position.
  • Page 75 Attach the spacing tubes for the headland gear Attach the shifter shaft and insert the cotter pin. Attach the closing plate. Attach the hydraulic cylinder or the handle for mechanical headland changeover.
  • Page 76 Attach the tightener. Attach the belts to the headland gear. Insert the belt tightener into the loose ends of the belts. Tighten the belt tightener, and then loosen it by a half to a full turn, so the belt tightener can slide freely back and forth.
  • Page 77 Attach the spring for the belt tightener until it has a length of 91–93 mm.
  • Page 78 REPLACING V-BELTS ON SPC4500-1/4500-2 WITHOUT HEADLAND GEAR Disassemble the belt tightener (belt disc 4 with fittings) before starting to attach the belt. On spreaders with two belts, attach both of them at the same time. 1. Mound the belt on disc 1. The end must face right. 2.

  • Page 79: Tire-Pressure Table

    750/60 – 30.5 BKT/TRELLEBORG 2.0 BAR 750/60 R30.5 TRELLEBORG TWIN RADIAL 4.0 BAR 800/65 R32 ALLIANCE 360 3.6 BAR The table values are recommended tire pressures at maximum load and 40 km/h. In case of doubt, contact Bredal or the tire supplier.
  • Page 84 BREDAL is located in Vejle, Denmark, where it has state-of-the-art production facilities with the latest technologies ensuring the production of top-quality machines. SIMPLE PRECISE RELIABLE Bredal A/S . Nimvej 1 . 7120 Vejle . Denmark . Tel.: (+45) 7589 5177 . info@bredal.com . www.bredal.com...
