  • Page 1 F8/F10 OPERATING MANUAL SIMPLE PRECISE RELIABLE www.bredal.com...
  • Page 2 Volume per impulse ....Speed sensor: Impulses / 100 meter....Misprints/typos might appear. General sales and delivery terms and conditions can be found at www.bredal.com/en/betingelser...

  • Page 3: Table Of Contents

    Connecting the spreader First time installation / set-up of Müller terminal First time set-up on existing terminal in the tractor Description of Bredal program icons Start-up of the terminal Language, contrast, light and measuring units Calibration of spreader’s speed sensor Configurable alarms Encoding menu for application rate, working width, density etc.
  • Page 4 Adjustment of belt Nylon scraper Checking and basic settings for the rear door Lubrication points Every 50 hours Every 100 hours Every 200 hours Maintenance and lubrication of spreading unit Tightness of the belts Headland device function Lubrication Gear for operating the belts Tire Pressure Table...

  • Page 5: Introduction

    This operating manual contains instructions and guidance for operating the machine and setting it for spreading of common types of fertilizer. Since the fertilizer quality can variate quite a lot from year to year and from batch to batch, it is recommended that there shall always be per- formed a spreading test, if there is a slightest doubt about characteristics of the given fertilizer type in relation to its ability to spread on the required working width performing a good result. The newest settings for most common types of fertilizer can be downloaded from Bredals homepage. It is recommended that there always shall be undertaken a spreading test with the type of fertilizer that has to be spread. The spreading test shall be performed with that type of fertilizer that shall be spread in order to try out the required settings by Bredal. It is the operator´s responsibility to make sure that the machine is set correctly and works like it should, so that acceptable spreading pattern could be achieved. Bredal takes no responsibility for spreading errors. Isobus terminal in the tractor and its software: The user surface looks different every time the machine gets connected to another ISOBUS terminal. The reason for this is that terminals have different solutions. Some functions of the spreader depend on the type of software the terminal has. The functions are dependant on that the terminal shall contain the necessary software. In order to perform headland spreading it is necessary to make sure that the terminal contains section control program along with track following program. If the application rating shall be based on the field map, the terminal must also include the software which is able to operate field maps. When the spreader gets connected to the tractor, the spreader’s jobcomputer starts to exchange data with the tractor’s terminal, and only the functions supported by the tractor’s terminal would be active. In case the terminal...

  • Page 6: Security Regulations

    SECURITY REGULATIONS The secure distance from the spreader’s discs is minimum 30 meters when they are in operation. In case there are people or animals within this distance, the tractor’s PTO shall be at once disconnected. Never try to service headland device or make setting adjustments on the spreader when the discs are in operation. Under loading avoid the situation when foreign objects like stone or similar come in contact with the machine’s hopper, as they might cause damage and inflict great danger for the surroundings.

  • Page 7: Connecting The Spreader

    CONNECTING THE SPREADER When the spreader is connected to the tractor, it is important that it is positioned horizontally, or slightly hunched, in order to reach the best possible spreading results. It is possible to adjust a little bit the height by moving the tension in the bolt holes on the spreader frame. The hydraulic hoses for operating the dosing shall be connected to a double-acting tractor outlet. 50-60 l/min shall be used. The hydraulic hoses for operating headland spreading shall be connected to a double-acting headland gear.

  • Page 8: First Time Installation / Set-Up Of Müller Terminal

    FIRST TIME INSTALLATION / SET-UP OF MÜLLER TERMINAL In case an ISOBUS terminal from Müller is delivered together with the machine, some basic set-up shall be done before applying the function of section control. For montaging the tractor assembly kit with GPS antenna, you get directed over to instructions provided by Müller, where it is possible to refer to Müller instructions for operating the programs not relating to spreader’s operation, such as Track-leader, Field-nav, Farmpilot, or other software that can be bought additionally for Müller terminal. The basic set-up of GPS receiver, its activation and the basic encoding for GPS antenna location can be equally found in montage and operating instructions from Müller. When the terminal, tractor assembly kit and GPS antenna are mounted, the socket from the spreader’s ISOBUS is connected, the basic set-up encoding is finished and the spreader can be set into action, press the button for about 3 seconds.

  • Page 9: First Time Set-Up On Existing Terminal In The Tractor

    The encodings shall be used for the spreader to start and stop the dosing at the right time, when turning at headland. Bredal program already contains this information, but not every tractor terminal uploads this data from the spreader when connected. Some terminals apply the encodings correctly. In some cases the tractor´s terminal applies only one or two of the encoded distances.

  • Page 10: Description Of Bredal Program Icons

    DESCRIPTION OF BREDAL PROGRAM ICONS In the following passage you can find a description of Bredal program icons, the positioning of icons can variate on different terminals. The icon´s meaning/function: Home, go back to starting page. Work, go to operating page. Start / stop button, starts and stops the dosing. Menu, go to the chosen menu. Return, go back to the previous menu.
  • Page 11 Manual closing of the section on the left side. Manual opening of the section on the left side. Increase output amount by 5%. Reduce output amount by 5%. Return to the original encoded output amount. Warning / Alarm Go to the next page. Delete the entry.

  • Page 12: Start-Up Of The Terminal

    START-UP OF THE TERMINAL Press on/off button on the terminal. When the terminal starts, the spreader´s program is loaded automatically, the popping-up warning ”Actuator closing” shall be confirmed for. Click to accept. Then the start-up screen picture (Home) is shown. Here you can see the entered application rate, working width etc. In case the start-up screenshot can not be seen, click on the left side of the screen.

  • Page 13: Language, Contrast, Light And Measuring Units

    LANGUAGE, CONTRAST, LIGHT AND MEASURING UNITS Click to change the settings: Click “Terminal”. Select e.g. “Language” by scrolling down. Click at the tab page “Language”. Choose from the list Click...

  • Page 14: Calibration Of Spreader's Speed Sensor

    CALIBRATION OF SPREADER’S SPEED SENSOR Pay some attention to that it is possible to choose other speed sources than the spreader’s speed sensor, e.g. the speed via GPS signal, see VT instruction manual for the terminal. Click menu button at Home screen picture. Select “Machine”...
  • Page 15 Click to start calibration. The number of impulses can be directly introduced into the entry line in settings, if the amount is known. Move 100 meter forward, the impulses are calculated. Click to save the calculated amount of impulses.

  • Page 16: Configurable Alarms

    CONFIGURABLE ALARMS It is possible to set some individual alarms, so that there comes a warning e.g when the hopper is almost empty. The following alarms can be configurated: • Kg/left in the hopper • PTO speed • CAN speed timeout point Click button at Home screen picture. Select “Machine”...
  • Page 17 In this example alarm is set for kg/left at ”On”. Click to accept. The entry field below is meant for introducing the residual quantity kg/left at which the alarm shall go off. Click to accept.

  • Page 18: Encoding Menu For Application Rate, Working Width, Density Etc

    ENCODING MENU FOR APPLICATION RATE, WORKING WIDTH, DENSITY ETC. The parametres that shall be encoded before the start of spreading are the following: • Kg/ha. • Working width • Rear door scale position • Downchute position • Density • Flow factor >...

  • Page 19: Encoding Working Width

    > Encoding working width Click the entry space “Working width” to change the value. Encode the required working width. Complete by clicking > Encoding scale position Under the line Scale Position the settings for the rear door opening shall be encoded. It is recommended to drive with a scale setting on 60. If bigger amounts of material are dosed, the scale settings are increased up to 80 or 100. If small amounts are to be dosed, the settings are reduced to 40.

  • Page 20: Encoding Downchute Positioning

    Manual, the required downchute position shall be encoded. • Automatic without flow control, similar to automatic, with the only difference that the position of downchutes isn’t changed at different flow patterns. When the working width is changed, downchute control always goes back to automatic! Optimized settings for the most fertilizer types can be downloaded at Bredal homepage, it is recommended to apply manual control of down- chutes position, and encode that position of downchute that fits for the fertilizer type to be spread. Click the entry space by “Downchute control” for selecting. Select the required setting. Complete by clicking When introduction of manual settings is completed, settings for downchute positioning...

  • Page 21: Encoding Density

    Introduce the required downchute position for spreading in the field. Complete by clicking or select to get to the next page, where downchute position for headland spreading can be encoded. Click the entry space by “Left” or “Right” to change the downchute position for head- land spreading. Encode the required downchute position for headland spreading. Complete by clicking Remember to encode downchute position for both left and right side, if both sides shall be adjusted. > Encoding density Click the entry space “Density”, to change the value.

  • Page 22: Encoding Flow Factor

    > Encoding flow factor Basically you shall always start with flow factor at 1,0. If the spreader is equipped with weighing cells, the flow factor is calculated continuously under spreading, the last calculated flow factor is displayed in the entry space under flow factor. Click the entry space by “Flow factor” to change the value. Encode the required flow factor. Complete by clicking...

  • Page 24: Operating Picture

    OPERATING PICTURE Operating picture is the screen picture shown during spreading, where application rate can be started and stopped, and different data is handed on to the operator. Click to go to operating picture. 1. Task Controler, when TC is shown, the Task Controler program is activated. 2. Shows how many kg there has been spread taking the data from the active counter. 3.
  • Page 25 When headland spreading is activated: Green = minimum (environmental), none or very little fertilizer is spread over the edge of the field. Yellow = medium, 40-50 % application rate at headland, some fertilizer is spread over the edge of the field. Red = maximum, full application rate all the way out to headland, a considerable amount of fertilizer is spread over the edge of the field. CAUTION! If settings from Bredal homepage are downloaded like recommended, PTO revolutions from there shall be applied, and not the abovestanding colour markings. 9. Starts and stops the application rate, there shall be circulation of oil for the belts before the dosing process starts. Button nr. 12 has the same function. 10. Home button.

  • Page 26: User Setup Of Operating Picture

    USER SETUP OF OPREATING PICTURE Here it is possible to adjust operating picture to user needs. The following can be changed: • Preferred screen (In case there are several terminals in the tractor) • Manual operation of sections (icons for operating sections are visible at operating picture) •...

  • Page 28: Express Unloading

    EXPRESS UNLOADING Click in Home menu. Click to start emptying. It is possible to change the conveyor belt speed by pressing onto revolutions and encoding another value.

  • Page 29: Weight Menu

    WEIGHT MENU Click symbol in Home menu. In this menu the encoded dosing is compared with the actual dosing, if the spreader has weighing cells. When dynamic weighing is activated, new flow factor is calculated automatically all the time. Dynamic weighing is activated when the machine is delivered from the factory, but can be disconnected if required. If the dynamic weighing is disconnected, weighing can still be done, but flow factor is no longer calculated and changed automatically. The active flow factor is shown, and the next oncomiing correction of flow factor (corrected flow factor) can be read off. When the spreader is being filled it is registered automatically, and a new calculation is started. A new calibration can be launched by clicking .

  • Page 30: Counters

    COUNTERS There are 10 trip counters in Bredal program part, that can be used to count area, distance, amount and time for one task. If the tractor`s ter- minal has an active task controller, it is the one that counts area, amount etc. The 10 trip counters in Bredal program part are deactivated, and in the menu under counters there can only be seen trip counter 11.
  • Page 31 The active trip counter is shown at the top of the operating screen, the counted kg and calculated area are shown as well. If TC is indicated on the screen, the tractor`s terminal task controller is active, and the counted values shown are taken from there. In counters menu there can be further chosen among Partial, Total and Export trip counters.

  • Page 32: Setting Up Machine Parametres

    SETTING UP MACHINE PARAMETRES In machine parametre menu it is possible to change the following parametres. • Application rate step : Step size in % • Speed source • Simulated speed • Mashine on/off sensor : Choose between start/stop button on the screen or external contact. • Headland left/right compensation: Automatic amount reduction by activating headland spreading • Use dynamic weighing : Connecting and disconnecting dynamic weighing. Click the button at Home screen picture. Select “Machine encoding” Select “Encoding” Machine parametres menu: Here different parametres can be changed, see expla- nation for each parametre below.
  • Page 33 Headland left/right: It is possible to encode reduction in output amount, when head- land spreading is activated. In case no reduction is required, there shall be standing 0 in both fields. Remember that there must be placed a minus sign in front of the number to reduce the amount, in case it is overseen, the output amount will be increased when headland spreading is activated. When reduction is encoded, it is shown in the operatng picture when headland sprea- ding is activated.

  • Page 34: Machine Calibration

    MACHINE CALIBRATION In machine calibration menu there shall be undertaken some basic encodings to ensure that the spreader operates in the correct way. All va- lues are introduced at the plant, though in some cases it might be necessary to introduce some changes to several parametres. The following encodings/calibrations can be performed in the menu: •...

  • Page 35: Hydraulic System

    > Hydraulic system To ensure that the conveyor belts are regulated in the best possible way it is important to perform a calibration of hydraulic system, by using the tractor that shall be pulling the spreader. The spreader can be functioning even though it has not been calibrated, but it will take longer time to achieve the correct application rate when the spreader gets started, as well as on introduction of changes into the output amount.

  • Page 36: Encoding Speed Sensor

    > Encoding speed sensor A certain value is already encoded at the plant, but it is recommended to control that the spreader´s forward speed is shown correctly, combine if possible the forward speed of the spreader with the tractor’s forward speed. If the spreader’s forward speed is not correct, calibration shall be performed. It is also possible to choose another speed source than the spreader´s, e.g. GPS speed, in case tractor terminal is connected to a GPS antenna. For changing the speed source see page 32. Select “Implement speed sensor” to get into the menu.

  • Page 37: Taring Of Weighing Cells

    > Taring of weighing cells If Weight number is not standing on 0 kg, when the spreader is empty, weighing cells shall be tared. Click at Home screen picture. Select ”Machine” Select ”Calibrations” Select ”Weighing system” Select ”Tare weighing system” Click to tare weighing cells. The spreader shall be positioned horizontally during taring process. Click to accept the taring.

  • Page 38: Calibration Of Weighing Cells

    > Calibrating of weighing cells Weighing cells are calibrated at the factory, but it is possible to undertake a new calibration if weighing cells don’t show the correct weight. Instead of performig a totally new calibration it is also possble to change a bit on weighing by adjusting the weighing number, this method is recommended in case weighing function is fine, but the displayed weight is a bit wrong, Click at Home screen picture.

  • Page 39: New Calibration

    > New calibration Click to perform a new calibration of weighing cells. The spreader shall be empty, and it shall be placed horizontally. Click to start calibration. Fill a known weight into the spreader. Click onto the entry space “(kg)” Encode the weight that has been filled into the spreader. Complete by clicking A new calibration number is calculated and calibration is completed.

  • Page 40: Tc-Implement Offsets

    A = The distance from the tractor´s drawbar to the spreader´s axle. • B = The distance from the spreader´s axle to the middle of spreading pattern. • C = The length of spreading pattern. Bredal has by way of testing determined some distances that most often prove to be fitting best, but there still might be some difference depending on the length of spreading pattern - spreading for 24 or 36 meter, there might also be difference on various fertilizer types. The distances encoded at the plant and recommended by Bredal: • A = 4,0 meter • B = 6,0 meter • C = 5,0 meter Click the button at Home screen picture.
  • Page 41 Select ”TC - implement offsets” Click onto one of entry spaces (m)” to change the encoded value.

  • Page 42: Test Of Inputs And Outputs

    TEST OF INPUTS AND OUTPUTS It is possible in the test menu to test the spreader´s inputs and outputs. > Test input Click the button at Home screen picture. Select ”Help /test” Select ”Diagnose” Select ”Test input” In test input menu all inputs from the spreader can be seen. When e.g. an inductive sensor is influenced and is changing status between high and low, and all impulses coming from the sensor are added up. In this case 29 impulses are counted from the inductive sensor on the left spreading disc.

  • Page 43: Test Output

    > Test output Click the button at Home screen picture. ”Help / test” Select ”Diagnose” Select ”Test output” Make sure there is nobody near the spreader when the functions must be tested! Here it is possible to test P-valves that regulate conveyor belt speed. Encode a % value in the text box.

  • Page 44: Go Back To Factory Settings

    GO BACK TO FACTORY SETTINGS If any values in the basic encoding have been deleted or changed, the original factory settings can be restored, pay attention to all values that could have been eventually changed since the machine was delivered from the factory will be changed back to original values as soon as factory settings are restored.

  • Page 46: Fertilizer Quality

    Try again on other granules, big as well as small, and calculate after that medium granule strength. Granule size can be measured by Bredal sorting box. Fill the space above the sieve, place back the top and shake until there is no more changes to be seen in distribution pattern. Position the box with the top looking upwards again. Now the granule size distribution can be determined.
  • Page 47 density of about 1,0 kg/liter or a bit more. Some fertilizer types have lower density (0,7-0,75kg/liter), with these types it will be difficult to achieve spreading width on 36 meter. Crushed or knobby fertilizer has worse aerodynamic characteristics, therefore it doesn´t fly so far. Large spreading widths require fertilizer that flies very good. These abilities are hard to measure in practice, but a visual evaluation is enough while not difficult to make, it is particularly smooth surface and roundness of the grain that provide the best flying properties.

  • Page 48: Settings For Different Types Of Fertilizer

    Spreading table on the right of the screen shall be chosen. Choose F8/F10 under machine type. Either A or H discs can be chosen (as standard F8/F10 are equipped with A discs) Choose the fertilizer type that is to be spread Choose the working width the spreader will spread on Press to see the result Now the result page appeares, along with the settings that fit for the chosen fertilizer type.

  • Page 49: Spreading Tests And Adjusting Application Rate

    SPREADING TESTS AND ADJUSTING THE APPLICATION RATE There shall always be performed a spreading test in the field to ensure that the spreading result is satisfying. The following factors shall be taken into consideration in connection with a spreading test: • The test shall be taken under dry conditions (field/machine) • The test shall be performed in the field covered with good-size crops - approx. 10 cm vigorous plant cover to avoid offspringing. • Make sure that you perform the test on a flat part of the field, as well as that the trays are positioned as horizontally as possible. • The test shall be performed at the forward speed which is normally chosen for spredning (optimally 14-15 km/t, if the field allows that). • Let approx. 100 -> 200 kg fertilizer through the spreader before the start of the test. There might be layers of old fertilizer, rust etc. on the spreader´s discs and vanes, which must be worn off before the spreader starts to show a constant spreading pattern. • The trays are placed at 1/2 working width at both sides from the middle track (of 3 tracks). Move forward along the 1st track back to the 2d and forward again along the 3d.

  • Page 50: In Case There Is Too Much Fertilizer In Between The Tracks

    >If there is too much fertilizer in the middle between tracks Encode a smaller value under downchute position. Encode about 2 scale intervals less. In case the following test shows that 2 intervals is too much, the difference between the two tests indicates how much the scale shall be moved back for. > If there is too much fertilizer behind the spreader Encode a bigger value under downchute position.

  • Page 51: Connecting/Disconnecting At Headland (Manual)

    CONNECTING/DISCONNECTING AT HEADLAND (MANUAL) If spreading is done without applying section control, the spreading shall be connected and disconnected at the right time. A common rule is: When the discs go past the headland track, spreading has to be disconnected. The connecting is necessary when the discs are at one working width away from headland track.

  • Page 52: Density

    DENSITY Fill the calibration bucket with fertilizer, tap it a few times lightly against the floor and fill it fully. Swipe off the top. Then hang the bucket on the weighing installation onto checkmark (X1). Set the counterweight so the arm balances. Read the fertilizer´s density next to the bolt end. (Calibration kit belongs to additional equipment) If the weight gets out of adjustment or when a control weighing has to be done, it is performed by filling the bucket with water. When the weight arm has acquired the balance, the bolt end shall point out at 1,0 at the scale. If not, the bolt shall be adjusted until the setting fits.

  • Page 53: Late Application With The Help Of Specific Late Application Equipment

    -2,0 -200 -1,0 -100 -1,0 -150 -0,5 -100 -0,5 -150 -150 Example: The given working width is 30 meter. PTO revolutions and downchute settings for the fertilizer to be spread is according to Bredal homepage 1000 rev/min and for downchute 5,0. As per the table under 30 meter there shall be deducted 150 rev/min from the 1000, which gives the optimal PTO of 850 rev/min. Downchute position is normally 5,0, according to the table 0,5 shall be deducted, so the optimal downchute setting is 4,5.

  • Page 54: Troubleshooting And Maintenance

    ERROR IN APPLICATION In this section there can be found description of the most common mistakes that might appear, along with causes to different error messages, and some help on searching for errors among the spreader´s electronic components. > Error in application rate The most common error appears when the spreader’s conveyor belt is not moving with the correct speed, or isn´t moving at all. The alarm can often go off quite briefly and disappear automatically again as soon as the mistake has disappe- ared, this case is not a sign of any mistake on the spreader, but is conditioned by the fact that application rate has been shortly out of application rate area.

  • Page 55: If Belts Do Not Run, The Following Might Be The Cause

    (12V). In case there is no voltage, the other sensors on the machine are not functioning either. In case the gear box sensor is defected, it shall be changed with a new one of the same type (Bredal order nr.: 01023137)

  • Page 56: Basic Settings And Adjustment Of Downchute Positions

    BASIC SETTINGS AND ADJUSTMENT OF DOWNCHUTE POSITION In order to achieve the best possible spreading picture it is important that basic settings for downchute are correct. Turning points for both downchutes shall be centered over the middle of the plates, downchutes position shall also be adjusted correctly. This control and adjustment shall be performed if parts of spreading unit or downchute have been separated.
  • Page 57 Downchutes shall be separated, as the base plates need to be used for adjustment. Loosen M8 bolt inside, then unscrew the unbraked unbraco screw out. Make sure that control disc, that centers downchute in the hole, comes back at its place when downchutes shall be put back together.
  • Page 58 After adjustment downchutes have to be put together, they shall be able to easily turn, when the central screw has been tightened; when they appear to turn rather easily, the counter screw shall be tightened. Make sure you get both the central disc and the big tightening disc exactly at their places. Mount downchutes and a drawbar back at place. Now the basic settings for downchute scale shall be controlled / adjusted.

  • Page 59: Control/ Adjustiment Of Downchute Scale

    > Control / adjustment of downchute scale Use the following procedure to make sure that downchutes are correctly positioned. Working width on ”36” meters is encoded into the computer. ”Auto, no flow control” shall be chosen under downchute control. Go back to operating picture and click ”start spreading” Note, headland spreading may not be activated, as downchutes would then not assume the right position, all sections shall be on. After ”start spreading” has been clicked on, the downchutes will move out and po- sition themselves in front of the little arrow cut in the bottom plate of downchutes. Unless the arrows are right across each other, they shall be adjusted so that basic settings are fitting.

  • Page 60: Adjustment Of Belt

    ADJUSTMENT OF BELT The belts shall be running in the middle of the rollers , in case a belt is running out to one side, it shall be adjusted. If the belt is running out to one side, the screw shall be tightened on that side where the belt is running to.

  • Page 61: Checking And Basic Settings For The Rear Door

    CHECKING AND BASIC SETTINGS FOR THE REAR DOOR Correct basic settings for the rear door secure the right application rate. The settings can be controlled by setting the scale onto 40 and placing 2 pcs of 40mm square tubes onto the belt under the lid. In case the settings don’t fit, it is necessary to adjust the drawbar of the lid. Set the drawbar scale onto 40 Place 2 square tubes at each side under the lid.

  • Page 62: Lubrication Points

    LUBRICATION POINTS Various lubrication points on the machine are described below, along with the standard number of operation hours for lubrication intervals given per each lubrication point. > For each 50 hours Flange bearing together with 6-groove axle towards the tractor. Remove the PTO axle to lubricate the axle with 6 grooves. Cardan joint in the middle under the spreader, the stainless steel guard must be removed, to enable the lubrication.
  • Page 63 Flange bearing at rear axle. PTO-axle under the spreader, disassemble further the PTO axle and lublicate 6-track ends with grease. The input shaft of the spreader box.

  • Page 64: Every 100 Hours

    LUBRICATION POINTS > For each 100 hours The roller bearings (2 on each front roller), it might be necessary to scroll the belt to be able to reach the lubricating nipple. Belt guide rollers (2 on each belt) Belts snap rolls (2 lubrication points on each belt) Seal on the gearbox outside.
  • Page 65 Flange bearings by pull rolls for the belt, both in the middle and in between the gearbox and the frame. Right and left top, just below the plates.

  • Page 66: Every 200 Hours

    LUBRICATION POINTS > for Each 200 hours Tightening device on the spreading unit. Drawbar/Ball hitch Seals on the rear axle brake camshaft and brake drums.
  • Page 67 Weighing cells in front and back. Hinges and ends on cylinder for hydraulic cover.

  • Page 68: Maintenance And Lubrication Of Spreading Unit

    MAINTENANCE AND LUBRICATION OF SPREADING UNIT It is very important that spreading unit is properly maintained/lubricated. There exists a generall rule interval for frequency of spreading unit lubrication, besides it is relevant that e.g. headland device is lubricated, esp. after washing and before the spreader is put away after the season. Moreover it is important to test the headland gear function every time the tightening on the spreader takes place, and after a long standstill period. Tightness of the belts shall also be controlled regularly. Below it is described in a detailed way how the spreader shall be inspected and maintained.

  • Page 69: Lubrication

    > Lubrication There are 2 lubrication places inside of the spreading unit, they shall be greased every 200 operating hours. If the spreader has been thoroughly washed inside, it shall anyway be processed and headland gear shall be lubricated as well. Headland gear shall be sprayed with oil on the axle where the claw-coupling slides up and down.

  • Page 70: Gear For Operating The Belts

    GEAR FOR OPERATING THE BELTS There is a gear box for operating each belt. Each gear box contains 3,5 liter transmis- sion oil. By normal operation it is not necessary to change transmission oil. A small thumb screw is mounted on top of the gearbox for manual operation of the belts.

  • Page 72: Tire Pressure Table

    TIRE PRESSURE TABLE TIRE SIZE TIRE BRAND/ TYPE RECOMMENDED TIRE PRESSURE 520/85 R38 ALLIANCE FARM PRO 169 A8/169 B 3,6 BAR 520/85 R42 ALLIANCE FARM PRO 157 A8/157 B 1,6 BAR 710/75 R32 TRELLEBORG TM 2000 3,2 BAR 650/85 R38 TRELLEBORG TM 900 HP / ALLIANCE 385 AGRISTAR 2,4 BAR 650/65 R38 MICHELIN MULTIBIB 1,6 BAR 800/65 R32 ALLIANCE 360 3,1 BAR...
  • Page 74 Bredal is located in Vejle, Denmark, where it has top modern production facilities with latest equipment used for pro- ducing the high-quality machines. Bredal A/S . Nimvej 1 . 7120 Vejle . Denmark . Tel.: (+45) 75 89 51 77 . info@bredal.com . www.bredal.com...
