Cooper Metal Shed FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-17060 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
Page 2
Scan this QR Code to view our online tutorial Estimated time for assembly: 4 hours...
Page 3
ATTENTION Before Installation, you must check building code or contact your local government authority to determine if building approval is required. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
Page 5
PACKAGE CONTENTS CODE DESCRIPTION PART Left Side Floor Frame 46-13/32" 1180mm Right Side Floor Frame 46-13/32" 1180mm Left Rear Floor Frame 37-39/64" 955mm Right Rear Floor Frame 37-39/64" 955mm Left Front Floor Frame 23-39/64" 600mm Right Front Floor Frame 23-39/64" 600mm Left Door Jamb 67-45/64"...
Page 6
PACKAGE CONTENTS CODE DESCRIPTION PART Roof Trim - 1 38-13/16" 986mm Roof Trim - 2 38-13/16" 986mm Horizontal Door Brace 17" 432mm Ridge Cap 51-5/16" 1304mm Left Gable Right Gable Gable Brace - 1 9" 230mm Gable Brace - 2 9"...
Page 7
PACKAGE CONTENTS 247x 193x 225x GLV02 F100 Install all hardware perpendicular to the opening. v.08012023C...
Page 8
Required tools for assembly (Not included) (1/16") (13/32") Assemble the left rear oor frame (2L) to the right rear oor frame (2R). 2L is upon 2R...
Page 9
Assemble the left side oor frame (1L) and right side oor frame (1R) to the assembly. Part 2L is upon part 1L. Part 2R is upon the part 1R. Assemble the left front oor frame (3L) and right front oor frame (3R) to the assembly.
Page 10
Assemble the ramp (5) to the assembly. Assemble the wall panel-2 (P1) to the assembly. 1-The code P1 can be found on the back of panel 2-One person hold on the panel P1 and the other one assemble the P1 on 3R with 3 pcs F1 screws and washers.
Page 11
Assemble the corner panel (P9) to the assembly. P9 is a piece corner panel which should surround the P1 in the place of corner. The hole here should be left for another panel. Don't screw on the F1 screw. Assemble the right side wall channel (22R) to the corner panel (P9). The hole here should be left for another panel.
Page 12
Assemble the wall panel-1 (P2) to the assembly. The hole here should be left for another panel. Don't screw on the F1 screw. Assemble the corner panel (P9) to the assembly. The 2 holes here should be left for another panel. Don't screw on the F1 screws.
Page 13
Assemble the wall panel-1 (P2) to the assembly. Assemble the left rear wall channel (23R) to the assembly. The hole here should be left for another panel. Don't screw on the F1 screw. 23R is upon 22R v.08012023C...
Page 14
Assemble the wall panel-1 (P2) to the assembly. The 2 holes here should be left for another panel. Don't screw on the F1 screws. Assemble the right rear wall channel (23L) to the assembly. The 2 holes here should be left for another panel.
Page 15
Assemble the corner panel (P9) to the assembly. The hole here should be left for another panel. Don't screw on the F1 screw. Assemble the left side wall channel (22L) to the assembly. The hole here should be left for another panel. Don't screw on the F1 screw.
Page 16
Assemble the corner panel (P9) to the assembly. The 2 holes here should be left for another panel. Don't screw on the F1 screws. Assemble the wall panel-1 (P2) to the assembly.
Page 17
Assemble the wall panel-2 (P1) to the assembly. The hole here should be left for another panel. Don't screw on the F1 screw. Assemble the side wall angle-1 (9) and side wall angle-2 (11) to the assembly. v.08012023C...
Page 18
Assemble the left gable (21L) , gable brace-1 (B3) , roof beam splice (12) , gable brace-1 (B4) to the right gable (21R). Part 12 should be installed on 21L between the left folding edge and B3. Please wear gloves and bend the corner of Part 12.
Page 19
Assemble the rear wall angle-1 (10L) , rear wall angle-2 (10R) and the pre assembled tri-angle panel to the assembly. The 2 holes here should be left for anotherpanel. Don't screw on the F1 screws. Assemble the rear wall angle-1 (10L) to the side wall angle-1 (9) . Then assemble the rear wall angle-2 (10R) to the side wall angle-2 (11).
Page 20
Slide in the door slides (G2) to the left door track (7) and right door track (8). Assemble the left door track (7) , right door track (8) and the pre-assembled tri-angle panel to the assembly. The 2 holes here should be left for anotherpanel.
Page 21
Assemble the left door track (7) to the side wall angle-1 (9) . Then assemble the right door track (8) to the side wall angle-2 (11). Part 9 and Part 11 with big hole is upon the Part 7 & Part 8 with small hole.
Page 22
Assemble the roof beam1 (16) to the assembly. Assemble the door track splice (6) to the assembly.
Page 23
Assemble the left door jamb (4L) and right door jamb (4R) to the assembly. Assemble the roof panel-2 (P11) and the roof panel-1 (P10) to the assembly. v.08012023C...
Page 24
Assemble the roof panels-3 (P7) to the assembly. P10/P11 P7 is upon panel P10/P11. Assemble the roof panel-1 (P10) and roof panel-2 (P11) to the assembly. P10/ Please note the back roof panel P11 is on the right , and P10 on the left. Here is opposite to the front roof panels.
Page 25
Assemble the roof trims-1 (17L) , roof trims-2 (17R) and peak caps (GE) to the assembly. Installation Caps of roof cover. Assembel Part 17R/17L on the Part 19 with F1 screw first , and assemble Part GE on the Part 19 with F1 screw Front/Back Eaves. Assemble the side roof trims (15) to the assembly.
Page 26
Attach handles to the door-1 (D1) and door-2 (D2). Install the handles with F2 screws assigning the middle hole on the handle. Assemble the horizontal door braces (18) to the door-1 (D1) and door-2 (D2).
Page 27
Attach lower door guides to the doors (D1,D2). Assemble the doors (D1,D2) to the door slides (G2). 7&8 There are 3 holes on the door sliders for adjusting the height of the doors. Cap all F1 screws with the plastic screw caps S2.
Page 28
Install the anchors (J1) onto each corner of base. Uers need to drill the installation holes by themselves with dia.1.5mm or 1/16" driller. Anchor the shed to the ground. After the whole shed and anchors installed, F100 move the shed to the place users want it to be, then drill one hole on concrate groundfor each anchor in 2"...
Page 29
Assemble the stainless steel hanger (J) to the connecting panel (D). Assemble the assembly to the top side of the wall panel. Install the combination part of D & J between the top of wall panel and top reinforcing rib with 4 pieces F1 screws.
Page 30
FURNITURE CARE AND MAINTENANCE Metal Shed Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
