Page 1
Cooper Metal Shed FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-17061 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
Page 2
Scan this QR Code to view our online tutorial Estimated time for assembly: 5 hours...
Page 3
ATTENTION Before Installation, you must check building code or contact your local government authority to determine if building approval is required. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
Page 5
PACKAGE CONTENTS CODE DESCRIPTION PART Left Side Floor Frame 33-3/8" 848mm Right Side Floor Frame 33-3/8" 848mm Left Rear Floor Frame 46" 1169mm Right Rear Floor Frame 46" 1169mm Left Front Floor Frame 31-13/16" 809mm Right Front Floor Frame 31-13/16" 809mm Left Door Jamb 67-45/64"...
Page 6
PACKAGE CONTENTS CODE DESCRIPTION PART Roof Beam Splice 14" 356mm Roof Beam L 33-1/2" 852mm Roof Beam R 33-1/2" 852mm 15-1 Side Roof Trim 34-1/2" 876mm 15-2 Side Roof Trim 34-1/2" 876mm Roof Trim - 1 47-1/2" 1207mm Roof Trim - 2 47-1/2"...
Page 8
PACKAGE CONTENTS 344x 281x 328x GLV02 F100 Install all hardware perpendicular to the opening.
Page 9
Required tools for assembly (Not included) ( 1/16" ) ( 13/32" ) Assemble the left side oor frames (1L) to the right side oor frames (1R). Then assemble the left rear oor frame (2L) to the right rear oor frame (2R). 1R is upon 1L 1R is upon 1L 2L is upon 2R...
Page 10
Assemble the side oor frames (1L,1R) to the rear oor frames (2L,2R) . 2L is upon 1L 2R is upon 1R Assemble the left front oor frame (3L) and right front oor frame (3R) to the assembly. 3L is upon 1R 3R is upon 1L...
Page 11
Assemble the ramp (5) to the assembly. Assemble the wall panel-3 (P3) and corner panel (P9) to the assembly. 1-The code P3/P9 can be found on the back of panel. The 2 holes here should be left for another panel. Don't screw on the F1 screws.
Page 12
Assemble the right side wall channel (22R) to the corner panel (P9). The hole on the right should be left. Don't screw on the F1 screw. Assemble the wall panel-1 (P2) to the assembly. The 2 holes here should be left for another panel.
Page 13
Assemble the corner panel (P9) to the assembly. The hole on the right should be left. Don't screw on the F1 screw. Assemble the left side wall channel (22L) to the assembly. The hole here should be left for another panel. Don't screw on the F1 screw.
Page 14
Assemble the left rear wall channel (23R) to the assembly. The hole on the right should be left. Don't screw on the F1 screw. 23R is upon 22L Assemble the wall panel-1 (P2) to the assembly. The 2 holes here should be left. Don't screw on the F1 screws.
Page 15
Assemble the corner panel (P9) to the assembly. The hole on the right of P9 bottom should be left. Don't screw on the F1 screw. Assemble the left rear wall channel (23L) to the assembly. 23L is upon 23R The hole on the right should be left. Don't screw on the F1 screw.
Page 16
Assemble the right side wall channel (22R) to the assembly. The hole on the right should be left. Don't screw on the F1 screw. 23L is upon 22R Assemble the corner panel (P9) and Wall Panel-3 (P3) The 2 holes on the right should be left.
Page 17
Assemble the left side wall channel (22L) to the assembly. 22L is upon 22R The hole on the right should be left. Don't screw on the F1 screw. Assemble the wall panel-2 (P1) to the assembly. The 2 holes here should be left. Don't screw on the F1 screws.
Page 18
Assemble the side wall angles-1 (9) and side wall angles-2 (11) to the assembly. These 4 holes here should be left. Don't screw on the F1 screws. Part 11 is upon Part 9 Assemble the gable braces (B1,B2) to the gables (21L,21R).
Page 19
Assemble the left gables (21L) , gable braces-1 (B3) , roof beam splices (12) , gable braces-1 (B4) to the right gables (21R). Part 12 should be installed on 21L between the left folding edge and B3. Please wear gloves and bend the corner of Part 12.
Page 20
Assemble the rear wall angle-1 (10L) , rear wall angle-2 (10R) and the tri-angle panel to the assembly. The 2 holes here should be left for another panel. Don't screw F1 screws. Slide in the door slides (G2) to the left door track (7) and right door track (8).
Page 21
Assemble the left door track (7) , right door track (8) and the tri-angle panel to the assembly. The 2 holes here should be left for another panel. Don't screw on the F1 screws. Assemble the wall panels-1 (P2) to the assembly. The P2 installed afterwards should be upon the one installed in previous step.
Page 22
Assemble the right roof beams (14) to the left roof beams (13). 14 is upon 13 Tips: do pay attention to the distance of the holes assigned through on 13/14. Assemble the roof beam (16-1) to the roof beam (16). 16-1 0.23"...
Page 23
Assemble the roof beams (16,16-1) to the assembly 16-1 Assemble the roof beams (13,14) to the assembly. The part no. 9 and no. 11 with big hole should be upon the part 7/8/10L/10R with small hole. v.08012023C...
Page 24
Assemble the door track splice (6) to the assembly. Assemble the left door jamb (4L) and right door jamb (4R) to the assembly.
Page 25
Assemble the roof panel-2 (P11) and the roof panel-1 (P10) to the assembly. Assemble the roof panels-3 (P7) to the assembly. P7 is upon panel P7. P7 is upon panel P10. v.08012023C...
Page 26
Assemble the roof panel-1 (P10) and roof panel-2 (P11) to the assembly. P10 is upon panel P7. P11 is upon panel P7. Assemble the ridge caps (19) to the assembly.
Page 27
Assemble the roof trims-1 (17L) , roof trims-2 (17R) and peak caps (GE) to the assembly. Assembel Part 17R/17L on the Part 19 with F1 screw first, and assemble Part GE on the Part 19 with F1 screw Front/Back Eaves. Assemble the side roof trims (15-1,15-2) to the assembly.
Page 28
Attach handles to the door-1 (D1) and door-2 (D2). Install the handles with F2 screws assigning the middle hole on the handle. Assemble the horizontal door braces (18) to the door-1 (D1) and door-2 (D2).
Page 29
Attach lower door guides to the doors (D1,D2). Assemble the doors (D1,D2) to the door slides (G2). 7&8 There are 3 holes on the door sliders for adjusting the height of the doors. Cap all F1 screws with theplastic screw caps S2 .
Page 30
Install the anchors (J1) onto each corner of base. Uers need to drill the installation holes by themselves with dia.1.5mm or 1/16" driller. Anchor the shed to the ground. After the whole shed and anchors installed, F100 move the shed to the place users want it to be, then drill one hole on concrate groundfor each anchor in 2"...
Page 31
Assemble the stainless steel hanger (J) to the connecting panel (D). Assemble the assembly to the top side of the wall panel. YOU’RE FINISHED! v.08012023C...
Page 32
FURNITURE CARE AND MAINTENANCE Metal Shed Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
