Edisons PROTEGE CZ-100 Owner's Manual

CZ-100 Owner's manual
Bill of Materials (BOM)
QYT Par t No
NO Name
1 Power cord 1 CZ 10001
2 Water tank 1 CZ 10002
3 Spray lance 1 CZ 10003
4 Gasket 1 CZ 10004
5 Spray nozzle 1 CZ 10005
6 Straight head gun 1 CZ 10006
7 Spray gun(Ball valve) 1 CZ 10007
8 Output hose 1 CZ 10008
9 Ratchet strap 2 CZ 10009
10 Drain cap gasket 1 CZ 10010
11 Drain cap 1 CZ 10011
12 Inner filter 1 CZ 10012
13 Snap ring 1 CZ 10013
Troubleshooting Guide
Problem Possible reason
Bad power connections
Short in wires
Pump will not
Motor hooked to battery
turn on
incorrectly
Problem with pressure switch
Nozzle clogged
No water out from
Low water or Air in hose
nozzle, Low
pressure or Pump
W o r n i n t a k e h o s e
does not run
Clogged inner filter
stably
Worn spray gun or Nozzle
clogged
Clogged suction hose
Clogged inner filter
Low flow
System leaks
Connections not fully engaged
O-ring not in right position
Water leakage
Worn O-ring
3
QYT
NO Name Par t No
14 Suction hose
1 CZ 10014
15 Gasket 1 CZ 10015
16 Brass fitting
2 CZ 10016
17 Screw
2 CZ 10017
18
O-ring 2 CZ 10018
19 Pump 1
CZ 10019
20 Gasket
4 CZ 10020
21
Screw 4 CZ 10021
22 Output hose (short) 1
CZ 10022
Screw
23
2 CZ 10023
24 Hose clamp
1 CZ 10024
Tank lid
25 1 CZ 10025
Lid gasket
26
1 CZ 10026
Solution
Check battery connections
Check wires
Ensure red battery clamp to the
positive(+) terminal of the battery
correct wiring, then remove pump
head and tighten offset bearing.
Replace pressure switch
Clean nozzle
Fill water tank or Purge air
from system
Replace intake hose
Clean inner filter
Replace spray gun or
Clean nozzle
Remove residues
Clean inner filter
Tighten leaking hose clamps
or fittings
Tighten hose clamps or fittings
Check O-ring
Replace O-ring
12V DC Electric Sprayer 100L
Owner's manual
CZ-100
