Page 6: About This System Manual
1 About this System Manual Introductory information This section provides introductory and general information on the System Manual. Chapter index Subject of the System Manual Observe related documents Imprint Symbols and warning signs used Main terms Technical changes reserved...
Page 7: Subject Of The System Manual
About this System Manual Subject of the System Manual Subject of the System Manual Users This System Manual is an integral part of the unimes H power distribution system. It is aimed at users of the unimes H power distribution system: specifiers, manufacturers,...
Page 8: Observe Related Documents
Manuals of the individual enclosure types Design verification Specifier Hager catalogues for power distribution systems with technical information Guidelines for project planning and design of switchgear according to DIN EN 61439 (VDE 0660-600) Component selection, lists and production drawings from the hagercad...
Page 9 Manuals/instructions for the operating equipment Design verification Storing the documents This System Manual is an integral part of the unimes H power distribution system. ➢ Store the System Manual at the operating site of the switchgear and con- trolgear assembly. The authorised personnel must have access to the System Manual at all times.
Page 10: Imprint
Product names, company names, trademarks or registered trademarks are the property of their respective owners and must be treated as such. The manual does not extend the Sales and Delivery Conditions of Hager. No new claims concerning the warranty and guarantee, which extend beyond the Sales and Delivery Conditions, can be derived from this manual.
Page 11: Symbols And Warning Signs Used
About this System Manual Symbols and warning signs used Symbols and warning signs used Structure of warning messages Signal word Type and source of the danger! Consequences if the danger is ignored ➢ Measures for averting the danger Danger levels in warning messages Colour Signal word Consequences of non-compliance...
Page 12: Main Terms
Main terms Main terms Group of users of the switchgear and controlgear assembly The unimes H power distribution system is set up to establish switchgear and controlgear assemblies according to the series of standards EN 61439, Part 1 and Part 2.
Page 13 About this System Manual Main terms Switchgear and controlgear assembly manufacturer The manufacturer of the switchgear and controlgear assembly is responsible for the finished switchgear and controlgear assembly. That is generally the panel builder. The panel builder's area of responsibility includes, among other things: measuring the system according to the nominal data agreed on with the user, or the specified nominal data, compliance with the design verification of the original manufacturer as well as...
Page 14: Personnel And Authorisations
About this System Manual Main terms 1.5.1 Personnel and authorisations Authorised personnel Assembly, installation, operation, handling and repairs may only be carried out by authorised personnel. According to EN 61439-1, authorised personnel refers to an electrically skilled person or an electrically instructed person. This person is authorised to perform specific work.
Page 15 At the very least, an electrically instructed person must be deployed as a work supervisor, depending on the type of activity and the electrical hazard. Hager recommends deploying a qualified electrically skilled person as work supervisor.
Page 16: Working Methods
About this System Manual Main terms 1.5.2 Working methods Working methods All work on an electrical system must be planned. One of the three working methods is selected based on a hazard and risk assessment and depending on the situation: Work in a voltage-free state Work in the vicinity of live parts Work on live parts...
Page 17: Enclosure System, System Components, Switchgear And Controlgear Assembly
Hager. System components Unit, assembly or equipment as an integral part of a system or subsystem. Hager is a producer of matched and tested system components. Hager has provided verification of the design by means of tests, calculations or by applying the design rules and makes this data available to the manufacturer of the switchgear and controlgear assembly.
Page 18: Project Planning And Constructing Power Switchgear
The manufacturer of the switchgear and controlgear as- sembly must obtain Hager's design verification of the parts used. If this verifi- cation is not available or if the manufacturer does not use type-tested parts, the manufacturer of the switchgear and controlgear assembly must provide the design verification.
Page 19: Special Operating Conditions
About this System Manual Main terms 1.5.5 Special operating conditions The user must inform the switchgear and controlgear assembly manufacturer of special operating conditions. The relevant special requirements must also be fulfilled or special agreements must be made between the user and the manufacturer.
Page 20: Safety
The safety-related information is provided to help you identify and avoid risks in good time. This information is essential for safe assembly and use of the system. Chapter index Intended use of the unimes H system Safety instructions for the power distribution system Preventing arc faults...
Page 21: Intended Use Of The Unimes H System
Complying with the safety regulations. Misuse Any other or additional use is considered misuse. Hager does not assume any liability for damages resulting from misuse. Technical changes reserved...
Page 22 Safety Intended use of the unimes H system Danger due to electric shock, arc faults or fires in the case of misuse Misuse of the power distribution system parts can result in dangerous situations due to high voltages and high currents. This may result in serious injuries and even death.
Page 23: Safety Instructions For The Power Distribution System
Safety Safety instructions for the power distribution system Safety instructions for the power distribution system Electrical hazards DANGER An electric shock results in serious burns and life- threatening injuries and even death. ➢ Prior to starting work on the system, observe the following 5 safety rules: 1.
Page 24: Preventing Arc Faults
Safety Preventing arc faults Preventing arc faults Provoked arc fault if there is no arc fault pro- Significant damage in the system tection system. The occurrence of arc faults with high subsequent costs following can cause deadly an arc fault. accidents.
Page 25 Ensure the power supply of the active arc fault protection system If the switchgear and controlgear assembly is equipped with a Hager active arc fault protection system, a permanent power supply must be guaranteed. The active arc fault protection system must also be securely supplied with voltage during maintenance and may not be switched off.
Page 26: Basic Safety Measures
Safety Basic safety measures Basic safety measures Observe safety objectives The dangers of electricity are frequently underestimated - even by electrically skilled personnel. To prevent accidents with consequences even up to death, the safety objectives must observed. ➢ Make sure to observe the following safety objectives: Protection against electric current passing through the human body (electrification, internal burns, ventricular fibrillation), Protection against arcs (heat, blinding, shock waves, flying parts,...
Page 27 Safety Basic safety measures Risk of electric shock in the vicinity of live parts! The dangerous proximity to live parts is underestimated time and time again. It may result in electric current passing through a human body and even death. ➢...
Page 28 Safety Basic safety measures Risk of accident from entering or climbing on the switching enclosure Accidents can happen when entering or climbing on the switching enclosure during assembly work or when drawing in cables. The casing of a switchgear and controlgear assembly is not designed for loads.
Page 29: Safety During Packaging And Transport
Safety Safety during packaging and transport Safety during packaging and transport Risk of accidents if the enclosure tips over or slips during transport or assembly! If the load is not evenly distributed, there is a risk that the enclosure may tip over or slip.
Page 30 Safety Safety during packaging and transport Risk of accident due to the enclosure tipping at the assembly site! If the enclosure is entered during assembly and the load is unevenly distributed, there is a risk of the enclosure tipping over. Personnel may be seriously injured or killed.
Page 31 If the manufacturer of the switchgear and controlgear assembly makes changes, with replacement of the equipment, that are not included in the design verification of the original manufacturer, Hager, the manufacturer of the switchgear and controlgear assembly becomes the original manufacturer for these changes.
Page 32: Personnel Requirements
Safety Personnel requirements Personnel requirements Product life cycle phase The following is an overview of the requirements for personnel during the life cycle phases of the switchgear and controlgear assembly. Product life cycle phase Training, qualification or skills Electrical engineer, master electrician, panel builder, electri- Planning cally skilled person Switchgear manufacture, as-...
Page 33 Safety Personnel requirements have the equipment and personal protective equipment (PPE) necessary for the relevant work and test it before use. Work on live equipment may only be performed if written work instructions have been defined by the work supervisor after a risk and hazard assessment has been carried out.
Page 34: Operator Obligations
Safety Operator obligations Operator obligations Operator responsible The operator responsible for the power switchgear must at least ensure that the switchgear is only used for its intended purpose and only in perfect working order, the safety equipment is regularly checked, maintenance and cleaning are regularly performed, the required personal protective equipment is available and worn by authorised personnel,...
Page 35: Standards And Certificates
The legal requirements for compliance with the low-voltage directive, EMC directive and national stipulations are met by complying with the standards. The unimes H power distribution system is set up for the implementation of switchgear and controlgear assemblies within the meaning of power switchgear and controlgear assemblies (PSC switchgear and controlgear assemblies).
Page 36 3 unimes H power distribution system Important features This section describes the important features of the unimes H power distribution system. Chapter index Introducing the system Spatial concept of enclosures Front concept of enclosures Ventilation concept of enclosures Installation options of the switchgear and controlgear assembly...
Page 37: Unimes H Power Distribution System Introducing The System
Switchgear and controlgear assemblies with enclosure depths of up to 800 mm and incoming units up to 4000 A are implemented from the components of the type-tested unimes H power distribution system. Over 1000 design versions can be assembled from the standardised enclosure types based on the basic enclosure U-BS(I).
Page 38: Expansion Technology - Principles
H power distribution system Introducing the system 3.1.1 Expansion technology - Principles Type of electrical connection according to EN 61439 The user can specify the electrical connection of functional units within the switchgear combination. A three-digit code identifies the type of electrical...
Page 39 H power distribution system Introducing the system Plug-in technology/fixed installation -F Main power circuit with permanently installed functional units Permanently installed entry and outlet Auxiliary power circuit permanently installed or plugged- Connection according to EN 61439- FFF or FFD...
Page 40 H power distribution system Introducing the system Insertion technology -W Main power circuit With functional units which are switched from the operating position to the disconnected position Input plugged in Outlet plugged in Auxiliary circuit Plugged in Connection according to...
Page 41: System Overview
H power distribution system Introducing the system 3.1.2 System overview U-PWE U-PWK U-TE U-TK U-T2 ACB incoming/ ACB coupling enclo- ACB incoming/ ACB coupling enclo- ACB incoming/ outgoing enclosure sure outgoing enclosure sure outgoing/coupling enclosure Couplings Incoming units Couplings...
Page 42 H power distribution system Introducing the system U-LE U-LK U-CW(I) U-S(I) U-SV LBS incoming/ LBS coupling enclo- Outgoing enclosure HRC outgoing enclo- HRC outgoing enclo- outgoing enclosure sure combiway sure sure LL/sasil/ slimline horizontal slimline vertical Couplings Field incoming unit...
Page 43 H power distribution system Introducing the system U-FL U-MUN U-BS(I) U-BK U-ES HRC outgoing enclo- Modular enclosure Basic enclosure Reactive power com- Corner panel sure fuseline univers N universal pensation enclosure Incoming unit Cable enclosure Compensation Traversal Field incoming unit...
Page 44 Areas of application The unimes H power distribution system is used in the following areas: Infrastructure, e.g. railway, airports, motorway tunnels Commercial buildings, e.g. hotels, shopping centres, sports facilities...
Page 45 1600 A can be integrated via modular enclosure univers N (U- MUN). This extends the range of applications of the unimes H to include the kits with all the accessories of the univers N system for low-voltage building distribution units.
Page 46: Spatial Concept Of Enclosures
Spatial concept of enclosures Spatial concept of enclosures Sophisticated spatial concept The unimes H power distribution system is characterised by a sophisticated spatial concept: a modular structure allows for a wide range of different design versions, combinations can be created in the modular design,...
Page 47: Functional Areas
H power distribution system Spatial concept of enclosures 3.2.1 Functional areas Busbar compartment The rated current I determines the necessary depth of the enclosure: 600 mm (max. 2950 A) 800 mm (max. 4000 A) 3 different positions of the main busbar system H-SaS are possible, of which...
Page 48: Internal Separation
Hager according to IEC/TR 61641. Forms of internal separation according to EN 61439 Form...
Page 49 H power distribution system Spatial concept of enclosures Functional areas/functional compartments Example for the clear distinction of the functional areas (in this case, no expansion to Form 2b of internal separation via bushing partitions and device partitions). Distribution busbar system F-SaS...
Page 50: Front Concept Of Enclosures
H power distribution system Front concept of enclosures Front concept of enclosures Modular front concept The modular front concept fulfils the requirements for flexible front equipment. Depending on the enclosure type and the mountable devices, you can choose between:...
Page 51: Ventilation Concept Of Enclosures
H power distribution system Ventilation concept of enclosures Ventilation concept of enclosures Air conditioning The adapted ventilation concept always ensures a safe climate in the enclosure. Ventilation concept/aeration and ventilation types Raised floor - Module roof with ventilation IP20/IP30...
Page 52 H power distribution system Ventilation concept of enclosures Concrete floor (floor closed) – cover plate closed without ventila- tion IP30 IP40 Cover plate All unimes H configurations with offset cover plate IPx1 possible. (Exception: U-BK reactive power compensation en- closure) Technical changes reserved...
Page 53: Installation Options Of The Switchgear And Controlgear Assembly
H power distribution system Installation options of the switchgear and controlgear assembly Installation options of the switchgear and controlgear as- sembly System installation options Series installation With / without base Wall installation Room installation Niche installation L / U installation...
Page 54: Arc Fault Protection Systems
Hager provides an active arc fault protection system and an optional passive arc fault protection system for the unimes H power distribution system. The reaction time is shortened with an active arc fault protection system: While passive arc fault protection takes about 100 ms to take effect, the active arc fault protection system needs only 2 to 3 ms.
Page 55: Passive Arc Fault Protection
Personal safety and system protection With its short arc fault suppression times of approx. 2 ms, Hager's active arc fault protection system offers a high level of personal safety as well as protection for the system and system function.
Page 56: Main Busbar System
H power distribution system Main busbar system Main busbar system Mechanical characteristics M-BB Busbar layer Enclosure rear Busbar installation position Horizontal Vertical (traversal) Material Flat copper Cu-ETP-R240 Bar support arrangement 2x 30 x 10 2x 40 x 10 II II...
Page 57 H power distribution system Main busbar system Electrical features Enclosure depth [mm] Rated current per busbar system ini- ≤ 2950 ≤ 4000 tial supply Rated current I 2x 30 x 10: 1250 (H-SaS top) 2x 40 x 10: 1600...
Page 58 H power distribution system Main busbar system Enclosure depth [mm] Rated short-time withstand current [kA] 2x 30 x 10: 60 (1 s) 2x 40 x 10: 65 (system-related distance between 2x 60 x 10: 85 4x 60 x 10: 85...
Page 59 TN-C TN-S Main protective conductor (main PE) The main PE can be routed at the top or bottom in the unimes H system. In some enclosures, an outgoing-protective conductor can be mounted opposite the main-PE. Enclosure roof and/or enclosure base...
Page 60: Power Distribution System Enclosures
H power distribution system Power distribution system enclosures Power distribution system enclosures 3.8.1 U-PWE/U-PWK 630-4000 A ACB incoming/outgoing/coupling enclosure 630-4000 A Area of application Incoming units, outgoing units up to 4000 A Cable outlets up to 4000 A Cross couplings up to 4000 A...
Page 61 H power distribution system Power distribution system enclosures Device compartment: Functional units with hw+ air circuit breaker hw+ device type 1600 A 2500 A 4000 A Equipment carrier Horizontal support frame Device size HW1... HW2... HW4... Switch/circuit breaker designation...
Page 62: U-Te/U-Tk 800-2000 A
H power distribution system Power distribution system enclosures 3.8.2 U-TE/U-TK 800-2000 A ACB incoming / outgoing / coupling enclosure 800-2000 A Area of application Incoming units / outgoing units up to 2000 A Cable outlets up to 2000 A...
Page 63 H power distribution system Power distribution system enclosures Device compartment: Functional units with air circuit breaker AR2…S ► 2000 A (front connection) Device type TemPower2 Equipment carrier Horizontal support frame Device size AR2… Switch/circuit breaker designation AR208S AR212S AR216S...
Page 64: U-Te / U-Tk 2500-3200 A
H power distribution system Power distribution system enclosures 3.8.3 U-TE / U-TK 2500-3200 A ACB incoming / outgoing / coupling enclosure 2500-3200 A Area of application Incoming units / outgoing units 3200 A Cable outlets 3200 A Cross couplings 3200 A...
Page 65 H power distribution system Power distribution system enclosures Device compartment: Functional units with air circuit breaker AR3…S ► 3200 A (front connection) Device type tempower2 Equipment carrier Horizontal support frame Device size AR3… Switch/circuit breaker designation AR325S AR332S Rated current switch/circuit breaker I...
Page 66: U-Te / U-Tk 4000 A
H power distribution system Power distribution system enclosures 3.8.4 U-TE / U-TK 4000 A ACB incoming/outgoing/coupling enclosure 4000 A Area of application Incoming units / outgoing units up to 4000 A Cable outlets up to 4000 A Cross couplings up to 4000 A...
Page 67 H power distribution system Power distribution system enclosures Device compartment: Functional units with air circuit breaker AR4…S ► 4000 A (rear connection) Device type tempower2 Equipment carrier Horizontal support frame Device size AR4… Switch/circuit breaker designation AR440S Rated current switch/circuit breaker I...
Page 68: U-T2
H power distribution system Power distribution system enclosures 3.8.5 U-T2 ACB incoming / outgoing / coupling enclosure 800-1600 A Area of application Double feed/double outgoing unit up to 1600 A Double cross coupling up to 1600 A Feed/outgoing unit and cross coupling up to 1600 A...
Page 69 H power distribution system Power distribution system enclosures Device compartment: Functional units with air circuit breaker AR2.. S ► 1600 A (front connection) Device type tempower2 Device support Horizontal support frame Device size AR2… Rated current switch I 1250...
Page 70 H power distribution system Power distribution system enclosures Applications for enclosure height 450 mm …KK …EK …EK …EE 2000 / 2200 2000 / 2200 2000* / 2200** 2000* / 2200** (Coupling / Coupling) (Feed / Coupling) (Feed / Coupling)
Page 71 H power distribution system Power distribution system enclosures Applications for enclosure height 600 mm …KK …EK …EK …EE 2000 / 2200 2000 / 2200 2000* / 2200** 2000* / 2200** (Coupling / Coupling) (Feed / Coupling) (Feed / Coupling)
Page 72: U-Le / U-Lk 1250-1600 A
H power distribution system Power distribution system enclosures 3.8.6 U-LE / U-LK 1250-1600 A LBS incoming / outgoing / coupling enclosure 1250-1600 A Area of application Incoming units, outgoing units 1250-1600 A Cable outlets 1250-1600 A Cross couplings 1600 A...
Page 73 H power distribution system Power distribution system enclosures Device compartment HA… ► (front connection) Device type Device support Vertical support structure Device size Switch designation HA362 HA364 HA462 HA464 Rated current switch I 1250 1600 Maximum power loss P...
Page 74: U-Le / U-Lk 2000-2500 A
H power distribution system Power distribution system enclosures 3.8.7 U-LE / U-LK 2000-2500 A LBS incoming / outgoing / coupling enclosure 2000-2500 A Area of application Incoming units, outgoing units 2500 A Cable outlets 2500 A Cross couplings 2500 A...
Page 75 H power distribution system Power distribution system enclosures Device compartment HA… ► (front connection) Device type Device support Vertical support structure Device size Switch designation HA365 HA366 HA465 HA466 Rated current switch I 2000 2500 Maximum power loss P...
Page 76: U-Cw(I)
H power distribution system Power distribution system enclosures 3.8.8 U-CW(I) Outgoing enclosure without/with integrated cable compartment Area of application Outgoing cables up to 630 A Field feed up to 2000 A Design options Compact circuit breaker h3+ Device installation:...
Page 77 H power distribution system Power distribution system enclosures Characteristic features of field distribution busbars Busbar installation position Vertical Material Flat copper Cu-ETP-R240 Distance between phases [mm] Rated current I Devices can be operated from the outside FE1 1250 1600...
Page 78 H power distribution system Power distribution system enclosures Device compartment: Functional units with compact circuit breaker h3+ MCCB Device type Hager h3+ series (TM / MAG / LSnI / LSI / LSIG / Energy) Device support Module carrier For device field width...
Page 79: U-S(I)
H power distribution system Power distribution system enclosures 3.8.9 U-S(I) HRC outgoing enclosure slimline horizontal Area of application Outgoing cables up to 630 A Field feed up to 2000 A Design options Device installation: slimline Measurement: Outgoing measurement Connection type:...
Page 80 H power distribution system Power distribution system enclosures Characteristic features of field distribution busbars Busbar installation position Vertical Material Flat copper Cu-ETP-R240 Distance between phases [mm] 185 Rated current I Devices can be operated from the outside 1250 1600...
Page 81 H power distribution system Power distribution system enclosures Device compartment [mm] 600 ► 12 MU Module heights Expansion Swivel-mounted control compartment with removable mounting plate Terminal compartment (U-SI only) Connection direction Enclosure roof and enclosure base Connection type Cable connection...
Page 82: U-Sv
H power distribution system Power distribution system enclosures 3.8.10 U-SV HRC outgoing enclosure LL/sasil/slimline vertical Area of application Cable outlets up to 630 A Field incoming unit up to 2000 A Design options Device installation: LL strips/slimline Measurement: Outgoing measurement...
Page 83 H power distribution system Power distribution system enclosures Characteristic features of field distribution busbars Busbar installation position Vertical Material Flat copper Cu-ETP-R240 Busbar distance between centres [mm] 185 Rated current I Devices can be operated from the outside 1250...
Page 84 H power distribution system Power distribution system enclosures Terminal compartment Connection direction Enclosure roof or enclosure base Connection type Cable connection Connection cross-sections 125 A 50 mm 160 A 70 mm 250 A 120 mm 400 A 240 mm...
Page 85: U-Fl
H power distribution system Power distribution system enclosures 3.8.11 U-FL HRC outgoing enclosure fuseline Area of application Outgoing cables up to 1000 A Field feed up to 2000 A Design options Device installation: vertigroup, LVS Measurement: Outgoing measurement Connection type:...
Page 86 H power distribution system Power distribution system enclosures Characteristic features of field distribution busbars Busbar installation position Vertical Material Flat copper Cu-ETP R240 Busbar centre-to-centre distance [mm] 185 Rated current I Devices can be operated 1250 1600 2000 from the outside...
Page 87 H power distribution system Power distribution system enclosures Device compartment [mm] 450 ► 9 MU Module heights 600 ► 12 MU Expansion Swivel-mounted control compartment with removable mount- ing plate Bracket kit for univers N extension Terminal compartment Connection direction...
Page 88: U-Mun
H power distribution system Power distribution system enclosures 3.8.12 U-MUN Modular enclosure univers N Area of application Outgoing cables up to 1600 A Field feed up to 1600 A Design options Device installation: univers N inner fitting system univers N HS inner fitting system...
Page 89: U-Bs(I)
H power distribution system Power distribution system enclosures 3.8.13 U-BS(I) Universal basic enclosure Area of application Cable enclosure separate Traversal for vertical busbar routing Universal control enclosure Measuring enclosure Design options Device installation: Freely configurable Connection type: Cable connection, enclosure roof and base...
Page 90 H power distribution system Power distribution system enclosures Terminal compartment Connection direction Enclosure roof and enclosure base Connection type Cable connection Cable connection cross-sections As per device specifications Position of N/PEN conductor As per expansion of the enclosure Position of the PE conductor...
Page 91: Traversal
H power distribution system Power distribution system enclosures 3.8.14 Traversal Traversal Area of application M-BB without protection device including measurement From M-BB top/middle From M-BB top/bottom From M-BB middle/bottom General characteristic features Enclosure widths [mm] 600 Enclosure heights [mm] 2000...
Page 92 H power distribution system Power distribution system enclosures Characteristic features, traversing M-BB (without protection devices) Enclosure depth [mm] Rated current per rail system initial ≤ 2500 ≤ 3800 feed Rated current I 1 x 60 x 10: 1250 (vertical busbar traversal)
Page 93: U-Bk
H power distribution system Power distribution system enclosures 3.8.15 U-BK Reactive power compensation enclosure Area of application Reactive power compensation up to 400 kvar Choking 5.5 %; 7 %; 14 % Design options Device installation: Withdrawable modules for the reaction power com-...
Page 94 H power distribution system Power distribution system enclosures Field integration unimes H enclosure (with FST-SaS) MES enclosure (without FST-SaS) W x D [mm] 800 x 600 800 x 800 800 x 600 Module type 2 and 3 Expansion Max. 4 modules Max.
Page 95 H power distribution system Power distribution system enclosures Terminal compartment Connection direction Enclosure base Connection type Cable connection Connection cross-sections Up to 2 x (3 x 240 mm²) Position of the PE conductor Front, Cu rail lying Max. installable power loss P...
Page 96: U-Es
H power distribution system Power distribution system enclosures 3.8.16 U-ES Corner enclosure Area of application Main busbar routing for 90° internal corner arrangement Installation options L-shaped arrangement / internal corner arrangement U-shaped arrangement / room arrangement General characteristic features...
Page 97: Active Arc Fault Protection System Agardio.arc
H power distribution system Power distribution system enclosures 3.8.17 Active arc fault protection system agardio.arc Active arc fault protection system agardio.arc agardio.arc Area of application Low voltage unimes H system General characteristic features Enclosure widths [mm] All unimes H enclosure widths...
Page 98: Passive Arc Fault Protection
H system General characteristic features Enclosure widths [mm] 450-1000 (All enclosure widths of unimes H with single doors, no double doors) Enclosure heights (specifications without base) All unimes H enclosure heights Enclosure depths All unimes H enclosure heights Protection type...
Page 99: Earthquake Resistance
Low voltage unimes H system MES-R (empty enclosure) General characteristic features Enclosure widths [mm] 450 - 1350 enclosure widths of unimes H Enclosure heights (specifications with- [mm] 2000 - 2200 enclosure heights of unimes H out base) Enclosure depths [mm] 600 - 800 enclosure depths of unimes H...
Page 100 H power distribution system Power distribution system enclosures Seismic intensities – Richter magnitudes Richter magnitudes Intensity Effects < 2.0 Micro Not felt 2.0 - < 3.0 Minor Usually not felt but measurable 3.0 - < 4.0 Minor Often felt, but very rarely causes damage 4.0 - <...
Page 101: Protective Earth
'upright' refers to the alignment of the main PE (flat or edgeways). Examples for main PE at front, lying The installation position 'front, lying' is possible in all unimes H enclosures. Main PE top, front, lying Main PE bottom, front, lying Examples for main PE at rear, upright In some enclosures, the main PE can also be installed at the 'rear, upright'.
Page 102 H power distribution system Power distribution system enclosures Possible installation positions of the main PE in unimes H enclosures Enclosure type Standard position Alternative position U-PWE Rear, upright Front, lying U-PWK Front, lying U-TE Rear, upright Front, lying U-TK...
Page 103 H power distribution system Power distribution system enclosures Main PE routing in corner enclosure Examples for main PE routing in corner enclosure Main PE bottom, front, lying Main PE top, front, lying 1 Main PE 2 PE transport divider...
Page 104 H power distribution system Power distribution system enclosures Examples of PE traversal Examples of configuration options for traversals. The corresponding drawings and required fixing angles are provided by the configuration tool. The selected busbar routing can be seen in the assembly plan.
Page 105 H power distribution system Power distribution system enclosures Traversal in cable compartment Traversal in corner enclosure It is possible to use an outgoing PE bar of 30x10 mm opposite the main PE in selected enclosures. Outgoing PE bar 30 x10 mm...
Page 106 H power distribution system Power distribution system enclosures Traversal options of the individual enclosure types PE traversal at the front at the front at the rear in the integrated Enclosure in the device in the device cable compart- type...
Page 107 H power distribution system Power distribution system enclosures PE - Outgoing bar in enclosures with integrated cable compartment (KRI) The PE outgoing bar can be mounted at the front or rear in the integrated cable compartment in enclosures with an integrated cable compartment (KRI).
Page 108 H power distribution system Power distribution system enclosures Width 400 mm, 600 mm one main PE at the rear if device outlet is on the right: PE on the right if device outlet is on the left: PE on...
Page 109 H power distribution system Power distribution system enclosures Width 600 mm two main PE at the rear, on the right and left, short version Dimensions: 1 x 30 mm x 10 mm on each side Position recommended for enclosure com-...
Page 110 H power distribution system Power distribution system enclosures PE outgoing bar in the basic enclosure U-BS In basic enclosures without an integrated cable compartment (U-BS), that are only used as a cable enclosure or as a device compartment, PE outgoing bars can be installed for the following configurations.
Page 111 H power distribution system Power distribution system enclosures PE - Outgoing bar in enclosures with combined outgoing top or bottom A combined outgoing top or bottom is possible in some enclosure types. In this case, the main PE is routed to where the main PE of the adjacent enclosures is.
Page 112 H power distribution system Power distribution system enclosures Enclosure divider for PE traversal An enclosure divider with pre-punches is required for the PE traversal, with the standard cut-outs for 1 x 30 mm x 10 mm and 1 x 40 mm x 10 mm copper busbars already in place.
Page 113 H power distribution system Power distribution system enclosures Enclosure divider for traversal at Enclosure divider for traversal at front rear with 1 x 30 mm x 10 mm cop- with 1 x 60 mm x 10 mm cop- per busbar...
Page 114 H power distribution system Power distribution system enclosures Fixing angles Various fixing angles are used for the PE depending on the type of PE and position. Description Reference Main PE at front, lying U-PEBWV Outgoing PE at front/PE traversal at...
Page 115 H power distribution system Power distribution system enclosures PE transport divider The same copper connection can be used at the front and rear for the PE transport divider between two enclosures. The 2200 mm-high modular enclosure univers N U-MUN is an exception with a 60 mm x 10 mm or 80 mm x 10 mm main PE at the rear, upright.
Page 116: Central Earthing Point (Cep) In The Incoming Enclosure U-Te
PE in the incoming enclosure U-TE. The cross section of the CEP connection corresponds to that of the main PE. Restrictions for planning a CEP in the unimes H system: Only possible for ACB 3P+PEN, not possible for 3-pole or 4-pole ACB...
Page 117 H power distribution system Power distribution system enclosures Copper busbar of the main PE The main PE can only be routed at the rear, upright. The version 'main PE at rear, upright, with L bar for the traversal' must be used.
Page 118 H power distribution system Power distribution system enclosures Adjusting the enclosure divider The enclosure divider has pre-punches for the copper busbar dimensions used in the CEP solution: 1 x 30 mm x 10 mm or 1 x 40 mm x 10 mm, 1 x 60 mm x 10 mm, 1 x 80 mm x 10 mm.
Page 119 H power distribution system Power distribution system enclosures Examples with copper busbar 1 x 80 mm x 10 mm CEP fixing angle The same U-PETH angle is used as for the PE traversal at the rear, see PE fixing angle (page 112).
Page 120: Internal Fitting By The Panel Builder
➢ Observe the assembly instructions for expanding the respective enclo- sure types and components (internal separation, for example). For environmental reasons, not all assembly instructions are available in paper form. If required, they can be downloaded from Hager's website or requested from Hager. Chapter index...
Page 121: Material Supply
Internal fitting by the panel builder Material supply Material supply Transport units Hager delivers the enclosures in accordance with customer requirements or internal transport guidelines with the following transport units and packaging materials: Basic system enclosures are usually delivered individually.
Page 122: Mounting The Busbar Supports
Internal fitting by the panel builder Mounting the busbar supports Mounting the busbar supports Busbar supports with wedge U-FSTK. The main busbars are supported by the busbar supports with wedge U-FSTK.. The busbar supports are mounted in the relevant retaining plate for this purpose.
Page 123 Internal fitting by the panel builder Mounting the busbar supports Assemble the U-FSTK and busbar systems The busbar supports are fastened in the support frame of the enclosure using a click system. The upper part of the busbar support is in- serted into the retaining plate for this pur- pose.
Page 124 Internal fitting by the panel builder Mounting the busbar supports Mounting aid The (optional) mounting aid U-MH.. facili- tates the correct positioning of the busbar systems. U-MH60 for enclosure depth 600 mm U-MH80 for enclosure depth 800 mm Technical changes reserved...
Page 125 Internal fitting by the panel builder Mounting the busbar supports Number of flat busbar supports U-FSTK Rated current In of the Mains type H- Quantity and type, Quantity and type, H-SaS [A] enclosure width enclosure width < 850 mm > 850 mm 1250 1-pole 1 x U-FSTK-30-2...
Page 126: Fibreglass Bars To Increase Short-Circuit Resistance
Fibreglass bars to increase short-circuit resistance Increasing the short-circuit resistance of the H-SaS A distinction is made between the different short-circuit resistances of the main busbars in the unimes H power distribution system: without fibreglass bar or with fibreglass bar.
Page 127 Internal fitting by the panel builder Fibreglass bars to increase short-circuit resistance Rated short-time current of the H-SaS > 85 kA Fibreglass bars must be used for a rated short-time current of the H-SaS > 85 kA. Fibreglass bar - Assembly sketch 1 H-SaS without reinforcement max.
Page 128 Internal fitting by the panel builder Fibreglass bars to increase short-circuit resistance Fibreglass bars to support the field connection Fibreglass bars are necessary to support the field connection in specific enclosure types irrespective of the fibreglass bars for increasing the short-circuit resistance of the main busbar system.
Page 129: Connecting The Main Busbars
Internal fitting by the panel builder Connecting the main busbars Connecting the main busbars Transport divider lugs The main busbars are connected via transport divider lugs U-TT/U-TTS or U-TT. Transport divider lugs U-TTS* (set) for main Transport divider lugs U-TTK (set) for main busbars with round perforations/holes.
Page 130 Internal fitting by the panel builder Connecting the main busbars Transport divider lugs U-TT/U-TTS Slot holes on transport divider lugs U-TT/U-TTS make it easier to mount the lugs even in the case of pre-assembled screws. After the access covers have been removed, the screw connection of the transport divider lugs can be accessed from the front also.
Page 131 Internal fitting by the panel builder Connecting the main busbars Check the main busbars ➢ Check that all main busbars are properly seated. ➢ Use a touch-up stick to mark screw connections that have been mounted with the specified tightening torque. ➢...
Page 132: Screwing The Busbar Systems Together
Internal fitting by the panel builder Screwing the busbar systems together Screwing the busbar systems together Screw main busbar to flat Cu busbar 1 Cu flat busbar 10 mm 2 Washer 3 Nut according to DIN EN ISO 8673 (DIN 934) 4 Hexagon screw according to DIN EN ISO 4014 (DIN 931)/ DIN EN ISO 4017 (DIN 933)
Page 133: Screw Connections
Internal fitting by the panel builder Screw connections Screw connections Screw lengths of the H-SaS to F-SaS connection Hexagon screw M12 x ... according to DIN 931/ISO 4014 and DIN 933/ISO 4017 Length for the number of copper busbar(s) Screw length = sCu (H-SaS) + screw connection + 18.5 mm H-SaS H-SaS [A] 1 copper busbar 2 copper busbars...
Page 134: Tightening Torques For Cu Screw Fittings
Internal fitting by the panel builder Tightening torques for Cu screw fittings Tightening torques for Cu screw fittings ➢ The tightening torques listed below must be applied if no specific values are provided for the connection. ➢ Observe the manufacturer's instructions for equipment. Tightening torques for busbar screw connections To DIN 43673 Part 1.
Page 135 Internal fitting by the panel builder Tightening torques for Cu screw fittings Conductor connection terminals for cables and lines that have not been pre-terminated according to DIN 43673 Cross section Clamping screw Screw form Max. min. - max. [mm²] according to tightening tor- que [Nm] 1.5 - 16...
Page 136: Neutral Conductor Routing And Earthing
Internal fitting by the panel builder Neutral conductor routing and earthing Neutral conductor routing and earthing Alternative coppering of the N outgoing bar Additional N outgoing bar An additional N conductor bar can be in- stalled at the rear of the enclosure. It is secured using two holding brackets U-HW and two insulators U-SI410.
Page 137: N Conductor In The Cable Compartment
N conductor in the cable compartment 4.10 N conductor in the cable compartment Depending on the market, Hager provides 2 fastening types for the N conductor in the cable compartment. N/PEN conductor on N/PEN support in the integrated cable compartment For outgoing enclosures with integrated cable compartment, Hager supplies sets with N/PEN bar supports and connection elements for the outgoing N bar.
Page 138 For enclosures with integrated cable compartment, Hager supplies sets with N/PEN bar supports and connection elements as well as insulators for the N/PEN bar. Hager also supplies the cover for the N connection to the H-SaS and the N touch protection as accessories.
Page 139 Internal fitting by the panel builder N conductor in the cable compartment Bushing partitions To avoid the generation of eddy currents in the area of the N connection to the N main busbar, the steel blank partition must be replaced by two bushing partitions made of aluminium.
Page 140 Internal fitting by the panel builder N conductor in the cable compartment Steps for assembling the N/PEN in the integrated cable compartment Steps for assembling the N conductor with N conductor touch protection in the integrated cable compartment. Step Action Mount the N/PEN bar support on fixing angle Tightening torque: 3 Nm...
Page 141 Internal fitting by the panel builder N conductor in the cable compartment Step Action Principle of connecting element 2 x U- AEAN: Connection of 2 copper busbars Tightening torque: 40 Nm Fit the cover cap of the N field connec- tion (optional) Attach the cable lugs to the copper bus- Fasten the touch protection bracket (optional)
Page 142 Steps for assembling N/PE/PEN conductors on insulators Step Action Drill the Cu busbar according to Hager's production drawing Determine the installation height of the Cu busbar Replace the H-SaS partition to the cable compartment on the Cu bushing with bushing partitions and insulating pieces...
Page 143 N conductor in the cable compartment Production drawings for Cu busbar Hager provides the panel builder with enclosure type-specific assembly drawings and individual component drawings for producing the individual copper parts. On receipt of the Cu production drawings, the panel builder can produce the individual Cu parts before the switching enclosures are delivered.
Page 144 Internal fitting by the panel builder N conductor in the cable compartment Determine the installation height of the Cu busbar Installation height of H-SaS at the top (CH, DE, NL) Enclosure front view/enclosure side view: Installation height of the connection to the H- SaS.
Page 145 Internal fitting by the panel builder N conductor in the cable compartment Installation height of H-SaS in the middle (CH, DE, NL) The partition from the H-SaS to the cable compartment is removed and replaced by two bushing partitions with insulating pieces to implement the Cu connection. Technical changes reserved...
Page 146 Internal fitting by the panel builder N conductor in the cable compartment Installation height of H-SaS at the bottom (CH, DE, NL) The second lowest partition from the H-SaS to the cable compartment is removed and re- placed by two bushing partitions with insulating pieces to implement the Cu connection. Technical changes reserved...
Page 147 Internal fitting by the panel builder N conductor in the cable compartment Installation height of H-SaS at the bottom: N in second lowest position (only DE) The lowest partition from the H-SaS to the cable compartment is removed and replaced by two bushing partitions with insulating pieces to implement the Cu connection.
Page 148 Cover the access openings in the retaining plate To meet Form 2b of internal separation, the access openings in the retaining plates must be covered. For enclosure types and enclosure depths (600 mm/800 mm), Hager offers suitable: Blank covers, height = 150 mm Access covers (PC), height = 150 mm.
Page 149: Assembling The Blank Covers And Access Covers (Pc)
Internal fitting by the panel builder Assembling the blank covers and access covers (PC) 4.11 Assembling the blank covers and access covers (PC) Assembling the blank covers and access covers (PC) No tools are required to establish a vibration-resistant connection using the snap elements.
Page 150: Packaging And Transport
5 Packaging and transport Transporting enclosures safely This section provides instructions on packaging and transporting the enclosures of the power distribution system Chapter index Weight specifications Enclosure connections Securing for transport Unloading and transporting Temporary storage Technical changes reserved...
Page 151: Weight Specifications
Packaging and transport Weight specifications Weight specifications Guideline values for weights and maximum dimensions Observe the specified limit values for the weight: A completely filled enclosure weighs 200 to 900 kg. The maximum weight is 1440 kg. The maximum dimensions of a transport unit depend on the ordered enclosure size.
Page 152 Packaging and transport Enclosure connections Enclosure connection with perforated plate or bolt depending on accessibility The internal enclosure connection can be made with enclosure connection plates MES-FV or enclosure connection bolts MES-FVB. The following are required for this: at least 2 x MES-FV or 2 x MES-FVB each at the strut in the front enclosure profile as well as at least 2 x MES-FV or 2 x MES-FVB each at the strut in the middle or rear enclosure profile.
Page 153: Securing For Transport
Packaging and transport Securing for transport Securing for transport ➢ Observe the safety instructions for this section. ➢ Before transporting enclosures mounted in a row, ensure that there are at least 4 suitable internal connections between each enclosure mounted in a row.
Page 154: Unloading And Transporting
Packaging and transport Unloading and transporting Unloading and transporting Observe the instructions in the section "Safety during packaging and transport". The enclosures can be lifted using 2 methods: from above using a crane, ground transport with a forklift, pallet truck or roller devices from underneath. Crane transport ➢...
Page 155 Packaging and transport Unloading and transporting The crane hook is positioned over the centre of grav- ity. When lifting an enclosure with a crane, the enclo- sure hangs in a balanced position on 4 lifting cables, of the same length where possible, at an angle of at least 45°...
Page 156 Packaging and transport Unloading and transporting Permissible load with combination lifting lug MES-KT at an angle of inclination of 30°/lifting cable angle 60°: the outer enclosures: 500 kg max., the inner enclosure: 1000 kg max. Lifting an enclosure combination consisting of 3 enclosures with internal connections and connections at the top via combination lifting lugs MES-KT.
Page 157: Temporary Storage
The user determines special requirements for the storage packaging according to DIN EN 61439-1, supplementary sheet 1, section 10.5, if there are special application requirements. Hager recommendations: Use undamaged transport packaging until the final assembly at the installation site. Precautionary measures prior to subsequent transport During subsequent transport: ➢...
Page 158: Installation And Assembly
6 Installation and assembly Assembly at the installation site Instructions for setting up and mounting the installed enclosures at the installation site. Chapter index Requirements and preparations Setting up and securing the switching enclosures Technical changes reserved...
Page 159: Requirements And Preparations
Installation and assembly Requirements and preparations Requirements and preparations Requirements Level and load-bearing installation surface In case of unevenness, use U profiles or I profiles or the optionally available base levelling set mes-NIV. Clean and dry installation site; if necessary, apply a dust protection floor coating to the floor.
Page 160: Setting Up And Securing The Switching Enclosures
Installation and assembly Setting up and securing the switching enclosures Setting up and securing the switching enclosures Setting up and securing the switching enclosures Various options are possible for setting up and securing the enclosures: Floor mounting Mount with screws and dowels or anchor bolts on the base corner piece Mount with additional floor mounting lug MES-BBL for easier access Mount with additional base levelling unit MES-NIV to level differences in height...
Page 161 Installation and assembly Setting up and securing the switching enclosures Setting up and aligning the first enclosure Step Action Set up the first enclosure. The first enclosure is the outer enclosure on the left or right. Fasten the first enclosure to the floor before you line it up to the following en- closure.
Page 162 Installation and assembly Setting up and securing the switching enclosures Connecting the second enclosure Step Action Transport the next enclosure in the planned order for assembly at the installa- tion site. Fasten the second enclosure to the floor. When fastening, make sure the en- closure is vertically aligned.
Page 163: Installation And Connection
7 Installation and connection Work for electricians The electrical installation and connection to the mains is carried out by an electrically skilled person or an electrically skilled person with special training. Chapter index Cable routing Compliance with EMC rules Measures to ensure EMC-compliant installation Take into account stray currents Avoiding stray currents Technical changes reserved...
Page 164: Cable Routing
Installation and connection Cable routing Cable routing Cable entry into the enclosure The cables fed from the outside are fastened via cable clamp rails MES-CPSTB.. or C profiles, which are secured to the mounting brackets MES-BEB. Fastening of cables via cable clamp rails Two cable entry positions are possible based on the different installation options of the mounting brackets MES-BEB: Straight cable entry...
Page 165 Installation and connection Cable routing Flexible connection options for incoming cables When connecting incoming cables, you have a flexible choice of 3 positions in the rear of the enclosures based on the arrangement of the main busbar system. Cable clamp rails for strain relief can be assembled at any location based on the arrangement of the H-SaS: in the base, at the bottom or rear enclosure frame or...
Page 166: Compliance With Emc Rules
Installation and connection Compliance with EMC rules Compliance with EMC rules When installing ready-to-connect switchgear and controlgear assemblies, electromagnetic compatibility must be ensured. The electrician must observe the known installation regulations as well as the manufacturer's regulations. This is done to rule out mutual interference of the installed equipment and the immediate surroundings.
Page 167 Installation and connection Compliance with EMC rules Testing and verifying immunity and interference EMC requirements must be verified by tests in accordance with the EN 61439 standard for finished switchgear and controlgear assemblies. Installed operating equipment must be designed according to the defined environment (environment A or environment B) with regard to its immunity.
Page 168: Measures To Ensure Emc-Compliant Installation
Implementing the spatial separation of EMC areas Spatial separation of the EMC areas in the switching enclosure is beneficial. With its clear spatial distribution, the unimes H power distribution system supports the functional and spatial separation of the functional areas. Make sure to divide into different EMC areas of different power/interference levels in the enclosure.
Page 169 Installation and connection Measures to ensure EMC-compliant installation Line routing and cabling ➢ Spatially separate the different line groups. ➢ Route the lines that are susceptible and sensitive to interference sepa- rately. Avoid routing the lines that are susceptible and lines that are sensitive to interference in one cable compartment.
Page 170 Installation and connection Measures to ensure EMC-compliant installation Integrate the cable ducts in the equipotential bonding system Metallic cable ducts that are integrated in the equipotential bonding system between two switching enclosures must be unpainted, metallic bare connections fixed directly on the switching enclosure. Metallic cable ducts must be conductively connected and fastened.
Page 171: Take Into Account Stray Currents
Installation and connection Take into account stray currents Take into account stray currents Currents that do not flow over the electrical supply network L1 – L3 and N/PEN during normal operation are referred to the stray currents. Impairment of property protection due to stray currents Stray currents impair property protection due to corrosion, pitting, transmission of interfering magnetic fields,...
Page 172: Avoiding Stray Currents
Installation and connection Avoiding stray currents Avoiding stray currents Avoiding stray currents Stray currents can be avoided by selecting the right network system and corresponding earthing concept based on the transformer star point. For reasons of personal and property protection, the PE in the switchgear should be connected to the earthed parts as often as possible.
Page 173 Installation and connection Avoiding stray currents TN-S network system with an insulated PEN installed with single supply TN-S system with an insu- lated PEN installed: Recommended for new systems No stray currents A bridge (1) marked green/yellow between the insulated PEN and PE anywhere in the switchgear is the central earthing point (CEP).
Page 174 Installation and connection Avoiding stray currents TN-S network system with multiple incoming units TN-S system: Recommended condi- tionally Stray currents are only avoided with 4-pole switches/circuit break- ers in the incoming unit and coupling TN-S system with an insulated PEN installed TN-S system with an insulated PEN installed: Recommended...
Page 175: Commissioning
8 Commissioning Experienced electrically skilled person Commissioning instructions are provided in this section. Chapter index Commissioning safety instructions Instructions for commissioning Final commissioning work Technical changes reserved...
Page 176: Commissioning Safety Instructions
Some initial tests require special training with verification according to national regulations. This applies to specific components such as air circuit breakers for example. Hager offers a maintenance service that can also include commissioning services. Qualified Hager service technicians or Hager-licensed...
Page 177: Instructions For Commissioning
Commissioning Instructions for commissioning Instructions for commissioning Check connections and tightening torques ➢ Check the stability of all connections and tightening torques: of the electrical connections, of the mechanical connections, of the switching enclosure fastenings. The tightening torques of the operating equipment and at the connections of the installed devices are determined by the manufacturer's instructions.
Page 178 Commissioning Instructions for commissioning Initial commissioning after testing and inspection WARNING Risk due to electric shocks, arc faults, burns or explosions. Due to undetected errors, the first time the system is switched on can be dangerous. It may result in serious bodily injuries or death.
Page 179 ➢ The panel builder can find planning instructions and checklists for the declaration of conformity as well as a writeable record for the routine verification in the Hager guidelines for 'Project planning and design of switchgear according to DIN EN 61439 (VDE 0660-600)'.
Page 180: Final Commissioning Work
Commissioning Final commissioning work Final commissioning work Perform sealing measures ➢ Perform sealing measures to meet the required protection type. ➢ Carry out corrections as necessary. Complete installation work ➢ At the end of the installation work, perform cleaning and another visual in- spection.
Page 181: Control And Operation
9 Control and operation Not to be operated by ordinary persons This section provides instructions on control measures, operation and faults occurring during operation. The switchgear and controlgear assembly is not intended to be operated by ordinary persons. Chapter index Personnel requirements Operating protective devices under loads What to do in the case of faults...
Page 182: Personnel Requirements
Control and operation Personnel requirements Personnel requirements Operation of the systems Operation includes all activities that are necessary for the electrical system to function. This includes: Switching, Monitoring, Performing tests and configuring settings, Repair and electrotechnical and non-electrotechnical work. Control Controlling electrical systems and electrical operating equipment includes activities such as: Observation,...
Page 183: Operating Protective Devices Under Loads
Control and operation Operating protective devices under loads Operating protective devices under loads WARNING Risk due to electric shocks, arc faults, burns or explosions. Unauthorised, accidental or careless switching can result in serious accidents. They may result in serious bodily injuries or death. ➢...
Page 184: What To Do In The Case Of Faults
Hager customer service This manual is not to be considered as work instructions for performing major repair work. Hager customer service or a Hager-licensed panel builder sales partner will be happy to perform this work for you. If errors occur, please contact the local Hager office for this.
Page 185: Cleaning
Control and operation Cleaning Cleaning For operational safety reasons, contamination or pollution must be removed. During cleaning, observe at least the following safety points: Cleaning work performed on disconnected systems by an electrically skilled person Cleaning work must be performed by electrically skilled personnel. Electrotechnically instructed personnel must have been specially trained for cleaning work and it must be ensured that work is performed in a voltage-free state.
Page 186: 10 Inspection And Maintenance
10 Inspection and maintenance Important information for safe operation This section provides information on inspection, maintenance and recurring tests. Preventive maintenance is important for the safe operation of power distribution systems. Chapter index Requirements of personnel for inspection and maintenance Testing intervals for recurring tests Test scope Testing the installed components...
Page 187: Requirements Of Personnel For Inspection And Maintenance
This applies to specific components such as air circuit breakers for example. Hager offers a maintenance service by qualified service technicians. If you are interested, please contact your local Hager office. Electrically instructed personnel may only perform tests under the direction and supervision of an electrically skilled person if the measuring and test devices are available for the measurement and testing tasks.
Page 188: Testing Intervals For Recurring Tests
Hager recommends performing the following at least once a year: a visual inspection (external inspection), switching operations of the individual protection devices and switchgear, document all tests, for example, in an inspection book.
Page 189: Test Scope
Test scope 10.3 Test scope The following minimum maintenance conditions must be met in the unimes H power distribution system (based on VDE 0100 Part 610 for switchgear and controlgear assemblies): The recurring tests during commissioning, in the event of changes, after faults or...
Page 190 ➢ Perform measurements and control tests according to the switching doc- uments. Hager Service In order to ensure its systems operate with a high degree of reliability, Hager offers a maintenance and service concept implemented by qualified service Technical changes reserved...
Page 191 Inspection and maintenance Test scope technicians that conforms to standards. These services include commissioning, conversion and maintenance. ➢ Contact your local office about this. Technical changes reserved...
Page 192: Testing The Installed Components
➢ Check the effectiveness of the protective earth connection. Hager recommends switching the system on and off at least once a year for ACBs and MCCBs. We recommend: Check the casing, the load break switches (HRC strips)
Page 193 Inspection and maintenance Testing the installed components Impairment/damage What to do? (The minimum instructions to be ob- served) Mobility of the withdrawable part of the Remove dust, lubricate rail guides with water- load break switches damaged repellent, anti-corrosion and lubricating agent Test the load break switches/NH fuse switches Impairment/damage What to do?
Page 194: Test The Acb And Mccb
Inspection and maintenance Testing the installed components Check the HRC blade fuse links Impairment/damage What to do? (The minimum instructions to be ob- served) Fuse links are not positioned correctly Position correctly or insert new fuse links Fuse link does not correspond to the ap- Replace the fuse link to suit the application plication External damage to a fuse link...
Page 195: 11 Storage, Decommissioning And Disposal
11 Storage, decommissioning and disposal Decommissioning, recycling Observe the instructions in this section for storage, decommissioning and disposal. Chapter index Personnel requirements Decommissioning Storing switching enclosures and components Disposal and recycling Technical changes reserved...
Page 196: Personnel Requirements
Storage, decommissioning and disposal Personnel requirements 11.1 Personnel requirements Switchgear and controlgear assemblies and individual enclosures must only be decommissioned by electrically skilled personnel and electrotechnically instructed personnel. Decommissioning requires: precise knowledge of the work assigned by an electrically skilled person, precise knowledge of possible hazards in case of improper behaviour, precise knowledge of the necessary protection devices and protective measures.
Page 197: Storing Switching Enclosures And Components
The user determines special requirements for the storage packaging according to EN 61439-1, supplementary sheet 1, section 10.5, if there are special application requirements. Hager recommendations: Use undamaged transport packaging until the final assembly at the installation site. Precautionary measures after storage During subsequent transport: ➢...
Page 198: Disposal And Recycling
Storage, decommissioning and disposal Disposal and recycling 11.4 Disposal and recycling Recycling HRC fuses Worn-out HRC fuses contain valuable materials even after disconnection. We recommend: Dispose of worn-out HRC blade fuse links via the appropriate recycling system. The HRC/HH recycling system in Germany or similar systems in other countries is suitable for this, for example.
Page 199: 12 Technical Data
The technical data listed may change as part of the ongoing development of Hager products. Technical data for enclosure types The technical data for the unimes H system enclosure types are listed with the description of the corresponding enclosures. Current technical data The current technical data can be viewed on the Hager homepage.
Page 200: General Data
Technical data General data 12.1 General data General characteristic features of the switchgear and controlgear assembly interfaces Degree of pollution Rated insulation voltage U 250 V 250 V 250 V 250 V Material group IIIa IIIb Minimum creepage distances 3.2 mm 3.6 mm 4 mm 4 mm...
Page 201 Technical data General data Service index Plug-in technology 221 Insertion technology 332 Explanation: Position 1, operation Position 2, maintenance Position 3, expansion 1 = Switch off complete system 2 = Switch off relevant functional unit 3 = Switch off relevant functional unit FU, test in test position Type of short-circuit protective devices Distribution and final circuit: Circuit breaker or fused devices...
Page 202: Main Busbar System (H-Sas)
Technical data Main busbar system (H-SaS) 12.2 Main busbar system (H-SaS) H-SaS components in the basic enclosure Enclosure depth 600 mm Enclosure depth 800 mm (2 x Cu for each terminal) (4 x Cu for each terminal) Retaining plate Busbar support U- FSTK.. for main busbars of the main busbar system H-SaS Main busbars/busbars of the H-SaS 2 x Cu for each terminal (enclosure depth 600 mm): Rated current I max.
Page 203 M12 screws Advantages of the H-SaS connection technology The easy connection (coupling) of the main busbars in the unimes H power distribution system offers several advantages: Easy and time-saving bar assembly...
Page 204 Technical data Main busbar system (H-SaS) Phase positions of the H-SaS NOTICE Up to three main busbar systems can be installed at the same time, but only a maximum of two main busbar systems may be loaded at the same time. System enclosures - Examples Basic enclosure U-BS Basic enclosure U-BSI...
Page 205 Technical data Main busbar system (H-SaS) Arrangement of the main busbars The rated current I determines the necessary enclosure depth and arrangement of the main busbars. With rated currents of 2950 A and higher, enclosure depths of 800 mm with 4 Cu busbars per terminal are used for the main busbar system. H-SaS positions for enclo- H-SaS positions for sure depth 600 mm...
Page 206 Main busbars without/with perforation(s) for fibreglass bars H-SaS reinforced with fibreglass bar (FG) A distinction is made in the unimes H power distribution system between the different short-circuit resistances of the main busbars: without reinforcement from additional fibreglass bars or with reinforcement from additional fibreglass bars.
Page 207 Technical data Main busbar system (H-SaS) Perforations for fibreglass bar for transport divider lugs U-TT/U-TTS (examples) Perforations for fibreglass bars for compact transport divider U-TTK (examples) Examples of production drawings: In this case, Cu 80x10 with fibreglass bar perforation(s) for transport divider lugs U-TT/U- TTS as well as for compact transport divider U-TTK A: Length B: Distance to the middle hole for the left/middle fibreglass bar...
Page 208 Technical data Main busbar system (H-SaS) TN-C TN-S Overview of busbar system routing according to the type of low-voltage network/ type of earth connection Technical changes reserved...
Page 209: Spatial Distribution Data
Spatial distribution data Installable devices in the device compartment A wide range of devices can be installed in the type-tested unimes H power distribution system, thus enabling the easy implementation of switchgear and controlgear assembles in accordance with EN 61439-1/-2. Using the CE declaration of conformity of the original manufacturer, Hager, reduces the effort required to prepare the CE declaration of conformity.
Page 210 Technical data Spatial distribution data Terminal compartment data Position of cable connection Depending on the enclosure type: top, bottom, left, compartment right Enclosures with integrated ca- U-BSI, U-SI, U-CWI ble compartment (KRI) Connection direction Enclosure roof or enclosure base, cable compartment Horizontal device installation: at the rear Position of outgoing N/PEN Vertical device installation: top or bottom...
Page 211: Distribution Busbars
Processing time optimised by production drawings Hager provides the panel builder with enclosure type-specific assembly drawings and individual component drawings for producing the individual copper parts. On receipt of the Cu production drawings, the panel builder can produce the individual Cu parts before the switching enclosures are delivered.
Page 212: Post Insulators
Technical data Distribution busbars 12.4.1 Post insulators Post insulators for field connections Post insulators U-SI410 are assembled to the short-circuit-proof busbars of the field connections. The post insulators are secured onto holding brackets for insulators U-HBFI.. or with holding plates U-HPL. U-TE: Number of insulators U-SI410 ACB 3-pole ACB 3-pole+N...
Page 213: Characteristics Of The Sk For Connecting To The Mains
Technical data Characteristics of the SK for connecting to the mains 12.5 Characteristics of the SK for connecting to the mains Characteristics for the SK for connecting to the electrical system Rated values for voltages Rated voltage U [V AC] ≤ 690 Rated operational voltage U [V AC] ≤...
Page 214: N/Pen Conductor On N/Pen Support In The Integrated Cable Compartment
Installation in the cable com- Left rear partment Field connection Fastening angle of H-SaS to N/PEN conductor in the ca- ble compartment in the unimes H system Material Flat copper Cu-ETP R240 Form of internal separation 1, 2b Electrical data...
Page 215: N/Pe/Pen On Insulators In The Integrated Cable Compartment
Technical data N/PE/PEN on insulators in the integrated cable compartment 12.7 N/PE/PEN on insulators in the integrated cable compartment Assembly on 4 N/PE mounting plates with an insulator Usage (DE) In enclosures with an integrated cable compartment In enclosures without an integrated cable compart- ment In separate enclosure U-BS Enclosure height...
Page 216: Continuous Current And Current Heat Losses Of Cu Conductors H-Sas
Technical data Continuous current and current heat losses of Cu conductors H-SaS 12.8 Continuous current and current heat losses of Cu conductors H-SaS Continuous current and current heat losses of Cu conductors: without reinforcement* Cu ETP-R240 [kA] (1 s) [kA] (e-Cu57 F25) (per terminal) for H-SaS support U- Without Without...
Page 217 Technical data Continuous current and current heat losses of Cu conductors H-SaS Continuous current and current heat losses of Cu conductors: with reinforcement* Cu ETP-R240 [kA] (1 s) [kA] (e-Cu57 F25) (per terminal) for H-SaS support U- With reinforce- With reinforce- FSTK ment ment...
Page 218: Reduction Factors
Technical data Reduction factors 12.9 Reduction factors Current reduction at an increased ambient temperature Reduced heat dissipation (lower temperature difference) Average values of switchgear and low-voltage switchgear Ambient temperature/reduction factor 35°C 40°C 45°C 50°C 55°C 0.95 0.85 Current reduction for altitudes > 2000 m above sea level Reduced heat dissipation (lower temperature difference) Average values of switchgear and low-voltage switchgear Altitude above sea level/reduction factor...
Page 219: 13 Appendix
Appendix 13 Appendix Abbreviations Abbreviation Description Air Circuit Breaker Type designation of the overcurrent relay, integrated into the ACB tempower2 Position signalling switch cos φ Phase shift Current Transformer Drawable, (a plug connection that can be released without the use of tools), see glossary for explanation Low voltage switchgear and control gear assemblies in accordance with DIN EN 61439-1/-3...
Page 220 ACB tempower2 TP2-TF Door flange for ACB tempower2 Type-tested low voltage switchgear and controlgear assembly System enclosure unimes H U-LE unimes H system enclosure for incoming and outgoing units, with LBS switch disconnector Technische Änderungen vorbehalten...
Page 221 H system enclosure: Double incoming / outgoing or coupling enclosure with the option of installing a double incoming unit, with ACB switch disconnector U-TE unimes H system enclosure for incoming and outgoing units, with ACB switch disconnector U-TK unimes H system enclosure: Coupling enclosure with cross cou-...
Page 222 Appendix Important formula characters first mentioned in EN 61439-1 Abbreviation Description Standard section EN 61439-1 Comparative tracking index 3.6.16 Low voltage 3.7.11 Electromagnetic compatibility 3.8.13 Rated frequency 3.8.12 Short-circuit current 3.8.6 Conditional short-circuit current 3.8.10.4 Prospective short-circuit current 3.8.7 Rated short-time current 3.8.9.3 Rated current 3.8.10.1...
Page 223: 14 Glossary
Glossary 14 Glossary Air circuit breaker (ACB). Compared to compact circuit breakers (MCCB = Moulded-Case Circuit Breaker), air circuit breakers have a larger volume and are designed for higher rated currents. A circuit breaker is a mechanical switchgear unit that can switch on, route, and switch off currents in the circuit under operating conditions.
Page 224 They determine the short-circuit resistance and thus the operational safety of a low-voltage switchgear and controlgear assembly. The busbar systems of the unimes H power distribution system can be designed with standard Cu busbars. The drill-free connection technology reduces workloads and thus saves time and costs.
Page 225 Terminal compartment. The connection points of the outer conductors/cables (interfaces) are located in the cable compartment. Some enclosure types of the unimes H power distribution system are provided as versions with an integrated cable compartment to the left or right of the device compartment.
Page 226 Glossary Distribution busbar system (F-SaS) Field distribution busbar system (F-SaS). Distribution busbars establish the connection between busbars of the main busbar system and the installed devices. The distribution busbar system F-SaS includes the busbar supports (F- SaS supports) and fastening and partition accessories in a field. Earthing connection The earthing connection includes all inactive conducting parts, such as casings, support rails, DIN rail, etc., which do not create a protective earthing connection...
Page 227 Glossary Supplements for parts of the EN 61439 standard Part of Content European standard EN 61439-1 General rules: Supplement 1 Guidance to specifying assemblies EN 61439-1 General rules: Supplement 2 A method of temperature-rise verification of low-voltage switchgear and controlgear assemblies by calculation EN 61439-2 Power switchgear and controlgear assemblies: Supplement 1...
Page 228 Glossary Hazard zone According to DIN VDE 0105-100, the hazard zone is an area around live parts in which the required insulation level is not ensured. When entering this area, there is the risk of electric current passing through the human body and/or arcing. All work preformed in the hazard zone must satisfy the conditions for work under voltage.
Page 229 Multi-pole busbar system that is routed in the enclosure of a switchgear and controlgear assembly. The main busbars of the enclosures of the power distribution system unimes H are connected via transport divider plates U-TT (U- TTS as a set) or the compact transport divider U-TTK. Distribution busbars can be connected to the main busbars.
Page 230 Range of components, according to the definition of the original manufacturer, that can be installed for different switchgear and controlgear assemblies in compliance with the manuals of the original manufacturer. The unimes H power distribution system is a type-tested switchgear and controlgear assembly for switchgear and controlgear assemblies according to EN 61439-1/-2.
Page 231 Glossary At the test position, the auxiliary circuit is connected in such a way that the integrated devices can be tested. At the test position, the withdrawable part is connected mechanically with the switchgear and controlgear assembly. Transport unit Complete switchgear and controlgear assembly or a part of a switchgear and controlgear assembly, which is not dismantled further or disassembled for transport.
Page 232 Glossary hoisting or lowering tools or material. Withdrawable part On power switchgear and controlgear assemblies, a withdrawable part is a removable part that can be moved from operating position to a disconnected position or a test position. It remains mechanically connected to the switchgear and controlgear assembly.
Page 233: 15 Index
Busbar support SST / F-BB support • 222 Instructions for commissioning • 175 Busbar system (SaS) • 222 Intended use of the unimes H system • 19 Internal fitting by the panel builder • 118, Cable compartment • 223 158, 160, 175, 205 Cable routing •...
Page 234 U-LE / U-LK 2000-2500 A • 72 Project planning • 119 U-MUN • 86 Project planning and constructing power unimes H power distribution system • 34 switchgear • 16 Unloading and transporting • 152 Protective earth • 99 U-PWE/U-PWK 630-4000 A • 58 Protective earthing connection •...
Page 236 Hager AG Chemin du Petit-Flon 31 1052 Le Mont-sur-Lausanne Switzerland Tel. +41 21 644 37 00 lausanne@hager.com hager.ch Hager Vertriebsgesellschaft mbH & Co. KG Zum Gunterstal 66440 Blieskastel Germany Tel. +49 6842 945 0 Fax +49 6842 945 4625 hager.de Hager Polo Sp.

hager unimes H System Manual

1 About this System Manual

2 Safety

3 Unimes H Power Distribution System Introducing the System

4 Internal Fitting by the Panel Builder

5 Packaging and Transport

6 Installation and Assembly

7 Installation and Connection

8 Commissioning

9 Control and Operation

10 Inspection and Maintenance

11 Storage, Decommissioning and Disposal

12 Technical Data

13 Appendix

14 Glossary

15 Index

Quick Links

Need help?

Questions and answers

Related Manuals for hager unimes H

Summary of Contents for hager unimes H

Table of Contents
