National Luna Classic Range 40 Owner's Handbook Manual

Portable refrigerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
P OR TAB L E R E F R IGE RATOR
F or m o de ls ma nu fa ct ure d fro m 2 0 0 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Classic Range 40 and is the answer not in the manual?

Questions and answers

Related Manuals for National Luna Classic Range 40

Summary of Contents for National Luna Classic Range 40

  • Page 1 P OR TAB L E R E F R IGE RATOR F or m o de ls ma nu fa ct ure d fro m 2 0 0 9...
  • Page 2 The National Luna range of products have been designed and manufactured in South Africa since 1989. Every product sold is of the highest possible quality, manufactured with world-class technology, marketed & serviced by a knowledgeable & dedicated team, locally & internationally This manual / handbook is a combined publication, for models manufactured from 2009.
  • Page 3 Setting the Temperature Celsius / Fahrenheit Conversion Chart Speed Control Battery Protection 11/12 National Luna Classic Range National Luna Double Door and Twin Range (Dual Control) National Luna Weekender Range Troubleshooting General Maintenance National Luna Warranty - South Africa Only - International...
  • Page 4 The versatility of each of the National Luna models allows the use of a wide range of AC supply voltage (85V DC - 265V AC) as well as 12-volt or 24-volt battery power (9.6V AC - 31.5V DC).
  • Page 5 Securing your fridge in a vehicle using a Base Mounting Plate A low-profile design with locking pin, this base offers a fixed mounting position with an easy to remove mechanism. The optional base mounting plate allows the refrigerator to be securely fastened to the floor or body of the vehicle.
  • Page 6 Installation guidelines When installing the refrigerator into a vehicle for the first time, ensure that the electrical connections to the vehicle’s battery are secure and the specified wiring is used. (See wiring guidelines on page 7) The fridge is supplied with a pre-made cable for use with a 12 / 24-volt DC supply. This cable is terminated with a high-quality male plug for connection into your vehicle.

  • Page 7: Connecting Power

    Connecting power All National Luna Portable refrigerators can accept a DC voltage ranging from 9.6V to 31.5V, as well as Fuse (15amp) an AC voltage range from 85V to 265V. Both power inputs are fuse protected : - 3.15A Time-lag fuse for AC input.
  • Page 8 To control temperature, the thermostat sensor must be placed in a position in order to take a tempera- ture reading. For practical purposes National Luna has elected to place this temperature sensor on the metal surface forming the interior bin of the fridge/freezer. Thus the switching on and off of the compressor will be controlled by the bin surface area temperature.

  • Page 9: Setting The Temperature

    Setting the Temperature The digital thermostat fitted to the National Luna Portable refrigerator allows accurate setting of the desired cooling temperatures. With the single compartment refrigerators, temperatures can be selected between +20°C and -30°C in 1°C increments. When powering up the fridge the first time, the temperature inside the fridge will be reflected on the display.

  • Page 10: Speed Control

    Introduction to Smart Compressor Speed Control National Luna developed a Smart Compressor Control ( advanced automatic speed control) function which has been fitted as standard to all current models. • Logic 1 (Setting the bin temperature in a range of +20ºC to -11ºC).
  • Page 11 Battery Voltage vs Capacity • Voltage of a battery can be an indication of its “state-of-charge”. • The voltage-capacity relationship is most accurate when the fridge is not running and the battery temperature is at 25°C. • By measuring the voltage, we can estimate the amount of energy remaining in the battery.

  • Page 12: Battery Protection Settings

    Battery Protection Settings The refrigerator is equipped with a multi-level battery protection circuit. The user has the choice of three voltage levels at which the compressor will shut down to protect against excessive battery discharge. (See page 11) To change the protection level, press and hold button until the preferred level is reached.

  • Page 13: National Luna Classic Range

    National Luna Classic Range 40/55/65/80/125 Introduction Developed for performance at high ambient temperatures, minimum power consumption and high operating efficiency, these single compartment fridges are recognised as the most powerful in the world. Low power consumption is achieved using 60mm high-density insulation and a very compact design.

  • Page 14: Control Panel

    Control Panel Automatic speed control with TURBO over-ride Fault identifier light Run status light Power ON/OFF and temperature UP control Temperature display SET mode and temperature DOWN control Battery protection control On / Off control The refrigerator can be turned the control panel.
  • Page 15 (During this time the run indicator light will be displayed). Speed Control National Luna refrigerators have an advanced speed control which will vary the speed of the compressor in order to conserve power and optimise performance.
  • Page 16 Introduction The Double door and Twin fridges in this range have only one compressor, but due to National Luna’s unique Dual Control technology, the fridge and freezer compartments can be set independently. This is like having two fridges in one.
  • Page 17 60/90 Twin The Twin has one lid covering both compartments. By reducing the fridge side insulation to 42mm thickness, National Luna offers a fridge/ freezer to meet the demand for maximum fridge capacity where space is limited. The freezer compartment has a separate internal lid. This prevents cold air escaping from the freezer when the main lid is opened, adding to the efficiency and ensuring stable temperatures within.
  • Page 18 To change the protection level, press and hold button until the preferred level is reached. (Refer to page 11 and 12). National Luna refrigerators have an advanced Speed Control speed control which will vary the speed of the compressor in order to conserve power and optimise performance.
  • Page 19 Setting the Temperature NB - Set one thermostat at a time Model 60/72/90/110 Refrigerators have dual thermostats allowing individual temperatures to be selected for each of the cooling bins. The “ ” bin has a temperature range between +20°C and -24°C. FREEZER The “...
  • Page 20 The National Luna Weekender is a high-performance, low-power portable refrigerator designed primarily for use in mobile applications. By reducing the insulation to 42mm thickness, National Luna offers a lightweight fridge/freezer to meet the demand for maximum fridge capacity where space is limited.
  • Page 21 52 Single Bin This model has been designed to operate as a fridge or freezer and the bin temperature can be set between +20°C and - 30°C. Weekender 52 1. Lid 2. LED Interior light 3. Lid locking latches 4. Cabinet exterior 5.
  • Page 22 Speed Control National Luna refrigerators have an advanced speed control which will vary the speed of the com- pressor in order to conserve power and optimise performance.
  • Page 23 Setting the Temperature - 50 Twin The digital thermostat fitted to the National Luna Portable refrigerator allows accurate setting of the desired cooling temperatures in the left hand fridge bin. (40 Litres) Bin temperatures can be selected between +20°C and -12°C in 1°C increments. When powering up the fridge, the temperature inside the fridge will be reflected on the display.
  • Page 24 Setting the Temperature - 52 The digital thermostat fitted to the National Luna Portable refrigerator allows accurate setting of the desired cooling temperatures. With the single compartment refrigerators, temperatures can be selected between +20°C and -30°C in 1°C increments. When powering up the fridge, the temperature inside the fridge will be reflected on the display.
  • Page 25 Battery Monitor and Protection The Weekender is equipped with a battery monitor and low-battery “cut-out” protection circuit. The monitor is intended to give an estimate of the available remaining energy in a 12-volt lead-acid battery. (For 24V systems the indicated battery voltage should be multiplied by two). The battery monitor has a built-in low voltage alarm which provides audible warning of a low-battery condition.
  • Page 26 Dual-direction Lid A special feature of the Weekender is the ability to change the direction in which the lid opens. The most common configuration is the front-opening direction (shown). If the application prevents the lid from opening fully or the refrigerator is installed long ways into a vehicle, it may be advantageous to use the side-opening configuration.

  • Page 27: Troubleshooting

    Ambient temperature very high. Wait for ambient temperature to Fridge over-loaded. drop. (See page 12) The thermostat display is The internal temperature probe is Contact a National Luna service showing “ Prf “ faulty, damaged or agent for a probe replacement. disconnected.

  • Page 28: General Maintenance

    General Maintenance Disconnect the Power Supply Failure to disconnect the power supply may result in electrical shock or personal injury. Removal of Side Cover Tip refrigerator so as grill area is at the top. (Pic 1) Remove screws from base plate (6xM5 screws) and from the face plate (4xM3 screws - Pic 2) Then from the power inlet area (2xM3 screws - Pic 3) The grill will now slide away easily.
  • Page 29 (Pic 18). One can clean the gasket and place it in the sun to soften the material. It can also be softened using a hair dryer to attain it’s uncompressed state. The National Luna refrigerators utilise a multi-cavity door seal which gives exceptional sealing capability. Under hot conditions, and after loading the fridge, the door could be “sucked”...
  • Page 30 10. National Luna shall not be held responsible for any injuries to persons caused by the incorrect or negligent usage of this appliance. 11. Repair work to be done in terms of this warranty must be referred to National Luna for written authorisation before any work is carried out.
  • Page 31 Any labour repairs and parts required would incur costs in foreign currency and be for the owner’s account. In the event of a National Luna refrigerator being fitted as standard equipment in caravans and trailers and subsequently being exported from South Africa, the warranty must be carried by the persons responsible for importing into a country other than South Africa.

  • Page 32: Care And Cleaning

    Occasionally the use of a fine synthetic scourer (green “Scotch-Brite”™) or a brush with nylon bristles may be used. Rinse well, dry with a soft cloth. www.nationalluna.com National Luna - South Africa Tel : +27 (0)11 452-5438 Fax : +27 (0)11 452-5263...
