CPAT FLEX DSG1 Lite User Manual

Digital signal generator
Hide thumbs Also See for DSG1 Lite:
Table of Contents

Advertisement

Quick Links

Download this manual
Please direct all questions to your local CPAT Flex sales office representative, or
distributor, or contact CPAT Flex technical support at:
Copyright 2024 CPAT Flex Inc. All rights reserved.
DSG1 Lite
Digital Signal Generator
www.cpatflex.com.
usermanual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSG1 Lite and is the answer not in the manual?

Questions and answers

Related Manuals for CPAT FLEX DSG1 Lite

Summary of Contents for CPAT FLEX DSG1 Lite

  • Page 1 DSG1 Lite Digital Signal Generator Please direct all questions to your local CPAT Flex sales office representative, or distributor, or contact CPAT Flex technical support at: www.cpatflex.com. Copyright 2024 CPAT Flex Inc. All rights reserved.
  • Page 2 CPAT Flex accepts no liability for any omissions or errors present in this document or for any damages that may arise from the utilization of the information provided herein.

  • Page 3: Table Of Contents

    1.2 Explanation of Symbols Used 1.3 Certifications 1.3.1 Test Specifications 1.3.2 Compliance 1.3.3 Note 1.4 Technical Support 1.5 Calibration 1.6 CPAT Flex Web Site 2. System Components 2.1 Product Overview 2.2 Initial Verification 3. Setup 4. System Operation 4.1 Power On 4.2 LED Information...
  • Page 4 Lite DSG1 GettingStartedManual2024-07-23V1.4 Appendix B – Our Services B.1 Customer Support B.1.1 Equipment Return Instructions B.2 Limited Product Warranty B.2.1 Hardware B.2.2 Software B.2.3 Exclusions B.2.4 Refurbished Parts and Prior Testing B.2.5 Exclusive Remedies B.2.6 Disclaimer...

  • Page 5: General Information

    Use of this product other than for its intended application may compromise the unit’s safety features. 1.2 Explanation of Symbols Used The following symbols are used on the DSG1 Lite label and in this Manual: Direct current (DC) Caution. Indicates that operations or procedures, if carried out without caution, may cause personal injury or damage to the unit.

  • Page 6: Note

    1.5 Calibration Your DSG1 Lite unit has been calibrated and tested at the factory and does not need further calibration before use. However, if the unit suffers damage or is repaired, it is recommended that the unit be tested by an authorized CPAT Flex service center.

  • Page 7: Cpat Flex Web Site

    Rechargeable Li-ion battery pack. 2.2 Initial Verification Your DSG1 Lite unit is charged, calibrated, and ready to use right out of the box. Upon delivery, visually inspect each item for any damage that may have occurred during shipping. If you notice any physical damage, please contact CPAT Flex: Toll-free from the U.S.
  • Page 8 Lite DSG1 GettingStartedManual2024-07-23V1.4 Check that your package contains all the standard items as well as any accessories you may have ordered. If you ordered the DSG1 Lite Digital Signal Generator kit, the following items are included: DSG1 Lite unit ...

  • Page 9: Setup

    Transmit carriers AM modulation depth 2 dB CAUTION! The DSG1 Lite High output level is set at 50 dBmV. It must not be connected to a live cable network in order to avoid interference with the current channel lineup. CAUTION! Even if the case resists splashing, this device is not waterproof.
  • Page 10 Harmonics levels based on 126 & 612 MHz at 50 dBmV NOTE A pad may be required at the output of the DSG1 Lite, especially if there is Some active equipment connected to the cable drop feed (set-top box, cable modem, etc.).

  • Page 11: System Operation

    4. System Operation 4.1 Power On To power the DSG1 Lite, press the power button on the front panel, and then release it. You should see the power LED (surrounding the power button) and the battery LED turn on. 4.2 LED Information The two front panel LEDs indicate the status of the unit.

  • Page 12: System Maintenance

    5.2 Cleaning the Equipment Your DSG1 Lite unit can be cleaned using a damp cloth. Do not immerse the unit in water. Avoid the use of solvents and commercial cleaners. 5.3 Preventive Maintenance The technician shall perform regular visual inspections of the RF connector for loose or broken connectivity, which could affect the system's performance of the system.

  • Page 13: Appendix A - Specifications

    Lite DSG1 GettingStartedManual2024-07-23V1.4 Appendix A – Specifications TECHNICAL DETAILS Modulator type Dual-band digital signal modulator Output type Single “F” 75 Ω female connector Frequency output 1 of 2 Fixed at 126 MHz (mid-band) Frequency output 2 of 2 Fixed at 612 MHz (LTE-band) Frequency stability ±5 kHz Modulated signal...
  • Page 14 CPAT Flex is not responsible for any damage that may occur during shipping. The customer should clearly mark the RA or reference number issued by CPAT Flex on the outside of the package and ship it prepaid and insured to CPAT Flex.
  • Page 15 B.2 Limited Product Warranty B.2.1 Hardware CPAT Flex warrants to the original end user (Customer) that the new CPAT Flex branded products will be free from defects in workmanship and materials, under normal use, for one (1) year from the date of original shipment.
  • Page 16 (Limited Warranty) and actually fails during the applicable warranty period and under normal use, CPAT Flex shall, at its sole discretion, (i) repair or replace the non-conforming product to remedy the nonconformity identified by the customer in accordance with this section (Limited Product Warranty);...
  • Page 17 Lite DSG1 GettingStartedManual2024-07-23V1.4 Published by CPAT Flex 8566 Ave de L’Esplanade Montreal, Quebec CANADA H2P 2R8 www.cpatflex.com 1-888-307-2728...
