Summary of Contents for Velleman EtiamproEP EDS201B

  • Page 2 Video Intercom Indoor Station Configuration Guide Legal Information About this Manual The Manual includes instructions for using and managing the Product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 Video Intercom Indoor Station Configuration Guide Data Protection During the use of device, personal data will be collected, stored and processed. To protect data, the development of our devices incorporates privacy by design principles. For example, for device with facial recognition features, biometrics data is stored in your device with encryption method; for fingerprint device, only fingerprint template will be saved, which is impossible to reconstruct a fingerprint image.
  • Page 4 Video Intercom Indoor Station Configuration Guide Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Danger Indicates a hazardous situation which, if not avoided, will or could result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, Caution could result in equipment damage, data loss, performance...
  • Page 5 Video Intercom Indoor Station Configuration Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 6 Video Intercom Indoor Station Configuration Guide 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).

  • Page 7: Table Of Contents

    Video Intercom Indoor Station Configuration Guide Contents Chapter 1 Local Operation ......................1 1.1 Activate Indoor Station ......................1 1.2 Quick Operation ........................2 1.3 Basic Settings ......................... 5 1.3.1 Set Indoor Station Network Parameters ..............5 1.3.2 Set Linked Device IP ....................6 1.3.3 Set Indoor Station No.
  • Page 8 Video Intercom Indoor Station Configuration Guide 2.4 Remote Configuration ......................25 2.4.1 System ........................25 2.4.2 Video Intercom ......................31 2.4.3 Network ........................39 2.5 Person Management ......................44 2.5.1 Organization Management ..................44 2.5.2 Person Management ....................45...

  • Page 9: Chapter 1 Local Operation

    Video Intercom Indoor Station Configuration Guide Chapter 1 Local Operation 1.1 Activate Indoor Station You can configure and operate the indoor station after creating a password for the device activation. Steps 1. Power on the device. It will enter the activation page. Figure 1-1 Activation Page 2.

  • Page 10: Quick Operation

    Video Intercom Indoor Station Configuration Guide Note We highly recommend you to create a strong password of your own choosing (using a minimum of 8 characters, including at least three kinds of following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend you change your password regularly, especially in the high security system, changing the password monthly or weekly can better protect your product.
  • Page 11 Video Intercom Indoor Station Configuration Guide Figure 1-3 Network Parameters 3. Configure the Guarding Vision service settings. 1) Enable Guarding Vision service. 2) Set LBS Server. 3) Slide the slider to edit verification code or use the activation password by default. 4) Tap Next.
  • Page 12 Video Intercom Indoor Station Configuration Guide 1) Select Device Type as Indoor Station. 2) Set Registration Password. 3) Configure advanced settings. 4) Optional: Enable Indoor Extension Settings to add indoor extensions. 5) Tap Next. Figure 1-5 Indoor Station Settings 5. Link related devices and tap Next. If the device and the indoor station are in the same LAN, the device will be displayed in the list.

  • Page 13: Basic Settings

    Video Intercom Indoor Station Configuration Guide Figure 1-6 Related Device 1) Tap the door station in the list to link. Note If the door station is inactive, the system will pop up the dialog to activate the door station. 2) Tap to pop up the Network Settings page.

  • Page 14: Set Linked Device Ip

    Video Intercom Indoor Station Configuration Guide network segment as other devices, it can work properly in the same system. Steps Note The default IP address of the indoor station is 192.0.0.64. Two ways are available for you to set IP address: DHCP, and set IP address manually. 1.

  • Page 15: Set Indoor Station No

    Video Intercom Indoor Station Configuration Guide standard SIP protocol. Steps Note ● The doorphone does not support adding with the standard SIP protocol. ● Here take door station network settings as example. 1. Tap Settings → → Configuration, and enter admin (activation) password. 2.

  • Page 16: Sip Settings

    Video Intercom Indoor Station Configuration Guide station No., is composed of the floor No. and the room No. The indoor extension No. Should be a numeric from 1 to 5. Up to 5 indoor extensions can be set for 1 indoor station. Steps 1.

  • Page 17: Add Camera

    Video Intercom Indoor Station Configuration Guide 1.3.5 Add Camera Steps 1. Tap Settings → → Configuration, and enter admin (activation) password. 2. Tap to enter the device management page. 3. Tap + to pop up the dialog box. 4. Select Private Protocol and you can add the camera depended on the private protocol. 5.
  • Page 18 Video Intercom Indoor Station Configuration Guide Figure 1-9 Zone Settings 2. Press a zone to pop up the zone editing dialogue box. 3. Set the zone type, alarm type, status of arming status, entering delay, and exiting delay. 4. Tap OK to save the settings. Note ●...
  • Page 19 Video Intercom Indoor Station Configuration Guide Steps Note On the home page, the arming status function and zone settings function are hidden by default. You should enable the alarm function first. 1. Back to the home page, tap Settings → →...

  • Page 20: Password Settings

    Video Intercom Indoor Station Configuration Guide 1.4 Password Settings 1.4.1 Modify Admin Password If you forget admin (activation) password when entering Configuration page, you can modify it via verification code from E-mail. Before You Start The E-mail address has been registered after activation. Steps 1.

  • Page 21: Synchronize Time

    Video Intercom Indoor Station Configuration Guide password to unlock. Duress Code When you are hijacked and forced to open the door, you can enter the duress code. An alarm will be triggered to notify the management center secretly. Note The duress code and the unlock password cannot be the same. 4.

  • Page 22: Sound Settings

    Video Intercom Indoor Station Configuration Guide Note ● The default unit of synchronizing interval is minute. ● The time zone can be configured as well if the NTP is not enabled. 1.6 Sound Settings Set the ringtone sound, the volume, and the auto answer. 1.6.1 Call Settings You can set the ringtone, ring duration, call forwarding time on call settings page.

  • Page 23: Volume Settings

    Video Intercom Indoor Station Configuration Guide The call will end automatically when the actual calling duration is longer than the configured one. Calling duration ranges from 30 s to 60 s. Call Forwarding The ring duration limit beyond which the call is automatically forwarded to the mobile phone designated by the resident.

  • Page 24: Link To The Mobile Client

    Video Intercom Indoor Station Configuration Guide 1.7 Link to the Mobile Client Steps 1. Tap Settings → → Guarding Vision Service Settings to enter the settings page. 2. Enable Enable Guarding Vision Service. Figure 1-14 Enable Guarding Vision Service 3. Edit LBS server and Verification Code. Note Verification code is used to add the device to mobile client.

  • Page 25: System Settings

    Video Intercom Indoor Station Configuration Guide 3. Tap Restore Default Settings to restore the default settings and reboot the system. 4. Tap Restore All to restore all parameters and reboot the system. 1.9 System Settings You can format or install TF card, clear the screen, view the version information of the indoor station and reboot the system on the settings page.
  • Page 26 Video Intercom Indoor Station Configuration Guide Note The indoor station supports 19 languages. Brightness Adjustment Tap + or - to adjust the screen brightness. Clean Screen Enable Clear Screen and the screen will be locked for 30s. And you can clear the screen within the time duration.

  • Page 27: Device Information

    Video Intercom Indoor Station Configuration Guide Zone Settings Note Only when enable Alarm in the shortcut settings, can the Zone Settings displayed on the Preference page. Set the zone parameters. For details, see Zone Settings. Scene Settings Note Only when enable Alarm in the shortcut settings, can the Scene Settings displayed on the Preference page.
  • Page 28 Video Intercom Indoor Station Configuration Guide Note 1 to 32 characters are allowed. Supports uppercase letters, lowercase letters, numerics, and special characters. Remain Open Enable the function, the relay remains open. Disabled the function, and you can set the remain open duration. Note ●...

  • Page 29: Chapter 2 Remote Operation Via The Client Software

    Video Intercom Indoor Station Configuration Guide Chapter 2 Remote Operation via the client software The Video Intercom module provides remote control and configuration on video intercom products via the Guarding Vision client software. 2.1 Activate Device Remotely You can only configure and operate the indoor station after creating a password for the device activation.

  • Page 30: Add Video Intercom Devices

    Video Intercom Indoor Station Configuration Guide 2.2.1 Add Video Intercom Devices Steps Note ● You can add at most 512 indoor stations and main stations in total to the client, and add at most 16 door stations to the client. ●...
  • Page 31 Video Intercom Indoor Station Configuration Guide Figure 2-1 Add the Device 4. Optional: Click Online Device, the active online devices in the same local subnet with the client software will be displayed on the Online Device area. EDS201B – Indoor Station...

  • Page 32: Modify Network Information

    Video Intercom Indoor Station Configuration Guide Note To add online devices to the software, you are required to change the device IP address to the same subnet with your computer first. 1) You can click Refresh Every 60s to refresh the information of the online devices. 2) Select the devices to be added from the list.

  • Page 33: System Configuration

    Video Intercom Indoor Station Configuration Guide of the selected device. Note You should enter the admin password of the device in the Password field of the pop-up window to modify the parameters. 2.3 System Configuration You can configure the video intercom parameters accordingly. Steps 1.
  • Page 34 Video Intercom Indoor Station Configuration Guide Information, General, Time, System Maintenance, User, RS-485, and Security. Device Information Click Device Information to enter device basic information page. You can view basic information (the device type, and serial No.), and version information of the device. Figure 2-2 Device Information General Click General to enter device general parameters settings page.
  • Page 35 Video Intercom Indoor Station Configuration Guide Figure 2-4 Time Settings Page Select Time Zone, Enable NTP, Enable DST, or SDK Synchronization. Click Save to save the time settings. ● Time Zone: Select a time zone from the drop-down list menu. ●...
  • Page 36 Video Intercom Indoor Station Configuration Guide Figure 2-5 System Maintenance ● Reboot: Click Reboot and the system reboot dialog box pops up. Click Yes to reboot the system. ● Restore Default Settings: Click Restore Default Settings to restore the default parameters. All default settings, excluding network parameters, will be restored.
  • Page 37 Video Intercom Indoor Station Configuration Guide Czech, Bulgarian, Croatian, Serbian. ○ Rebooting the device is required after you change the system language. User Click User to enter the user information editing page. Select the user to edit and click Edit to enter the user parameter page. Figure 2-6 User Page Note ●...
  • Page 38 Video Intercom Indoor Station Configuration Guide Figure 2-7 RS-485 Settings Note For indoor station and main station, there are 3 choices for the working mode: transparent channel, disable, and custom. Security Click Security to enter the page. You can enable SSH or enable HTTPS on this page. Click Save after configuration.

  • Page 39: Video Intercom

    Video Intercom Indoor Station Configuration Guide 2.4.2 Video Intercom Click Video Intercom on the remote configuration page to enter the video intercom parameters settings: Time Parameters, Password, Zone Configuration, IP Camera Information, Volume Input and Output Configuration, Ring, Arming Information, Calling Linkage, Relay, and SIP No. Time Parameters Steps 1.
  • Page 40 Video Intercom Indoor Station Configuration Guide ● For indoor extension, it only requires setting the maximum live view time. Permission Password Click Permission Password to enter password changing page. Select password type. Create a new password and confirm it. Click Save to complete the settings. Figure 2-10 Permission Password Note For indoor station, you can enter the old password and new password to change the arm/disarm...
  • Page 41 Video Intercom Indoor Station Configuration Guide Figure 2-11 Zone Alarm 2. Select Area No. 3. Select Zone Type from the drop-down list. 4. Select Alarm Type from the drop-down list. 5. Set the NO/NC status. 6. Set Entering Delay and Exiting Delay. 7.
  • Page 42 Video Intercom Indoor Station Configuration Guide receive alarm message when the detector is triggered. ● After setting enter delay time, if OK is pressed within the enter delay time after the alarm, the alarm event will not be uploaded to the management center; if OK is not pressed within the enter delay time after the alarm, the alarm event will be uploaded to the management center.
  • Page 43 Video Intercom Indoor Station Configuration Guide Figure 2-13 Import Added Device Information Volume Input and Output Steps 1. Click Volume Input/Output to enter the configuring the volume input or output page. EDS201B – Indoor Station...
  • Page 44 Video Intercom Indoor Station Configuration Guide Figure 2-14 Volume Input or Output 2. Slide the slider to adjust the input volume, output volume and speak volume. 3. Click Save to enable the settings. Ring Import Steps 1. Click Ring Import to enter the ring configuration page. Figure 2-15 Ring Import 2.
  • Page 45 Video Intercom Indoor Station Configuration Guide Arming Information Click Arming Information to enter the configuring arming informaton page and view the arming information. Figure 2-16 Arming Information Click Refresh to refresh the arming information. Relay Click Relay to enter the set relay parameters page. Select a relay and click "...
  • Page 46 Video Intercom Indoor Station Configuration Guide Figure 2-18 Add SIP Info 3. Select Device Type as Indoor Extension. 4. Enter the required information. Serial No. EDS201B – Indoor Station...

  • Page 47: Network

    Video Intercom Indoor Station Configuration Guide Enter the device's serial No.. The serial No. is on the rear panel of the device (A fixed-length number with 9 digits). IP Address Enter the device's IP address. Gateway Enter the device's gateway. Subnet Mask Enter the device's subnet mask.
  • Page 48 Video Intercom Indoor Station Configuration Guide Figure 2-19 Local Network Configuration 2. Enter the Local IP Address, IP Address Subnet Mask, Gateway, Port No. and HTTP Port No. 3. Click Save to enable the settings. Note ● The default port No. is 8000. ●...
  • Page 49 Video Intercom Indoor Station Configuration Guide Figure 2-20 SIP Server Configuration 2. Click Enable. 3. Set the parameters according to your needs. Note ● Up to 32 characters are allowed in the Register User Name field. ● Registration password should be 1 to 16 characters in length. ●...
  • Page 50 Video Intercom Indoor Station Configuration Guide DNS Settings The indoor station supports 2 DNS address. Click Advanced Settings to enter DNS address settings page. Edit the IP address and click Save. Figure 2-21 DNS Settings Configure Mobile Client Connection Configure Guarding Vision server parameters before viewing videos via mobile client. Before You Start Make sure the indoor station connects to the network.
  • Page 51 Video Intercom Indoor Station Configuration Guide Group Network Settings Click Group Network Settings to enter the group network settings page. Figure 2-22 Group Network Settings Device No. Settings Select the device type from the drop-down list, and set the corresponding information. Note ●...

  • Page 52: Person Management

    Video Intercom Indoor Station Configuration Guide 2.5 Person Management You can add, edit, and delete the organization and person in Person Management module. Organization and person management is necessary for the video intercom function. On the main page, click Person to enter the page. Figure 2-23 Personal Management Application The page is divided into two parts: Organization Management and Person Management.

  • Page 53: Person Management

    Video Intercom Indoor Station Configuration Guide Add Organization Steps 1. In the organization list on the left, click +Add. 2. Input the organization name as desired. 3. You can add multiple levels of organizations according to the actual needs. 1) You can add multiple levels of organizations according to the actual needs. 2) Then the added organization will be the sub-organization of the upper-level organization.
  • Page 54 Video Intercom Indoor Station Configuration Guide 2. Set basic person information. 1) Enter basic information: name, gender, tel, birthday details, effective period and email address. 2) Optional: Click Add Face to upload the photo. Note The picture should be in *.jpg format. Click Upload Select the person picture from the local PC to upload it to the client.
  • Page 55 Video Intercom Indoor Station Configuration Guide 4) Click ... to select the Excel file with person information. 5) Click OK to start importing. Get Person Information from Device If the added device has been configured with person information (including person details, fingerprint, issued card information), you can get the person information from the device and import to the client for further operation.
  • Page 56 Video Intercom Indoor Station Configuration Guide 3. Click OK to save the settings. EDS201B – Indoor Station...
