MIZETTO PARKER TABLE Assembly Instruction Manual

Download this manual

P A R K E R

T A B L E / B E N C H

A S S E M B L Y I N S T R U C T I O N

Need help?

Do you have a question about the PARKER TABLE and is the answer not in the manual?

Page 1 P A R K E R T A B L E / B E N C H A S S E M B L Y I N S T R U C T I O N...
Page 2 PARTS Parker table includes: Gable X2 Table top X2 Connecting rod OPTIONAL Allen bolt Allen bolt Adjustable feet Foot Sleeve Floor fixture M8 20mm x4pcs M6 22mm x8pcs x4pcs x4pcs (NOT INCLUDED) TOOLS To assamble Parker you need the following tools.
Page 3 ASSEMBLE PARKER TABLE The construction is easy to assemble with few parts. 1. MOUNT THE FEET Start by inserting the foot sleeve in the gabel legs, then screw in the adjusting foot. 2. MOUNT THE TABLE TOP Put the gable on a flat surface with some protective material, so you don’t scratch the...
Page 4 3. FIX THE TABLE TOP Use M6. Screw in all screws by hand before tightening them with the key. Do not tighten them fully. You will tighten all screws when both gables are mounted.
Page 5 4. ATTACH THE ROD Use M8. Insert the connecting rod to the gabel. Screw in all screws by hand before using the the allen key. Do not tighten them fully. You will tighten all screws when both gables are mounted. 5.
Page 6 6. TIGHTEN THE BOLTS Screw in all screws for the second gable by hand. Then tighten all screws on both gables with the allen keys...
Page 7 7. FLIP THE TABLE Make sure to be at least two people then turning the table. Adjust feet if needed.
Page 8 MIZETTO.COM / MAIL@MIZETTO.COM / ENGELSKA VÄGEN 5 / 393 56 KALMAR, SWEDEN / +46 480-54 999...
