Monaco III Assembly Manual
Δ CAUTION:
1.Make sure the weight of the base is heavy enough before open the parasol.
2.
down. Otherwise, the pin inside will scratch the pole.
3. When the parasol is fully opened, do not over turn the handle for avoiding any
damage.
4. Close the parasol in windy or rainy day.
Advertisement
Related Manuals for Madison Monaco III
Summary of Contents for Madison Monaco III
- Page 1 Monaco III Assembly Manual Δ CAUTION: 1.Make sure the weight of the base is heavy enough before open the parasol. down. Otherwise, the pin inside will scratch the pole. 3. When the parasol is fully opened, do not over turn the handle for avoiding any damage.
- Page 2 PARASOL COMPONENTS Qty. Components Ref. 2pcs 2pcs...
- Page 3 1. Assemble the parasol 1. Take out the parasol main body and rotation part from the carton, remove the packing material. 2. Install the parasol onto the rotation part with umbrella roof, and foot pedal of the rotation part on the same side(a-1). 3.
- Page 4 2. Open the parasol 1. Untie the band on the canopy, insert the handle into the slider handle open close hole, hold the end of rib with one hand and hold handle with another(a-3). 2. Turn the handle in the clockwise direction to open the parasol completely, and adjust the shade angle by moving the slider to different hole on the standing pole(a-3).
- Page 5 3. Tilt Function in left/right direction 1. Make sure the parasol is fully opened and at the level position before operation(a-4). 2. Pull the slider that hand can touch the end of rib. 3. Insert the handle into the slider handle left right hole, turn the handle in clockwise or anti- clockwise direction to make the canopy tilt in left or right side(a-4).
- Page 6 4. Rotation function Press down on the pedal of the Rotation part ( a -5). Rotate the sunshade around the pole with 360 degrees to any desired angle ( a-6 ). Caution Never leave this parasol in the open position over night or while away. Weather conditions causing guesting winds could result in damage to this parasol.
- Page 7 5. Close the parasol Close parasol by moving the slider to bottom hole, and turn the handle in anti- clockwise direction, fully close parasol and tie the cover by band (a-7,a-8).
