Electrical current hazard! Installation and maintenance of the PV modules must only be performed by qualified technical personnel. Observe the safety instructions issued by the PV module manufacturer! PROLINE SINGLEFIX-V MOUNTING KIT | V1 | INSTALLATION GUIDE | 202102 SCHLETTER SOLAR GMBH | SUBJECT TO CHANGES...
Roof centre area area Corner area Corner area Edge area Building Calculation formula: e = min (x or y or 2 · h) PROLINE SINGLEFIX-V MOUNTING KIT | V1 | INSTALLATION GUIDE | 202102 SCHLETTER SOLAR GMBH | SUBJECT TO CHANGES...
Press the SingleFix-V components sideways onto the high beads and screw tight with 2 self-drilling screws. Place the screws slightly inclined downwards* and slightly inclined outwards**! PROLINE SINGLEFIX-V MOUNTING KIT | V1 | INSTALLATION GUIDE | 202102 SCHLETTER SOLAR GMBH | SUBJECT TO CHANGES...
Do not screw on the SingleFix in the trapezoidal sheet joint area. Make sure that the SingleFix lies flat. 4. CREATE POTENTIAL EQUALISATION Connect module rows using perforated tape and self-drilling screws. PROLINE SINGLEFIX-V MOUNTING KIT | V1 | INSTALLATION GUIDE | 202102 SCHLETTER SOLAR GMBH | SUBJECT TO CHANGES...
Tightly screw the last module of a row with 2 end clamps. Further information regarding our systems is available on our website: www.schletter-group.com under Downloads in the solar section. PROLINE SINGLEFIX-V MOUNTING KIT | V1 | INSTALLATION GUIDE | 202102 SCHLETTER SOLAR GMBH | SUBJECT TO CHANGES...
