- Page 2 The copyright and other intellectual property rights contained in this Manual belong to Elecnova. without the prior consent of Elecnova or its licensors, this Manual may not be modified or copied in whole or in part. The following are trademarks or registered trademarks of Elecnova in China and other countries: Other trademarks (of other owners) used in this Manual does not imply sponsorship or endorsement of their products or services by Elecnova.
-
Page 3: Table Of Contents
ECO-E100WX Installation Manual Contents 1. About the Manual ......................1 1.1 Preface ........................1 1.2 Applicable Product ....................1 1.3 Applicable Personnel ....................1 1.4 Usage of Manual ..................... 1 1.5 Usage of Symbols ....................1 2. Safety Instructions ......................2 2.1 Application Scope of Product .................. 2 2.2 Safety Instructions ....................2... -
Page 4: About The Manual
Elecnova aim to the full industrial chain placement of key battery material and system integration for LFP battery application. Elecnova focus on R&D, manufacturing, sales and service of BESS products to provide client with efficient, reliable, and customized BESS solutions. -
Page 5: Safety Instructions
ECO-E100WX Installation Manual Always pay attention to the warning signs on the cabinet. The signs include: This sign indicates that there is high voltage inside the cabinet. Touching the cabinet may lead to electric shock. This sign indicates that the temperature here is higher than the acceptable range for human body. - Page 6 ECO-E100WX Installation Manual Touching Power Grid or touching the contacts and terminals that are connected to Grid may lead to electric shock and death! Do not touch the terminals or conducts connecting the Grid Damaged equipment or system fault may cause electric shock or fire! Before operation, conduct a preliminary visual inspection of the equipment for any damage or hazards.
- Page 7 Electrical connection must be conducted in strict accordance with the electrical wiring diagram in this Manual The configuration, relevant current, voltage, power and other parameters of the LFP battery pack have been fully set-up and matched by Elecnova, and shall not be modified arbitrarily Aways apply and obtain approval/permission from local Grid authority before connecting the ESS Cabinet to the power grid.
-
Page 8: Delivery & Handling
ECO-E100WX Installation Manual blocked. 2.2.9 Moisture Protection The invasion of moisture is most likely to damage the BESS! Do not open the cabinet door when air relative humidity is above 95%. Avoid installation in rainy or in humid weather conditions. -
Page 9: Integrity Inspection For Transportation
ECO-E100WX Installation Manual Figure 3-2 Appearance Figure 3-3 Nameplate Position Name Description LED indicators To show power status, operation status and fault status respectively LCD touch screen To display data and execute control commands Emergency stop button To be pressed in emergency to turn off the AC-side power... -
Page 10: Installation Design
If the BESS is to be stored for more than six months, the packing shall be opened for inspection and the desiccants be renewed before repacking every 6 months. 4. Installation Design 4.1 BESS Physical Parameters Figure 4-1 ECO-E100WX Dimensions Width Depth Height 1,250mm... -
Page 11: Cable Design
ECO-E100WX Installation Manual Figure 4-2 ECO-E100WX Air inlet and Outlet 4.3 Cable Design The product in standard configuration has all connecting cables coming in and out from the bottom of the cabinet. The positions of the inlet and outlet holes are shown in Figure 4-3. Holes in front of the cabinet are for communication cables, and the behind ones are for AC power cables. -
Page 12: Installation Environment Requirements
ECO-E100WX Installation Manual 4.5 Installation Environment Requirements The ground, space, cable ducts, air ducts, ventilation equipment, and protective measures in the control room of the ESS Cabinet shall be properly designed to meet at least the following requirements. 4.5.1 Foundation Requirements The BESS shall be installed on a concrete foundation or channel steel structure that is flame-retardant. -
Page 13: Wiring Specifications
ECO-E100WX Installation Manual anchor screws or channel steel. In case steel brackets are used, the ESS Cabinet may be directly installed and fixed on such structure. The cable trenches are usually designed and constructed in accordance with the relevant standards, taking into account the weight and dimensions of the ESS Cabinet. -
Page 14: Mechanical Installation
ECO-E100WX Installation Manual Torque (N.m) 0.7-1 1.8-2.4 4-4.8 17-20 34-40 60-70 119-140 In order to reduce the stress on copper noses connecting a cable, the cable shall be fixed at another position nearby 4.7.2 Cable Protection The protection of cables includes the protection of communication cables and power cables. The... - Page 15 ECO-E100WX Installation Manual Sign Meaning Right side up. It is prohibited to handle the cabinet lying down, tilted or upside down. Handle with care. Avoid damage to the ESS Cabinet caused by excessive collision and friction. Moisture prevention. Protect the ESS Cabinet from and against rain or moisture...
- Page 16 ECO-E100WX Installation Manual Transportation with Crane A crane may be used to lift and transport the ESS Cabinet. For the purpose of lifting, tie two flexible lifting straps to the outer packaging box through lifting signs. The equipment shall be lifted with the hook being perpendicular to BESS gravity center.
- Page 17 ECO-E100WX Installation Manual Figure 5-3 Transportation with Forklift (with Bottom Wooden Pallet) If the wooden pallet at the bottom of the ESS Cabinet has been removed, it may be transported directly by a forklift, and the forks may be placed directly in the base fork grooves.
-
Page 18: On-Site Installation
ECO-E100WX Installation Manual Figure 5-5 Transportation with Crane (no package, no pallet) 5.2 On-site Installation It is prohibited to perform any un-related mechanical operation either inside or on the top of the ESS Cabinet. During installation, please ensure the ESS Cabinet is clean (both inside and ... - Page 19 ECO-E100WX Installation Manual Figure 5-6 Schematic Diagram of Fixing Status of the Cabinet to Pallet After the ESS Cabinet is detached from the wooden pallet, it is strictly prohibited to transport the ESS Cabinet through the wooden pallet again. In addition, since now the ESS Cabinet is at risk of tipping over, please handle with special care.
- Page 20 ECO-E100WX Installation Manual Figure 5-7 Fixing Method for ESS Cabinet The connection sequence between the bottom of the ESS Cabinet and the channel steel is shown in the figure below. Name Spring washer Flat washer Base of Cabinet Channel steel...
-
Page 21: Electrical Installation
ECO-E100WX Installation Manual Mind the polarities of DC cables and the phase sequence of AC cables Don’t pull the cables hard to avoid damage to insulation. Bending allowance shall be reserved for all cables Take auxiliary measures to reduce stress of cables, ... - Page 22 ECO-E100WX Installation Manual 6.3.2 Cable Requirements The requirements for cable selection are as follows: The selected cables shall have sufficient current capacity. The current capacity of a conductor is related to the factors: 1) environmental conditions, 2) type of insulation material on the conductor, 3) cable laying method, 4) material of conductor 5) cross-section area.
- Page 23 ECO-E100WX Installation Manual Use a wire crimper to compress the copper nose terminal. Compress it at least twice. Step 5: Install the heat shrink tubing. Select a heat shrink tubing that matches the cable size. The length of the tubing shall exceed ...
-
Page 24: Grounding Of Ess Cabinet
ECO-E100WX Installation Manual The length of wiring screw/bolt shall be appropriate, so that the screw/bolt slightly protrudes from the connection hole of copper bar. Excessive long screw/bolt may affect the insulation performance or even lead to short circuit. Check whether any heat shrink tubing is clamped at the connection point. If ... -
Page 25: Annex
ECO-E100WX Installation Manual The insulated protective cover: complete and secured and the warning signs are clear and secured Other Inspections Inside the cabinet: no foreign objects, like tools, parts, waste or conductive dust The ESS Cabinet and cables: neat and secured 7. -
Page 26: Cables Reference
PE (25-50mm 2 cable) or grounding flat steel Grounding cable 7.3 Quality Warranty Refer to Limited Warranty Letter for Elecnova ESS Products (Standard Edition). The warranty conditions are also subject to terms and conditions of a contract. 7.4 Contact Information For any question about the Product, please contact us with info below: Name: Shanghai Elecnova Energy Storage Co., Ltd.
