Summary of Contents for Elecnova ECO-E100WX
- Page 2 The copyright and other intellectual property rights contained in this Manual belong to Elecnova. without the prior consent of Elecnova or its licensors, this Manual may not be modified or copied in whole or in part. The following are trademarks or registered trademarks of Elecnova in China and other countries: The use of other trademarks belonging to their respective owners in this Manual does not imply sponsorship or endorsement of their products or services by Elecnova.
-
Page 3: Table Of Contents
ECO-E100WX User Manual Table of Contents 1. About this manual ........................3 1.1 Preface ..........................3 1.2 Applicable Product ......................3 1.3 Security Statement ......................3 1.4 Safety instructions ......................3 2. ESS Cabinet Introductions ..................... 4 2.1 System Overview ......................4 2.2 Technical parameters ....................5 2.3 System Diagram ...................... -
Page 4: About This Manual
Dear user, much appreciation for using the all-in-one air-cooled ESS Cabinet ECO-E100WX product (hereafter referred as ECO-E100WX, or the ESS Cabinet, or the Product) developed and produced by Shanghai Elecnova Energy Storage Co., Ltd. We sincerely hope that this product can meet your needs, and we also hope that you are satisfied with its performance and provide us with your valuable comments and suggestions. -
Page 5: Ess Cabinet Introductions
2. ESS Cabinet Introductions 2.1 System Overview ECO-E100WX is a C&I ESS Cabinet product solely developed and produced by Elecnova. This product adopts the All-In-One integrated design and integrates LFP batteries, BMS, PCS, FSS, BCQ (local EMS controller), air-cooled HVAC and other components into a single ESS Cabinets. The ESS Cabinet has the characteristics of energy saving, small size, high energy density, high environmental flexibility, fast on-site installation, friendly-grid-access and easy capacity expansion etc. -
Page 6: Technical Parameters
ECO-E100WX User Manual Figure 2-1 Product Image Figure 2-2 ECO-E100WX internal layout Note: Local EMS Control Box is named as BCQ box Product Advantages: Ingress Protection level IP55, supporting outdoor and indoor multi-scenario installation. Fire early-warning + fully immersive Aerosol FSS ... -
Page 7: System Diagram
Grid-tied operation mode The AC side of ECO-E100WX is connected to the grid, and the DC side is internally connected to the lithium battery. It is applicable for scenarios such as power expansion, PV plus EV charging, peak shaving, demand management, power quality management. Based on the grid-tied P/Q operating mode,... -
Page 8: Ports
ECO-E100WX User Manual Figure 2-4 ECO-E100WX Communication Diagram 2.5 Ports A-PACK Ports Figure 2-5 A-PACK Panel 1 2 3 4 5 6 7 Figure 2-6 7Pin-plug (for both A-PACK and B-PACK) Port Pin No. Pin Descriptions Pin Definitions External 24V power supply... - Page 9 ECO-E100WX User Manual External 24V power supply External 24V power supply B-PACK Ports Figure 2-7 B-PACK Panel High-voltage Box Ports Figure 2-9 High-voltage Box Panel Figure 2-10 GAM, GBM plug...
- Page 10 ECO-E100WX User Manual Ports Pin No. Pin Descriptions Pin Definitions BMU power supply BMU power supply BMU address allocation CAN0H BMS internal communication CAN0H CAN0L BMS internal communication CAN0L BMU power supply BMU power supply KT-485A Air-conditioning 485 communication KT-485B...
- Page 11 Smoke detection signal feedback Temperature detection signal feedback Sprinkling signal feedback Door/Access control signal feedback Emergency stop signal feedback Power supply switch trip signal feedback of POC cabinet corresponding to ECO-E100WX I/O signal common terminal HW-L1 Cabinet POWER indicator HG-L1 Cabinet RUN indicator...
-
Page 12: Pcs
ECO-E100WX User Manual 2.5.5 ESS Cabinet External Interface Wiring Diagram Figure 2-14 External Interface Diagram (see Installation Manual for details, for a specific project, wiring method may vary) 2.6 PCS PCS Introduction PCS, also known as bidirectional converter, is a device that realizes bidirectional conversion of electrical energy. - Page 13 ECO-E100WX User Manual Frequency range 45Hz ~ 55Hz Switching time (ms) <100 Protection Functions DC-side protection Isolating switch or fuse bank DC-side control DC contactor AC-side protection Circuit breaker or fuse AC-side control AC relay Short circuit protection Support AC phases sequence protection...
- Page 14 ECO-E100WX User Manual Slow flash in green at 1s intervals when power is off with no fault; Continuous in red when a fault occurs Ethernet/local debugging switch; ETH/LOCAL Right turn LOCAL for local debugging; Left turn for ETH Ethernet (reserved) Digit 1-2 are CAN Communication matching resistor connection;...
-
Page 15: Fire Suppression System (Fss)
And Aerosol FSS device is simultaneously activated to extinguish the fire, meanwhile an electronic signals of FIRE emergency is transmitted to BMS, notifying all parties to take actions immediately. Figure 2-18 ECO-E100WX FSS logic block diagram FSS Components ... -
Page 16: Ess Cabinet Operations
Personnel will be exposed to voltages up to 864 VDC from battery pack, and there is also the possibility of low- and medium-voltage AC exposure. Arc flash and electric shock hazards are common at ESS Cabinet sites. Elecnova encourages full compliance with the practices and procedures specified in NFPA 70E, including the use of personal protective equipment (PPE), to adequately mitigate hazards of arc flash. -
Page 17: Cabinet Panel
ECO-E100WX User Manual Do not start the ESS Cabinet until commissioning and inspection are completed by Elecnova on-site technicians. Do not restart ESS Cabinet before scheduled maintenance are completed. Do not modify or alter this manual without Elecnova's written permission. - Page 18 ECO-E100WX User Manual Temperature detector is activated (alarm signal transmitted) Smoke detector is activated (alarm signal transmitted) Aerosol device is activated (alarm signal transmitted) Immersion detector is activated (alarm signal transmitted) General Faults Charge/discharge power ≥5kW. Cabinet door is open BMS charge/discharge 3rd level alarm (SOC alarm excluded).
-
Page 19: Connection And Power-On
ECO-E100WX User Manual 3. Industrial computer body fault; 4. Industrial switch fault; 5. IO module Communication fault; 6. 4G router Communication fault; 7. Industrial exchange Comm fault; 8. Comm fault with BMS (Indicator on, PCS running); 9. Comm fault with PCS (indicator on. PCS running);... -
Page 20: Power-Off Operation
Disconnect the breaker inside POC or DB to disconnect ESS Cabinet from Power Grid. The white LED indicator on the Cabinet panel goes out, it indicates that ECO-E100WX, the ESS Cabinet, is successfully powered off. Note: Before powering off ECO-E100WX, please ensure that it has exited from the charge/discharge mode. -
Page 21: Operation Instructions For Hmi
ECO-E100WX User Manual Check the system configuration table: Be sure that EvbmaServer.ini is consistent with the model of CAN card. Examine the baud rate; Check the system configuration table: Be sure that EvbmaServer.ini is consistent with the model of CAN card. Examine the baud rate;... -
Page 22: Maintenance Under Normal Operation
ECO-E100WX User Manual Long-term Idle: ESS Cabinet is shut down for more than 3 consecutive months (the battery system shall be charged to minimum SOC 40% before it is laid idle). 4.2 Maintenance under Normal Operation Perform the battery system maintenance once every 12 months to prevent battery damage. Refer to ... -
Page 23: Emergency Faults Handling Methods
Service Hotline: +86 21 5439 6121, Email: sales@elecnova-ess.com https://www.elecnova-ess.com To the extent permitted by laws, Elecnova has the final right of interpretation for this Manual. Elecnova reserves the right to modify this Manual without further notice. Annex 1: Yes -√... - Page 24 ECO-E100WX User Manual Are there any surfaces of the cabinet deformed Visual inspection Are there any surfaces of the cabinet rusted or Visual inspection damaged Is there any moisture inside the cabinet Visual inspection Is the low-voltage wiring harness loose or damaged Visual inspection...
