ALMEGA 2 Brake Test Operation Quick Guide
Prerequisites:
1. Brake Test Switch, and Brake Test Circuit Installed
2. Brake Coils are wired correctly and configured for SERIES or PARALLEL operation!
3. Almega 2 Software Version V4.10 or above is installed.
4. Brake Test parameters are Setup and Enabled (as below)
Check Brake Monitoring inputs are configured and working
5.
6. Check the "Lift Car" load is set as per the Lift Standards Test Sheet (e.g, 125%).
STEP 1: PARAMETER SETUP
Several Brake Control parameters can be found in Travel Controls and Travel Times (as below):
Travel Control Parameters:
Parameter
BRAKE TEST CONTROL
BRAKE TEST FLOOR
BRAKE TEST LATCH
Travel Time Parameters:
Parameter
BRAKE TEST STR PAUSE TIME 1s
BRAKE TEST CRASHSTOP TIME 1s
IO Parameters:
Check an input is configured for Brake Test (i.e. input 101).
Input is ON when switch not operated, input is OFF when switch operated.
STEP 2: SWITCH TO "PREPARE TO TEST" CONTROL
1. Press MENU
2. then ENGINEER'S SELECTION
3. then select PREPARE TO TEST
4. select DOORS OFF
5. Press OK to confirm.
STEP 3: TURN OFF BRAKE MONITORING IN THE VF DRIVE (if applicable)
1. e.g. Ziehl Abegg Z4
2. Select MONITORING MENU
3. SELECT BR; and select option OFF
4. Press Enter / Carriage Return to confirm
CD605 ISS3 28.03.2022
020 8288 0668
020 8288 0667
info@lestercontrols.co.uk
www.lestercontrols.co.uk
ISSUE: 3 Date: 03/02/2022
Minimum
Maximum
NO
SEMI_AUTO NO
Bottom Floor Top Floor
NO
YES
Minimum
Maximum
10s
30s
1
(inputs on when stationary).
Default
Setup as:
SEMI_AUTO
1
Lowest Floor
Accessible
e.g. floor 1
NO
NO
Default
Setup as:
3s
3s
5s
5s
