Remote Control Systems TX-3v2 Manual

P.O Box 578 Casino, NSW, 2470 Australia
Phone: International ++614 2902 9083
Australia (04) 2902 9083
Website:
E mail: Info@rcs-rc.com
TX-3v2
Digital Proportional R/C
THE PRIMARY PURPOSE OF THE TX-3 IS FOR CONTROLLING LIVE STEAM LOCOS.
THE SECONDARY PURPOSE IS FOR USE WITH "LOW OFF" RCS BATTERY ESC's.
THESE INSTRUCTIONS REFER SPECIFICALLY TO THE
WHEN USED FOR LIVE STEAM A
SMALL KNOB SETS THE VALVE GEAR.
300º KNOB CONTROL OF REGULATOR.
1 X FULL THROW SERVO FOR WHISTLE.
CAN ALSO BE USED WITH RCS BASIC "LOW OFF" & "CENTRE OFF" ESC's.
When used for battery R/C you will supply a locomotive or trail car, the 14 – 20 volt traction batteries (depending on ESC), a fuse,
ON-OFF switch and wires where necessary, to connect the ESC to the battery and motor(s).
Where soldering is necessary, we recommend a low wattage soldering iron and resin core solder.
TO AVOID CONFUSION WITH OTHER OPERATORS, WE SUGGEST YOU MARK THE TX TO
DO NOT ATTEMPT TO ALTER THE TUNING OF THE RADIO EQUIPMENT.
DO NOT USE RADIO CONTROL EQUIPMENT IN THUNDERSTORMS.
CHILDREN UNDER 12:
http://rcs-rc.com
Thank you for purchasing this DSM2 3 channel TX handpiece.
THE TX-3 CAN ALSO BE USED WITH ANY "CENTRE OFF" ESC's.
INSTRUCTION MANUAL
They should be read in conjunction with the RCS ESC you are using.
REMOVE REAR OF TX-3 TO INSERT
LED BLINKS WHEN BATTERY LOW.
A HIGH QUALITY 9V SNAP IS USED.
PRIMARY USE IS WITH LIVE STEAM LOCOS.
THE TX-3v2 IS GUARANTEED FOR ONE YEAR.
SHOW WHICH LOCO IT IS OPERATING.
ADULT SUPERVISION RECOMMENDED DURING USE.
PROVIDED IN INSTRUCTIONS.
Page # 1 Introduction.
Page # 2 Preparing the TX-3v2. Binding.
Page # 3 Preparing & driving Live Steam locos.
Page # 4 Using with a centre off battery R/C ESC.
Other instructions for use with battery R/C are
found with the ESC.
http://www.rcs-rc.com/pages/instructions
DELTANG R/C
THE 9 VOLT BATTERY.
CAUTION
TABLE OF CONTENTS
BASED TX-3 HANDPIECE.
WHEN USED FOR BATTERY R/C
SMALL KNOB SETS THE DIRECTION.
300º KNOB CONTROLS SPEED.
1 X BUTTON FOR SOUND TRIGGER.
