  • Page 1 EK-AI7933CLD User Guide Version 912-13903 Doc No Date 2024/08/07 AcSiP Technology Corp www.acsip.com.tw...
  • Page 2 Add EVK Schematic Ivan 2022/11/14 Modify Hardware Features Ivan 2024/06/14 Modify EVK Schematic Ivan 2024/08/07 Modify the picture description and Ivan pin-header description according to the EVK schematic Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 1 /33...

  • Page 3: Table Of Contents

    INDEX Introduction ..................4 General Description ......................4 Get started with the HDK ..............5 Configuring the EK-AI7933CLD ..................5 Installing the FTDI drivers on Microsoft Windows ............6 Hardware Features ................8 Features Description ......................8 Hardware Feature Configuration ............10 Microcontroller .......................
  • Page 4 Figure 3. COM port associated with the EK-AI7933CLD ............. 7 Figure 4. Default power jumper plot ..................10 Figure 5. Power up the EK-AI7933CLD using an Battery ............12 Figure 6 . Audio Jumper and connector Locations ..............13 Figure 7. RGB LED ........................14 Figure 8.

  • Page 5: Introduction

    SRAM/ROM memory. The module also supports rich peripheral interfaces, including USB2.0, SDIO, SPI master, I2C, I2S, IR input, UART, AUXADC, PWM, and GPIOs.These features are used to download and debug a project on EK-AI7933CLD.The front view of the EK-AI7933CLD including AI7933CLD module in Figure 1.

  • Page 6: Get Started With The Hdk

    2. Get started with the HDK Before commencing the application development, you need to configure the development platform. 2.1 Configuring the EK-AI7933CLD The top view of the EK-AI7933CLD is shown in Figure 2. SW2(Vol+) , SW3(Vol-) WIFI+BT ANT Port AMIC_R...

  • Page 7: Installing The Ftdi Drivers On Microsoft Windows

    1) CON8 transfer USB interface to UART interface, can debug through UART, transmit, and receive a signal form PC. 2) CON8 is a USB 5V power for EK-AI7933CLD, or you can use external 5V power at J1. 3) CON6 is a USB OTG function com port.
  • Page 8 PRODUCT USER GUIDE www.acsip.com.tw Due to the com port numbers (COMx) are different at different PC. As red block in Figure 3. showed, means “CM33 UART”. Figure 3. COM port associated with the EK-AI7933CLD Product Name EK-AI7933CLD Version Doc No...

  • Page 9: Hardware Features

    PRODUCT USER GUIDE www.acsip.com.tw 3. Hardware Features This section provides the main supported features of the EK-AI7933CLD. The detailed description of the features is provided in the upcoming sections. 3.1 Features Description 3.1.1 Technology and Package • AI7933CLD LGA-104 module, 32mm X 32mm X 2.7mm (Typ.) 3.1.2...
  • Page 10 Channel assessment and WB RSSI for AFH • Supports BT/Wi-Fi coexistence 3.1.7 Miscellaneous • Embedded eFuse to store specific device information and RF calibration data • Advanced TDD mode Wi-Fi/Bluetooth coexistence scheme Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 9 /33...

  • Page 11: Hardware Feature Configuration

    EK-AI7933CLD supports two types of power supply. 1) Power up with a micro-USB connector. An on-board switching regulator provides voltage of 3.3V for the EK-AI7933CLD, if the power is supplied from an on-board micro-USB connector CON8 (Figure 2). This supply can be isolated from the switching regulator using the jumpers.
  • Page 12 Table 1 Jumper settings for system power input through USB connection Jumper Usage Comments Use external power source to supply 5V voltage to EK-AI7933CLD External 5V power supply PCB. Pin 1 is EXUSB_5V, Pin2 is GND. EXUSB_5V transfer to DC_DC_3V3 Pin 1 is DC_DC_3V3, Pin2 is 3V3_IN.
  • Page 13 JP11 J25 (Pin1+, Pin2-) F2 (fuse) is connected in parallel with JP11, 3.6V < Battery < 4.2V When F2 is disconnected, JP11 can be connected Figure 5. Power up the EK-AI7933CLD using a Battery Product Name EK-AI7933CLD Version Doc No...

  • Page 14: Audio

    Audio header for right speaker, Pin1 is AU_SPKR_N1, Pin2 is AU_SPKR_P1 AMIC (AU0_VIN0) for left channel (the microphone hole is set at back side of EK-AI7933CLD) AMIC (AU0_VIN1) for right channel (the microphone hole is set at back side of EK-AI7933CLD)

  • Page 15: Buttons

    Force DL mode Press SW5 to trigger strapping mode (download mode…) 4.5 RGB LED As Figure7 showed, the EK-AI7933CLD has on-board RGB LEDs (U54/U56) which be controlled by SPIM interface. Please note that ensure jumper J79 and J80 are connected before using RGB LED function. If...

  • Page 16: Sd Card

    4.6 SD Card The EK-AI7933CLD has a reserved SD card slot to facilitate users to store data to the SD card. It should be noted that the position of some resistor components needs to be modified before using the SD card.

  • Page 17: Extension Connectors

    4.7 Extension connectors The EK-AI7933CLD provides similar pin-out extension connectors for various sensor and device connectivity, as shown in Figure.7 and described in Table 4. The board has 46 GPIOs multiplexed with other interfaces. Depending on the use case, user can configure each I/O functionality.
  • Page 18 J28 - 11 Note: GPIO_39 is AU_AMP_MUTE by default. When using pin headers J28-29pin, resistor R161 needs to be switched to Location of R160. J28-Pin29 Table 5 GPIO pin multi-function definition Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07...
  • Page 19 0010 MSDC0_DAT1 MSDC0 Data[1] 0011 SPIM0_MOSI SPI0 (Master) Output SDIO_DAT1 0100 UART0_CTS UART0 CTS 0101 DEBUG_3 Debug Signal 3 0110 ANT_SEL3 Antenna Select 3 0111 CM33_GPIO_EINT1 CM33 EINT1 Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 18 /33...
  • Page 20 0010 SPIM1_SCK SPIM1 (Master) Clock 0011 I2SO_BCK I2SO BCK GPIO_B_1 0100 UART1_RX UART1 RX 0101 DEBUG_7 Debug Signal 7 0110 ANT_SEL4 Antenna Select 4 0111 CM33_GPIO_EINT5 CM33 EINT5 Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 19 /33...
  • Page 21 BT Debug UART TX 0010 UART0_TX UART0 TX 0011 TDMIN_BCK TDMIN BCK GPIO_B_6 0100 DMIC_DAT0 DMIC DAT0 (AUXADC) 0101 UART1_RX UART1 RX 0110 IR_IN IR RX Input 0111 CM33_GPIO_EINT10 CM33 EINT10 Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 20 /33...
  • Page 22 External PTA WLAN Active GPIO_B_10 0011 TDMIN_DI TDMIN DI (AUXADC) 0100 DMIC_DAT2 DMIC Data2 0101 DEBUG_14 Debug Signal 14 0110 ANT_SEL10 Antenna Select 10 0111 CM33_GPIO_EINT14 CM33 EINT14 Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 21 /33...
  • Page 23 0001* ADSP_JTAG_TRST DSP JTAG 0010 CM33_UART_TX CM33 UART TX 0011 UART0_TX UART0 TX GPIO_B_14 0100 SPIM0_CS_N SPIM0 CS 0101 RSVD RSVD 0110 UART1_TX UART1 TX 0111 SPIS_CS_N SPIS_CS_N Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 22 /33...
  • Page 24 DSP UART TX 0010 ADSP_JTAG_TCK DSP JTAG 0011 PWM_1 PWM 1 GPIO_R_1 0100 PTA_EXT_IF_WLAN_ACT External PTA WLAN Active 0101 CONN_WF_MCU_TCK Wi-Fi N10 JTAG 0110 CM33_RSVD3 RSVD 0111 CM33_GPIO_EINT22 CM33 EINT22 Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 23 /33...
  • Page 25 USB OTG ID Pin 0010 I2C0_SCL I2C0 Clock 0011 PWM_5 PWM 5 GPIO_R_5 0100 I2C1_SCL I2C1 Clock 0101 RSVD RSVD 0110 DEBUG_0 Debug Signal 0 0111 CM33_GPIO_EINT26 CM33 EINT26 Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 24 /33...
  • Page 26 0010 CM33_UART_TX CM33 UART TX 0011 PWM_9 PWM 9 GPIO_R_9 0100 I2C0_SDA I2C0 Data 0101 CONN_BGF_MCU_TRST_B I BT N10 JTAG 0110 I2C1_SCL I2C1 Clock 0111 CM33_GPIO_EINT30 CM33 EINT30 Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 25 /33...
  • Page 27 RSVD 0010* DBSYS_SWCLK_TCLK CM33_SWD (Default) 0011 UART1_RX UART1 RX GPIO_T_1 0100 UART0_RX UART0 RX 0101 DSP_URXD0 DSP UART RX 0110 ANT_SEL3 Antenna Select 3 0111 CM33_GPIO_EINT1 CM33 EINT1 Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 26 /33...
  • Page 28 SPIM0 SCK 0010 RSVD RSVD 0011 I2C1_SCL I2C1 Clock CONN_WF_MCU_AICE_ GPIO_T_5 0100 Wi-Fi N10 SWD TCKC 0101 PWM_1 PWM 1 0110 ANT_SEL7 Antenna Select 7 0111 RSVD RSVD Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 27 /33...
  • Page 29 CM33 UART TX (default) 0010 RSVD RSVD 0011 KEYPAD_KPCOL_0 KEYPAD_KPCOL_0 KPCOL_0 0100 DSP_UTXD0 DSP UART TX 0101 PWM_5 PWM 5 0110 ANT_SEL11 Antenna Select 11 0111 AUDIO_DEBUG_IN_2 AUDIO_DEBUG_IN_2 Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 28 /33...
  • Page 30 SPIM0 MOSI 0010 CM33_UART_RX CM33 UART RX 0011 KEYPAD_KPCOL_2 KEYPAD_KPCOL_2 CONN_BGF_MCU_AICE_ KPCOL_2 0100 BT N10 SWD TCKC 0101 PWM_7 PWM 7 0110 UART1_TX UART1 TX 0111 AUDIO_DEBUG_IN_4 AUDIO_DEBUG_IN_4 Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 29 /33...

  • Page 31: Rtc

    Power Management Unit (PMU). In retention mode, the PMU is turned off while the RTC module remains powered on. The RTC module only consumes 6µA in retention mode. Product Name EK-AI7933CLD Version Doc No 912-13903...

  • Page 32: Federal Communication Commission Interference Statement

    This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Country Code selection feature to be disabled for products marketed to the US/CANA Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07...
  • Page 33 The end user manual shall include all required regulatory information/warning as show in this manual. Limited module procedures Not applicable Trace antenna designs Not applicable RF exposure considerations Product Name EK-AI7933CLD Version Doc No 912-13903 Date 2024/08/07 Page 32 /33...

  • Page 34: Evk Schematic

    The final host product still requires Part 15 Subpart B compliance testing with the modular transmitter installed. 6. EVK Schematic The following figure is the Schematic of EK-AI7933CLD Product Name EK-AI7933CLD Version...
  • Page 35 AI7931LD / AI7933CLD / AI7933ALD Module SDIO_DAT3 SDIO_DAT3 GPIO_R_0 GPIO_R_0 AI7933CLD / ALD Only SDIO_DAT2 GPIO_R_1 SDIO_DAT2 GPIO_R_1 AI7933CLD / ALD Only SDIO_DAT1 GPIO_R_2 SDIO_DAT1 GPIO_R_2 AI7933CLD / ALD Only SDIO_DAT0 GPIO_R_3 SDIO_DAT0 GPIO_R_3 AI7933CLD / ALD Only SDIO_CMD SDIO_CMD GPIO_R_4 GPIO_R_4 AI7933CLD / ALD Only...
  • Page 36 Extra USB 5V Power DC to DC 3.3V VCCIO Switch EXUSB_5V DC_DC_3V3 R/0/Ohm/0402 Silkscreen TOP Base_3V3 "Only for power supply " IC_VCCIO Base_1V8 EXUSB_5V VCCIO18 header 3x1 WIP252012S-2R2ML PHYLDO_OUT CON8 JP3/DIP/P2.54 LX/SW UCE01SB3020-99R Reserve for EXT 5V header 3x1 PolyFuse-SSMD1812P110TF/16 JP3/DIP/P2.54 R/0/Ohm/0402 3V3_FB1...
  • Page 37 RTC Interrupt (AI7933CLD / ALD Only) DIP1/P2.54 PMU_EN_RTC_M PMU_EN_RTC EXT_PMU_EN R736 R/300/Ohm/0402 R737 R/1M/Ohm/0402 RTC_EVT R738 RTC_EVT Max. input 1.8V R/10K/0402/1% R739 R/15K/0402/1% Silkscreen TOP "RTC interrupt" SW-PUSHBUTTON SW4P/DIP/FLAT RTC_Reset V_2AA_B_I (3.6V~4.2V) Strap (Mode Selection) IC_VCCIO R760 NC/10K/0402/1% GPIO_B_6 R761 NC/10K/0402/1% GPIO_B_7 Silkscreen TOP...
  • Page 38 Module Audio Part (AI7933CLD Only) Audio Power Plan Volumn Key Pad Level Shift Circuit IC_VCCIO USB_3V3 R/0/Ohm/0402 EXUSB_5V Audio_VCC_5V R/0/Ohm/0402 R/0/Ohm/0402 C/0.1uF/0201 C/0.1uF/0201 C/0.1uF/0201 R/0/Ohm/0402 AU_AMP_MUTE IOVL1 IOVC1 AU_AMP_SD AVCC IOVL2 IOVC2 EZJZ0V800AA EZJZ0V800AA SW-PUSHBUTTON SW-PUSHBUTTON C/0.1uF/0201 NLSX4373 R/0/Ohm/0402 PVCCR 0/NC C/0.1uF/0201 Silkscreen TOP...
  • Page 39 GPIO USB CON (AI7933CLD / ALD Only) KPROW0 CON6 KPROW2 UCE01SB3020-99R R746 R/0/Ohm/0402 C_SDIO_CLK USB_IDDIG SDIO_CLK GPIO_R_5 MSDC0_CLK R747 NC/R/0/ohm/0402 USB_DP_P0 A_USB_DP Co-Pad R145 R/0ohm/0201 R/0ohm/0201 USB_DM_P0 R/0ohm/0201 USB_ID_C GPIO_T_6 KEY_SYSRST_B A_USB_DM R147 R/0ohm/0201 DLW21SN900HQ2L GPIO_T_8 R748 R/0/Ohm/0402 R149 R/0ohm/0201 R100 R/0ohm/0201 R/0ohm/0201...
