ADDER ADDERLink Portal R100 Series Instruction Manual

Main status indicators
• Off No power
• Green Operating - Video, USB and network link all present
• Orange Operating - But video, USB and/or network link missing.
• Green or orange flashing A user is connected.
• Red (momentarily) Unit is booting up, or
(consistently) Unit has failed, try rebooting.
• Red/green flashing Unit is in backup mode.
• Blue Factory reset has been activated.
• Red/blue flashing Unit is in upgrade mode.
SCAN FOR
PRODUCT PAGE
www.adder.com
© 2024 Adder Technology Limited • All trademarks are acknowledged.
Part No. MAN-QS-000087_V1.1
ADDERLink Portal R100 Series
™
Welcome
This quick start guide covers some of the key points of the ADDERLink Portal dongle. In combination
with Adder's ARDx Viewer, each ADDERLink Portal dongle provides highly secure remote connectivity
across the Internet or corporate network. Full user details and setup instructions can be found in the
Downloads section at www.adder.com/en/kvm-solutions/adderlink-portal-r110-dp
LAN or
Internet
Multiple remote
users (up to 8
concurrently)
Highly secure
Enterprise grade security (using 256-bit encryption and RSA 2048-bit public key authentication) is
employed as standard. This is further enhanced by the Adder ARDx Viewer, which allows the creation
of ciphered user communications.
User management
An unlimited number of user profiles (normal users plus those with admin rights) can be associated
with the ADDERLink Portal dongle. At any one time up to 8 remote users may access the unit
simultaneously, subject to available network bandwidth and content.
High quality remote video
Despite its small size the ADDERLink Portal dongle offers video streaming at resolutions up to 1920 x
1080 at frames rates up to 60fps with non-blocking access for up to eight remote users.
EDID management
The ADDERLink Portal dongle has intelligent EDID management allowing the user to specify the video
modes generated by the controlled device.
Initial configuration
Please see the next page for Connection details.
Quick Start
Single host computer
(or multiple hosts,
if using an optional
KVM switch)
