Electric Range
User manual
NSI6D*9550****

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NSI6D 9550 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung NSI6D 9550 Series

Summary of Contents for Samsung NSI6D 9550 Series

  • Page 1 Electric Range User manual NSI6D*9550****...
  • Page 2 Anti-tip device WARNING WARNING To reduce the risk of tipping the range, the range must be secured by a properly installed Anti-Tip device. AFTER THE RANGE HAS Do not step, lean, or sit on the doors of the range. You can cause the BEEN INSTALLED, CONFIRM THAT THE ANTI-TIP DEVICE HAS BEEN range to tip, resulting in burns or serious injuries.

  • Page 3: Table Of Contents

    Contents Important safety instructions Operating the oven What you need to know about safety instructions The control panel For your safety Lock Induction cooktop elements Display mode Electrical safety Clock Child safety Dual Door™ Oven Single mode Remote Operation Twin mode Self-cleaning ovens Cooking mode Ventilating hood...

  • Page 4: Important Safety Instructions

    Make sure the machine is grounded to prevent electric shock. installing, maintaining, and operating your oven. Call a Samsung service center for help. Important safety symbols and precautions Note What the icons and signs in this user manual mean: These warning signs are here to prevent injury to you and others.

  • Page 5: For Your Safety

    FOR YOUR SAFETY • Do not enter the oven. • Do not store items of interest to children in cabinets above When using electrical appliances, you should follow basic safety the range or on the back guard of the range. precautions, including the following: Children climbing on the range to reach items could be CAUTION...
  • Page 6 Important safety instructions • If there is a fire in the oven during self-cleaning, turn the • Use only dry potholders. Placing moist or damp potholders oven off and wait for the fire to go out. Do not force the on hot surfaces may result in burns from steam.

  • Page 7: Induction Cooktop Elements

    INDUCTION COOKTOP ELEMENTS • Never leave surface elements unattended at high heat settings - Boilovers cause smoking and greasy spillovers that • Be sure you know which touch control operates each surface may ignite. A pan that has boiled dry may melt. heating unit.

  • Page 8: Electrical Safety

    If your appliance is in • Ensure that the appliance is switched off before replacing the need of repair, contact a Samsung authorized service center. lamp to avoid the possibility of electric shock. Failure to follow these instructions may result in damage and •...

  • Page 9: Oven

    WARNING • Use care when opening the door. Let hot air or steam escape before you remove food from or put food into the oven. Accessible parts may become hot during use. To avoid burns, young • Protective liners. Do not use aluminum foil to line the oven children should be kept away.

  • Page 10: Remote Operation

    Important safety instructions SELF-CLEANING OVENS CAUTION Do not attempt to operate the oven during a power failure. If the Do not clean the door gasket. The door gasket is essential for power fails, always turn the oven off. If the oven is not turned off a good seal.

  • Page 11: Ventilating Hood

    GLASS/CERAMIC COOKING SURFACES • Before operating the self-clean cycle, wipe grease and food soils from the oven. Excessive amounts of grease may ignite, • DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS. leading to smoke damage to your home. Surface units may be hot even though they are dark in color.

  • Page 12: Critical Installation Warnings

    Important safety instructions CRITICAL INSTALLATION WARNINGS • Install your appliance on a hard, level floor that can support its weight. WARNING - Failing to do so may result in abnormal vibrations, noise, or problems with the product. • This appliance must be installed by a qualified technician or •...

  • Page 13: Critical Usage Warning

    • If the appliance is flooded by any liquid, please contact your contact an authorized Samsung service center near you. nearest Samsung service center. Failing to do so may result in • If you use the appliance when it is contaminated by foreign electric shock or fire.
  • Page 14 • Make sure that the appliance’s controls and cooking areas are - When a repair is needed, contact your nearest Samsung out of the reach of children. service center. - Failing to do so may result in electric shock, burns, or injury.
  • Page 15 - If the door is damaged, do not use the appliance. them. Make a hole in food items that have shells (eggs, Contact a Samsung service center. chestnuts, etc) with a knife before cooking them. • Do not hold food in your bare hands during or immediately - Failing to do so may result in burns or injury.

  • Page 16: Usage Cautions

    Important safety instructions USAGE CAUTIONS • Take care when heating liquids, such as water or other beverages. CAUTION - Make sure to stir during or after cooking. - Avoid using a slippery container with a narrow neck. • If the surface is cracked, turn the appliance off. - Wait at least 30 seconds after heating before removing the - Failing to do so may result in electric shock.
  • Page 17 • Do not put your face or body close to the appliance while • Do not use sealed containers. Remove seals and lids before cooking or when opening the door just after cooking. cooking. Sealed containers can explode due to the build up of - Take care that children do not come too close to the pressure even after the oven has been turned off.

  • Page 18: Critical Cleaning Warnings

    Important safety instructions CRITICAL CLEANING WARNINGS BATTERY USAGE (7 inch LCD Display models only) CAUTION • Remove and immediately recycle or dispose of used batteries • Do not clean the appliance by spraying water directly on to according to local regulations and keep away from children. Do NOT dispose of batteries in household trash or incinerate.

  • Page 19: California Proposition 65 Warning

    GENERAL EMC INSTRUCTIONS WARNING (FOR INDUCTIONS COOKTOP MODELS ONLY) • INGESTION HAZARD: This product contains a button 1. FCC Notice cell or coin battery. FCC STATEMENT: • DEATH or serious injury can occur if ingested. This appliance has been tested and found to comply with the limits for a class B digital device, pursuant to Part 18 of the FCC rules.

  • Page 20: Introducing Your New Range

    Gliding rack (1) * Air Fry tray (1) * Divider (1) * NOTE If you need an extra accessory marked with a *, you can buy it from the Samsung Contact Center (1-800-726-7864). 01 Control panel 02 Vent 03 Oven door (See page 22 for more information.)

  • Page 21: Before You Begin

    Before you begin Surface cooking Clean the oven thoroughly before using it for the first time. Then, remove the About induction cooktop cooking accessories, set the oven to bake, and then run the oven at 400 °F for 1 hour. There will be a distinctive odor.
  • Page 22 Surface cooking • Do not use the induction range to dry clothes. Location of the induction cooktop elements and controls • Never store flammable materials such as aerosols and detergents in the drawer The induction control knobs operate the induction surface elements on the cooktop or cupboards under the induction cooktop.

  • Page 23: How To Set The Appliance For Cooktop Cooking

    How to set the appliance for cooktop cooking A. To use the Power boost setting, tap the Boost. CAUTION • The cooktop elements may be hot even when off and burns can occur. Do not touch the cooktop elements until they have cooled down sufficiently. •...

  • Page 24: Before Using The Cooktop

    Surface cooking Sync control Before using the cooktop You can use Sync control to operate and control the two elements on the left side simultaneously, as a single cooking zone, and then use the zone for large Use quality cookware in good condition cookware.

  • Page 25: Cookware For Induction Cooking Zones

    Cookware for induction cooking zones CORRECT INCORRECT The Induction element can only be turned on when cookware with a magnetic base is placed on one of the cooking zones. You can use the cookware identified as suitable below. Curved or warped pan bottoms or Flat pan bottom &...

  • Page 26: Using The Correct Size Cookware

    Surface cooking Using the correct size cookware Operating noises • The Induction Cooking Zones require that you use pots and pans of a minimum You may hear the following operational noises: size or larger at each location. The inner ring of each Cooking Zone is your •...

  • Page 27: Compatibility Test

    Better pans produce better results Compatibility test • You can recognize good pots and pans by their bases. The base should be as thick and flat as possible. 1. Press and hold the Power button for more than 1 second to activate the •...

  • Page 28: Temperature Detection

    Surface cooking Temperature detection Suggested settings for cooking specific foods If for any reason the temperatures on any of the cooking zones exceeds the safety The figures in the table below are guidelines. The power settings required for level, then the cooking zone will automatically reduce the heat to a lower power various cooking methods depend on a number of variables, including the quality level.

  • Page 29: Protecting The Cooktop

    Operating the oven Protecting the cooktop The control panel Cleaning • Clean the cooktop before using it for the first time. • Clean your cooktop daily or after each use. This will keep your cooktop looking good and can prevent damage. •...

  • Page 30: Lock

    Operating the oven Lock Display mode This feature lets you lock Cooktop controls, Oven controls, and Oven door so they Sleep mode cannot be activated accidentally. The control panel enters Sleep mode if the oven is not used for a while. How to activate the Lock feature In Sleep mode, the control panel is inactive until it is reactivated by the user.

  • Page 31: Clock

    Clock Dual Door™ You must set the clock correctly to ensure the automatic features work properly. This oven has a unique Dual Door™ that is hinged in the middle. If you have This product supports two time formats: 12-hour (default) and 24-hour. inserted the Smart Divider and divided the oven in two (so it is in Twin Mode), you only need to open the top half to access the upper cavity.

  • Page 32: Single Mode

    Operating the oven How to use the full door Single mode 1. Hold the handle only and then pull. STEP 1 Put all ingredients in a heat-safe container. STEP 2 Select a cooking mode, and then start 2. This will open the whole door as shown. preheating.

  • Page 33: Twin Mode

    Twin mode STEP 4 Place a wire rack into the oven, arrange STEP 1 food containers on the racks. Put all ingredients in a heat-safe container. STEP 2 Insert the divider into the 4th rack position and push in until the range beeps. STEP 5 Close the door and start cooking.

  • Page 34: Cooking Mode

    Operating the oven NOTE • To use Twin mode operation, insert the divider. • The cooling fan automatically runs for a certain amount of time after cooking is complete. • When you are not using the divider, store it at room temperature. •...
  • Page 35 Single Mode Twin Mode Temperature Default Temperature Default Mode Set Cook Time Delay Start Mode Set Cook Time Delay Start range (°F) temperature (°F) range (°F) temperature (°F) Bake 175 - 550 Upper Broil Hi-Lo Broil Hi / Lo Convection 175 - 550 Convection Bake...

  • Page 36: Twin Mode Temperature Setting Ranges

    Operating the oven Twin Mode Temperature setting ranges (O - Available, X - Not available) Upper Oven Your oven has different temperature setting ranges when you use the upper oven Lower Oven Available Setting Function and Temp. and lower oven simultaneously. The range for each oven changes, depending on the function and temperature setting of the other oven.

  • Page 37: Using The Oven Racks

    Using the oven racks Twin Mode - Two Ovens In Twin mode, the divider separates the oven into an upper oven and lower oven. The upper oven and lower oven each have 3 rack positions. Single Mode - Full Oven Rack position Your oven range comes with 2 racks and 7 rack positions.
  • Page 38 Operating the oven Inserting and removing an oven rack Rack and Pan placement Centering the baking pans in the oven as To insert an oven rack much as possible will produce better results. 1. Place the rear end of the rack on a rack If baking with more than one pan, place the guide.

  • Page 39: Using The Gliding Rack

    Before using the racks Using the gliding rack The oven has two racks. The fully extendable Gliding rack makes food preparation easier, especially when Each rack has stops that need to be placed correctly on the supports. These stops you are preparing heavier dishes. The Gliding rack has 2 glide tracks that allow will keep the rack from coming completely out.

  • Page 40: Using The Divider

    Operating the oven Removing the Gliding rack Using the divider • With the Gliding rack in the "Closed" • To use twin mode operation, insert the divider. position and the oven off and cool, grasp • You cannot use the Self-Clean or Steam-Clean functions when the divider is the rack and frame and pull both forward installed in the oven cavity.

  • Page 41: Recipe Guide

    Recipe guide Convection cooking The convection fan at the back of the oven circulates hot air evenly throughout the CAUTION oven cavities so that food is evenly cooked and browned in less time than with Always use this cooking mode with the regular heat.
  • Page 42 Operating the oven Convection Vegetable recommendation guide • Ideal for foods being cooked using multiple racks. • Preheating is not necessary. • Good for large quantities of food. • For best results, use this mode on a single oven rack and place the dish on the •...
  • Page 43 • If you leave the oven door open for more than 2 minutes when the oven is on, • For more information, the Samsung website offers special menus and recipes to all heating elements will shut off automatically.
  • Page 44 Operating the oven Broiling guide Air Fry This feature uses hot air for crispier and healthier frozen or fresh foods without, NOTE or less oil, than normal convection modes. For best results, use this mode on a For reference only. single oven rack and place the Air Fry tray on the position 3.(in upper oven of •...
  • Page 45 • Before using a baking ware, check the maximum allowable temperature of Air Fry recommendation guide baking sheet. Time (Min.) • Place under a few sheets of paper like parchment paper to absorb the fat for Amount Temperature Item Single Upper Tips reducing splatter and smoke during the Air Fry.
  • Page 46 Operating the oven Time (Min.) Time (Min.) Amount Temperature Amount Temperature Item Tips Item Tips Single Upper Single Upper (oz) (°F) (oz) (°F) oven oven oven oven Frozen Vegetables Chicken 30 - 35 425 - 450 20 - 30 20 - 25 Asparagus, Dip sliced vegetables 15 - 20...
  • Page 47 Air Sous Vide recommendation guide NOTE • It is not necessary to preheat the oven Food Doneness Temperature (°F) Time (hrs.) when using Air Sous Vide mode. • Place the vacuum sealed bags of food on Beef the rack 4 of the oven. Rare 2.5 - 4 •...
  • Page 48 Operating the oven Dehydrate Food Doneness Temperature (°F) Time (hrs.) Dehydrate dries food or removes moisture from food via heat circulation. After Vegetables drying the food, keep it in a cool and dry place. For fruit, adding lemon (or pineapple) juice or sprinkling sugar on the fruit helps the fruit retain sweetness. Asparagus 0.5 - 2 NOTE...

  • Page 49: Cooking Options

    Cooking options Delay Start The Delay Start function lets you use the kitchen timer to automatically start CAUTION and stop another cooking program. You can set Delay Start so that it delays the automatic start of a cooking operation you select by up to 12 hours. Food that can easily spoil, such as milk, eggs, fish, poultry, and meat, should be Mode: Bake / Convection Bake / Convection Roast / Convection Vegetable / chilled in a refrigerator before they are placed in the oven.

  • Page 50: More Functions

    Operating the oven More functions Oven settings Setting Description Tap and hold 3 seconds on the control panel, and then use the drag slider to change various settings for your oven. Please refer to the following table Set the timer. The timer gives you an extra timer you Timer for detailed descriptions.

  • Page 51: Smart Control

    Smart control Setting Description Set the clock to display the time in the 12-hour or Use 24-hr format How to connect the oven 24-hour format. 1. Download and open the SmartThings app on your smart device. Set the clock to display the current date and time. 2.

  • Page 52: Voice Control

    When the app is connected to the oven, you can perform the following Bixby functions through the application: • Bixby is the name of Samsung's artificial intelligence solution that makes it possible to control the product by voice. Oven remote control using the SmartThings app •...

  • Page 53: Special Features

    Special features To enable the Sabbath feature The Sabbath feature (For use on the Jewish Sabbath and Holidays) Use this option only for baking on the Jewish Sabbath and Holidays. For more information, visit the website at http://www.star-k.org With the Sabbath feature •...

  • Page 54: Maintaining Your Appliance

    Operating the oven Maintaining your appliance Self-cleaning CAUTION • Do not attempt to activate any other functions except for Bake when the This self-cleaning oven uses high temperatures (well above cooking temperatures) Sabbath feature is on. Only the following functions will function properly: to burn off leftover grease and residue completely or reduce them to a finely Bake, Oven Start/Set, and Oven Off.
  • Page 55 Before a self-cleaning cycle How to run a self-cleaning cycle 1. Make sure the oven door is closed completely and unlocked. Turn off all oven • We recommend venting your kitchen and cooktop functions. with an open window or using a 2.

  • Page 56: Steam-Cleaning

    Maintaining your appliance How to turn off the self-cleaning feature Steam-cleaning You may find it necessary to stop or interrupt a self-cleaning cycle due to smoke in the oven. How to set the oven for steam-cleaning 1. Tap Stop. For light cleaning, the steam-cleaning function saves time and energy. For heavier- 2.

  • Page 57: Care And Cleaning Of The Oven

    Care and cleaning of the oven CAUTION Wear the glove during cleaning. WARNING After a steam-cleaning cycle • Be sure all controls are OFF and all surfaces are COOL before cleaning any part of the range. • Take care when opening the door before a steam-cleaning procedure has ended. •...
  • Page 58 Maintaining your appliance Cleaning painted parts and decorative trim Air Fry tray • For general cleaning, use a cloth with hot, soapy water. To keep the Air Fry tray clean, remove them from the cavity, and soak them in • For more difficult residue and built-up grease, apply a liquid detergent directly Lukewarm soapy water.

  • Page 59: Care And Cleaning Of The Glass Cooktop

    Drawer Handle Care and cleaning of the glass cooktop Remove dust with soft brush or soft cloth covered with water. Normal daily use cleaning CAUTION Use only a ceramic cooktop cleaner. Other creams may not be as effective. • Do not use alkaline detergents, By following these steps, you can maintain and protect the surface of your glass sulfuricacid, hydrochloric acid, organic cooktop.
  • Page 60 Maintaining your appliance Removing heavy, burned-on residue Cleaning the cooktop seal 1. Allow the cooktop to cool. To clean the seal around the edges of 2. Use a single-edge razor-blade scraper at the glass, lay a wet cloth on it for a few approximately a 45°...

  • Page 61: Removing And Reinstalling The Oven Door

    Removing and reinstalling the oven door 5. Lift door up and out until the hinge arm is clear of the slot (Fig. 2). How to remove the door CAUTION • The door is very heavy. Be careful when removing and lifting the door. Do not lift the door by the handle.

  • Page 62: Removing And Reinstalling The Storage Drawer

    Maintaining your appliance Removing and reinstalling the storage drawer Hinge lock Hinge lock 1. Slide open the drawer until it stops. 2. Locate the roller guide clips on either side. Using both hands, pull down the left clip while lifting the right clip, and then remove the drawer.

  • Page 63: Changing The Oven Light

    The oven light is a standard 40-watt appliance bulb. It will come on when the oven Samsung works hard to ensure that you don’t have problems with your new electric range. If you run into unexpected trouble, look first for a solution in the door is open.
  • Page 64 Troubleshooting CONTROL DISPLAY Problem Possible cause Solution The surface unit The element will cycle on This is normal operation, Problem Possible cause Solution frequently cycles and off to maintain the and not a system failure. The display goes A fuse in your home may Replace the fuse or reset on and off.
  • Page 65 OVEN Problem Possible cause Solution Brown streaks or Boilovers have been cooked • Wait until the surface Problem Possible cause Solution specks. onto the surface. cools down. Then, use a The oven will The range is not completely Make sure the electrical single-edge razor-blade not turn on.
  • Page 66 Troubleshooting Problem Possible cause Solution Problem Possible cause Solution The oven The oven controls have not Refer to the section on using Food does not The serving size may not be Refer to the cooking guide for smokes been set properly. the broiler starting on page broil properly.
  • Page 67 Problem Possible cause Solution Problem Possible cause Solution Excessive There is excessive soiling in Tap Stop. Open the windows Strong odor. An odor coming from the Operate the oven empty on smoking during the oven. to rid the room of smoke. insulation around the inside the bake setting at 400 °F for a self-cleaning...

  • Page 68: Information Codes

    Troubleshooting Information codes Displayed Possible cause Solution code OVEN The sub PCB sensor is open Tap Stop, and then restart the when the oven is operating. Displayed C-22 oven. If the problem persists, Possible cause Solution There is a short in the sub PCB code disconnect all power to the sensor.
  • Page 69 The IGBT sensor is short when the If the problem still EEP-ROM failed. burner is operating. continues, contact a local Samsung service center. This code occurs if the DC fan motor is open or locked. English 69...

  • Page 70: Warranty (U.s.a)

    SAMSUNG authorized servicer is not available, you may customer’s responsibility. be responsible for a trip charge or required to bring the product to a SAMSUNG Visits by an authorized servicer to explain product functions, maintenance or authorized service center for service.

  • Page 71: Warranty (Canada)

    To receive in home service product must be unobstructed and accessible No warranty or guarantee given by any other person, firm, or corporation with to the service agent. If service is not available Samsung may elect to provide respect to this product shall be binding on SAMSUNG.
  • Page 72 Warranty (CANADA) SAMSUNG will repair or replace this product, at our option and at no charge EXCEPT AS SET FORTH HEREIN THERE ARE NO WARRANTIES ON THIS as stipulated herein, with new or reconditioned parts or products if found to PRODUCT EITHER EXPRESS OR IMPLIED AND SAMSUNG DISCLAIMS ALL be defective during the limited warranty period specified above.

  • Page 73: Appendix

    Appendix Memo Open Source Announcement The software included in this product contains open source software. The following URL http://opensource.samsung.com/opensource/SMART_TP1_0/ seq/0 leads to open source license information as related to this product. English 73...
  • Page 74 * Requires reader to be installed on your smartphone Scan this with your smartphone Please be advised that the Samsung warranty does NOT cover service calls to explain product operation, correct improper installation, or perform normal cleaning or maintenance. QUESTIONS OR COMMENTS?
