MODE 3001-L-50 Manual

Led mirrors
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

3001-L-50
(
Power Rating:15W)
3153-L-7050
(Power Rating:23W)
3153-L-8060
(Power Rating:27W)
LED
MIRRORS
3100-L-6060
( Power Rating:11W)
3100-L-8060
(Power Rating:16W)
3155-L-7050 (Power Rating:23W)
3155-L-6060 (Power Rating:23W)
3155-L-8060 (Power Rating:27W)
3155-L-10060 (Power Rating:32W)
3162-L-3950
(Power Rating:11W)
3162-L-5070
(Power Rating:16W)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3001-L-50 and is the answer not in the manual?

Questions and answers

Related Manuals for MODE 3001-L-50

Summary of Contents for MODE 3001-L-50

  • Page 1 MIRRORS 3100-L-6060 3162-L-3950 3001-L-50 ( Power Rating:11W) (Power Rating:11W) Power Rating:15W) 3100-L-8060 3162-L-5070 (Power Rating:16W) (Power Rating:16W) 3153-L-7050 3155-L-7050 (Power Rating:23W) (Power Rating:23W) 3155-L-6060 (Power Rating:23W) 3153-L-8060 3155-L-8060 (Power Rating:27W) (Power Rating:27W) 3155-L-10060 (Power Rating:32W)
  • Page 2 BEFORE YOU START, HERE IS SOME IMPORTANT INFORMATION. 1) General Information Please inspect this product upon delivery. Any missing parts or manufacturing defects must be reported immediately to the supplier. Damage or defects reported later will not be accepted. TAKE CARE WHEN HANDING GLASS PARTS- AVOID HEAVY CONTACT BETWEEN THE GLASS EDGES AND ANY HARD SURFACE.

  • Page 3: Tools Required

    3155-L-7050 / 3155-L-6060 3 LED driver /3155-L-8060/3155-L-10060 4 IP44 terminal box Demister pad 2 Touch on/off and dimming 3 LED driver 4 IP44 terminal box 3001-L-50 Demister pad 2 Touch on/off and dimming 3 LED driver 4 IP44 terminal box...

  • Page 4: Installation Steps

    INSTALLATION STEPS STEP 1 ISOLATE THE MAINS POWER SUPPLY TO THE ELECTRICAL FEED THAT WILL POWER YOUR MIRROR. STEP 2 Do not stand the mirror upright on hard surfaces whilst fitting, as this will damage the corners. Measure the distances of the four screw fixing slot centers at back of chassis. STEP 3 Decide on position on the wall and mark the four centers, ensuring your power supply cable will...
  • Page 5 STEP 5 Wire the main power supply to the IP44 terminal block at back of mirror as belows. RED OR BROWN --- TERMINAL MARKED L (LIVE) BLACK OR BLUE --- TERMINAL MARKED N (NEUTRAL) GREEN & YELLOW --- TERMINAL MARKED E OR WARNING: This appliance must be earthed.

  • Page 6: Care And Maintenance

    CARE AND MAINTENANCE 1) AFTER CARE INSTRUCTIONS It is recommended that mirrors are cleaned with a soft, dry, non-abrasive cloth. Do not use abrasive cleaning materials, or chemical cleaners as this will damage the mirror surface and edges. 2) MAINTENANCE The supplier accepts no liability for any type of use of care other than those contained in this instruction.

This manual is also suitable for:

3100-l-60603100-l-80603162-l-39503162-l-50703153-l-70503153-l-8060 ... Show all
