GREISINGER electronic GDH 12 AN Operating Manual

H18.0.03.6C-01
Operating Manual for Digital Precision Manometer
Specification:
Measuring range:
Overload:
Resolution:
Accuracy (device):
Drift (device):
Sensor:
Sensor accuracy:
(typ.)
[Option]:
(typ.)
Operating temperature:
Relative humidity:
Storage temperature:
Display:
Analog output:
Power supply:
Power consumption:
Mains connection:
Low battery warning:
Dimensions (device):
Dimensions (sensor):
Weight:
EMC:
GREISINGER
D - 93128 Regenstauf, Hans-Sachs-Straße 26
Tel.: 0049-9402/8500, Fax: 0049-9402/1829, e-mail: info@greisinger.de
GDH 12 AN
0 to 1300 mbar absolute.
max. 2 bar abs.
(sensor will neither be destroyed nor will a recalibration be necessary)
1 mbar
1 mbar ± 1 digit (at nominal temperature 25°C)
0.01 % / K
piezoresistive absolute pressure sensor, externally mounted in plastic case, connection terminal for
plastic tube 6 x 1 mm (4 mm i.d.), approx. 1 m of 4-wire PVC connecting cable with 4-pin mini DIN
plug. Temperature in sensor is compensated from 0 to 70° C.
Sensor suitable for non-corrosive and non-ionising gases and liquids (do not use for water - air
cushion or hydrophobic filter).
± 0.2% full scale hysteresis and linearity
± 0.4% full scale temperature influence: 0 to 50°C
± 0.1% full scale hysteresis and linearity
± 0.2% full scale temperature influence: 0 to 50°C
device: 0 to 50°C
sensor: -40 to 85°C (temperature in sensor is compensated from 0 to 70° C)
0 to 80 % r.F. (non-condensing)
-10 to 70°C
3½ digit LCD-display , approx. 13 mm high
0 - 1 V DC equiv. 0 to 1300 mbar
connection over 3.5 mm dia jack connector (plug included in scope of supply)
9V battery, type JEC 6F22 (in scope of supply)
approx. 5 mA
2.5 mm socket for external 10 - 12V supply voltage. (suitable power pack: GNG10)
Battery will be automatically disconnected as soon as power pack is connected.
"BAT" displayed automatically in case of low battery
approx. 150 x 86 x 30 mm (H x W x D), impact resistant ABS plastic housing
with integrated pop-up clip for table-top or uspended use.
approx. 67.5 x 26 x 15 mm (H x W x D), with suspension eye
approx. 340g (device ready for operation)
The device corresponds to the essential protection ratings established in the Regulations of the
Council for the Approximation of Legislation for the member countries regarding electromagnetic
compatibility (89/336/EWG).
Additional error: <1%
