Glasdon TOPSY 65 LITTER BIN Operating Manual

TOPSY™ 65 LITTER BIN
Prior to installation, it may be necessary to restrain the plinth to prevent it from spinning when removing the hood. Glasdon
recommends ALL TOPSY litter bins be ground fixed or ballasted to maximise the performance of the unique locking system.
The bin must be sited on level ground. If you are not using Glasdon fixings you must ensure that 50mm diameter washers are used in
Ensure that all relevant personnel read the points listed within this leaflet and that a copy is given to staff involved with the
OPERATING THE BIN
OPENING/CLOSING WITH KEY & LOCK
1.
To open, ensure the illustration
on the key is uppermost. Then
insert the key all the way into
the lock. (Do not turn the key.)
This will release the locking
mechanism.
OPERATING MANUAL
IMPORTANT NOTE:
order to secure the bin when ground fixing.
maintenance of this product.
2.
With the key still in position,
turn bin body anti-clockwise,
and lift the bin body over the
liner.
3.
Remove the key from the lock.
1 of 2
4.
To close, lift bin body over the
liner and lower to rest on plinth,
turn clockwise until the bin
body engages with the plinth
track way and locks with a click.
