GLASDON JUBILEE
DUO 220
OPERATING & INSTALLATION MANUAL
IMPORTANT NOTE:
The bin must be sited on level ground to ensure correct alignment of the doors and body. If you are
not using Glasdon fixings you must ensure that 50mm diameter washers are used in order to secure
the bin when ground fixing.
Ensure that all relevant personnel read the points listed within this leaflet and that a copy is given to
staff involved with the installation and maintenance of this product.
1 of 8
Advertisement
Table of Contents
Related Manuals for Glasdon JUBILEE DUO 220
Summary of Contents for Glasdon JUBILEE DUO 220
- Page 1 The bin must be sited on level ground to ensure correct alignment of the doors and body. If you are not using Glasdon fixings you must ensure that 50mm diameter washers are used in order to secure the bin when ground fixing.
- Page 2 OPERATING & INSTALLATION MANUAL CONTENTS PAGE SECTION 1 OPERATING THE BIN Open/Closing Keyed Version Open/Closing Keyless Version Removing Liner/Using Sack Retention Inserting/Removing Bait Box Inserting/Removing Poster Removing/Replacing Aperture Panels Ashtray Emptying SECTION 2 CLEANING Liner Tray SECTION 3 INSTALLATION / FIXING INSTRUCTIONS Concrete Foundation Fixing Kit Paving Slab Fixing Kit Concrete-In Anchor (Adjustable Depth) Fixing Kit...
- Page 3 SECTION 1 - OPERATING THE BIN OPENING/CLOSING - KEYED VERSION Place foot into base recess, on Insert key into keyhole. Turn Using the foot recess and the Slam to shut. the left hand door as shown. key anticlockwise until it stops. key, lift the door and allow it Note: Right hand door must be to pivot open.
- Page 4 REMOVING/INSERTING LINER TRAY AND FITTING BAIT BOX Glasdon Jubilee Duo 220L Bin. Max. size bait box 280 x 280 x 130mm Remove the liner tray by Insert bait box into position Reposition liner tray into bin removing the fixings with a...
- Page 5 ASHTRAY OPERATING INSTRUCTIONS Open both doors as detailed Using the handle, slide the Empty contents of the liner. Slide ashtray liner back into the previously. (‘Opening/Closing’) ashtray liner out. Use other bin compartment making sure hand to support the liner. the handle is facing towards you.
- Page 6 SECTION 3 - INSTALLATION / FIXING INSTRUCTIONS IMPORTANT SAFETY NOTE: To ensure a secure and robust installation the bin should be sited onto a sound concrete foundation and the 50mm diameter washer must be used. We strongly recommend that the bin is NOT installed onto tarmac or block paved areas.
- Page 7 CONCRETE-IN ANCHOR FIXING KIT ADJUSTABLE DEPTH KIT CONTENTS (BINS WITH 4 FIXING POINTS): TOOLS/EQUIPMENT REQUIRED: - Adjustable concrete-in fixing - 6mm Allen key - Washer M10x50mm - Equipment to excavate hole - Fixing screw M10x80mm - Concrete mix (fast setting) METHOD: Check for buried services before starting installation.
- Page 8 GLASDON cannot be held responsible for claims arising from incorrect installation, unauthorised modifications or misuse of the product. Stock No. C000/1045 - DWG No. 07B381-13 Issue 1 - July 2023 © Copyright 07/2023 Glasdon UK Ltd reserve the right to alter specifications without prior notice. 8 of 8...
