Current EVOLVE ESPL Installation Manual

LED Floodlight
Sports Lighter (ESPL)
BEFORE YOU BEGIN
Read these instructions completely and carefully.
Save these instructions for future use.
WARNING
Fixtures must be grounded and installed in accordance with
the National Electrical Code and all local codes. Failure to do
so may increase the RISK OF PERSONAL INJURY, PROPERTY
DAMAGE, FIRE AND DEATH. Install and use so fixture failures
do not cause a hazard and use only in environments for which
the product is specifically marked.
WARNING
This product contains chemicals known to the State of
California to cause cancer, birth defects, and/or other
reproductive harm. Thoroughly wash hands after installing,
handling, cleaning, or otherwise touching this product.
Note: This luminaire is designed for oudoor lighting
applications and ambient temperatures not exceeding 40
(104 o F).
• All electrical work must be done by a qualified electrician.
• Turn off electric power to all affected circuits and allow to
cool before installation or servicing.
• A regularly scheduled maintenance program should be
established to retain optimum light output and reduce
heat retention. Dusting with a soft, clean, dry cloth
Storage & Handling
1
-40° C
-40° F
Store packaged units in a covered dry area
LED.com
© 2023 Current Lighting Solutions, LLC. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
Dangerous voltage exist within the unit and all precautions
usually observed in handling high voltage equipment should
be observed when replacing light engine or otherwise servicing
luminaires. Disregarding this warning could result in electrical
shock and possible injury to the individual installing or servicing
this equipment. Installation and servicing should be done by
qualified personnel.
Follow ALL luminaire recommendations, product markings,
instructions, restrictions and warnings regarding luminaire
operation and burning position. Luminaire label shows
electrical and environmental requirements and restrictions.
is normally sufficient for the optical system. Any
accumulation of dust or dirt should be removed regularly.
o C
• Carefully read these instructions before installing product.
If you do not understand these instructions, before
starting any work, contact your Lighting distributor or
techsupport@currentlighting.com or (864) 678-1000
• Give instructions to facility owner/manage for future
reference.
+50° C
+122° F
Check for damage
Installation Guide
WARNING
WARNING
Do not impact Do not stack
GEH-6081-LED-Evolve-Sports-Lighter-Floodlight-InstallGuide_R01
Page 1 of 6
(Rev 05/28/23)
