- Page 1 INSTALLATION MANUAL ET Solar Series Module Installation | Safety instructions | Maintenance Version:2023Q2...
-
Page 2: Table Of Contents
6.2 The visual inspection of the modules ............- 13 - 6.3 Inspection of the connector and cable ..........- 14 - Disclaimer of liability ....................- 14 - Appendix 1: Electrical ratings of ET Solar modules ............. - 14 -... -
Page 3: Introduction
Non-compliance with this installation instruction may result in property damage and/or physical injury. ET Solar will not be liable for compensation of any loss or injury caused by this type of non-compliance. 2 Codes and regulations The mechanical and electrical installation of PV systems should be performed in accordance with all applicable codes, including electrical codes, building codes and electric utility interconnection requirements. -
Page 4: Safety Precautions For Installing A Solar Photovoltaic System
3.1 Safety precautions for installing a solar photovoltaic system Regular safety: ET Solar Modules are designed to meet the requirement of IEC 61215 and IEC61730, application class A. Modules rated for use in this application class may be used in system operating at greater than 50VDC or 240W, where general contact access in anticipated. -
Page 5: General Installation Notes
www.etsolar.hk Keep children well away from the system while transporting and installing mechanical and electrical components. Completely cover all modules with an opaque material during installation to prevent electricity from being generated. Do not wear metallic rings, watchbands, ear, nose, or lip rings or other metallic devices while installing or troubleshooting photovoltaic systems. -
Page 6: Fire Rating
4 Mechanical Installation 4.1 Installation requirement ET Solar bears NO responsibility for any damage caused by the use of unsuitable or inappropriate mounting / fixing systems. Before starting with the mounting process, the strength of mounting / fixing structure on the panel field must meet the local loading condition, e.g. -
Page 7: Selecting The Proper Mounting Structure And Hardware
www.etsolar.hk Shading on the module will reduce electricity production. Do not install the module near equipment or in locations where flammable gases can be generated or collected. A minimum angle of 10° is recommended in order to make ... -
Page 8: Mounting With Clamping Hardware
www.etsolar.hk Mounting with clamping hardware 4.2.2 When choosing clamp mounting method, please be sure to use at least four clamps on each module, two clamps should be attached on each long sides of the module. Depending on the local wind and snow loads, if excessive pressure load is expected, additional clamps or support would be required to ensure the module can bear the load. -
Page 9: Installation Position And Static Loads
www.etsolar.hk Installation position and static loads 4.2.3 Maximum Static load(test load) of the PV module by: front 5400pa and back 2400pa, these values can vary depending on installation method of the modules (please refer to the following installation methods) Installation Methods and corresponding max pressure relation Installation methods Clamp Clamp... -
Page 10: Electrical Installation
When using lay-in lugs, the grounding conductor should be inserted into the opening indicated in the figure, and secured using the set screw. Expect for equipment grounding, ET Solar recommends the negative pole of PV module array is connected to earth during all PV system installations. That... -
Page 11: Wire
EN50618(or IEC62852 ) All field wiring cables must have large enough cross- sectional areas approved for use at the maximum short-circuit current of the PV module. ET Solar recommends that installers use only sunlight resistant cables for direct current (DC) wiring in PV systems. The recommended minimum wire size should be 4 mm²(12AWG) and must be subject to the local national codes... -
Page 12: Connectors
Notice, bypass diode is not the overcurrent protection device. If the diode is suspected to be defective, the installer or system providers shall contact ET Solar. Please do not try to open the junction box by yourself. -
Page 13: Operation And Maintenance
ET Solar recommends the following maintenance items to ensure optimal performance of the module. 6.1 Cleaning This manual covers the requirements for the cleaning procedures of ET Solar PV modules. Professional installers should read these guidelines carefully and strictly follow these instructions. Failure to follow these instructions may result in death, injury, or property damage. - Page 14 www.etsolar.hk not have"self-cleaning" function as those installed at 10° or larger tilt angles. The back surface of the monofacial module usually does not need to be cleaned. When cleaning the back of the bifacial module, avoid any sharp objects that may cause damage or penetrate the base material.
-
Page 15: The Visual Inspection Of The Modules
The maximum water pressure recommended is 4 MPa (40 bar) Method B: Compressed Air ET Solar recommends using this method to clean the soft dirt (like dust) on modules. This technique can be applied as long as the method is efficient enough to clean the modules considering the on-site conditions. -
Page 16: Inspection Of The Connector And Cable
PV product. No license is granted by implication or otherwise under any patent or patent rights. The information in this manual is based on ET Solar's knowledge and experience and is believed to be reliable, but such information including product specification (without limitations) and suggestions does not constitute a warranty, expressed or implied. - Page 17 Module Type Dimension (tolerance+/- System fuse with with power: power: 3%) Pmax(W) voltage(V) rating(A) +/-3% +/-3% Vm(V) Im(A) Voc(V) Isc(A) 156.75*156.75mm ET-M672370WW/WB 1966x992*40 48.45 9.88 39.7 9.32 1500 ET-M672375WW/WB 1966x992*40 48.68 9.97 40.02 9.37 1500 ET-M672380WW/WB 1966x992*40 48.9 10.08 40.33 9.43...
- Page 18 2008x1002x35 ET-M672BH390WW/WB/BB 49.3 10.12 41.1 9.49 1500 2008x1002x40 2008x1002x35 ET-M672BH395WW/WB/BB 49.5 10.23 41.4 9.55 1500 2008x1002x40 2008x1002x35 ET-M672BH400WW/WB/BB 49.8 10.36 41.7 1500 2008x1002x40 2008x1002x35 ET-M672BH405WW/WB/BB 50.1 10.48 9.65 1500 2008x1002x40 2008x1002x35 ET-M672BH410WW/WB/BB 50.4 10.6 42.3 9.69 1500 2008x1002x40 2008x1002x35 ET-M672BH415WW/WB 50.41 10.61 42.61...
- Page 19 2094x1038x35 ET-M672BH450WW/WB/BB 49.3 11.6 41.5 10.85 1500 2115x1052x35 2094x1038x35 ET-M672BH455WW/WB 49.5 11.66 41.7 10.92 1500 2115x1052x35 2094x1038x35 ET-M672BH460WW/WB 49.7 11.7 41.86 10.99 1500 2115x1052x35 1755x1038x35；1755x1038x30 ET-M660BH345BB 39.9 11.05 33.4 10.34 1500 1776x1052x35；1776x1052x30 1755x1038x35；1755x1038x30 ET-M660BH350BB 40.1 11.15 33.6 10.42 1500 1776x1052x35；1776x1052x30 1755x1038x35；1755x1038x30 ET-M660BH355WW/WB/BB 40.3...
- Page 20 ET-M772BH535TW/TB 2279X1134X33 49.45 13.79 41.47 12.91 1500 ET-M772BH540TW/TB 2279X1134X33 49.6 13.86 41.64 12.97 1500 ET-M772BH545TW/TB 2279X1134X33 49.75 13.93 41.8 13.04 1500 ET-M772BH550TW/TB 2279X1134X33 49.9 41.96 13.11 1500 ET-M772BH555TW/TB 2279X1134X33 50.05 14.07 42.11 13.18 1500 ET-M772BH560TW/TB 2279X1134X33 50.2 14.14 42.27 13.25 1500 ET-M766BH470BB 2094*1134*33...
- Page 21 ET-M754BH415WW/WB/BB 1722*1134*30 37.45 14.02 31.61 13.13 1500 ET-M754BH420WW/WB/BB 1722*1134*30 37.58 14.11 31.8 13.21 1500 ET-M754BH390TW/TB 1722*1134*30 36.85 13.61 30.64 12.73 1500 ET-M754BH395TW/TB 1722*1134*30 36.98 13.7 30.84 12.81 1500 ET-M754BH400TW/TB 1722*1134*30 37.07 13.79 31.01 12.9 1500 ET-M754BH405TW/TB 1722*1134*30 37.23 13.87 31.21 12.98 1500 ET-M754BH410TW/TB...
- Page 22 For module specifications or datasheets, please download from: www.etsolar.hk INFORMATION ABOUT MANUFACTURER: ET SOLAR POWER HONGKONG LIMITED Room 63,7/F,Woon Lee Commercial Building 7-9 Austin Ave,Tsim Sha Tsui,Kwoloon,H.K ChinaTel: 86 510 85382358 Fax: 86 510 85382358 mail: support@etsolar.HK www.etsolar.hk ET Solar inc.
