Diamond H2O DCS1 Startup Manual

DCS1 Water Softener
Start-Up Guide
Engineered Water Treatment Solutions
*Since 1932*
*All plumbing connections to the water softener MUST be complete before beginning start-up
procedure.
*Diamond H2O recommends an Inlet & Outlet Isolation Valve and a By-Pass System.
*If your Water Softener is equipped with an electronic timer, all programming should be
completed before proceeding with start-up.
Before beginning Start-Up, Re-Confirm the following have been completed:
(A). Inlet & Outlet Connections to the Control Valve are correct.
(B). The Drain Line has been run from the Control Valve to an open drain.
(C). The proper Drain Line Flow Control has been installed in the drain
A Drain Line Flow Control will be supplied with all new Water Softener Systems.
* Note:
(D). The Brine Line has been connected.
If Brine Line is not attached, connect the poly tubing (provided) from the control valve to
* Note:
the air check or safety float in the brine tank.
DCS1 START - UP STEPS
DCS1 START - UP STEPS
1.(A). Add approximately 5" of water to the brine tank (if Brine Tank is supplied with a grid plate fill until water is
about 1" above grid).
* NOTE: Start-Up only one unit at a time.
2.(A). Close the Inlet and Outlet Isolation Valves to each unit and open the By-Pass Valve. Verify flow through By-
Pass before proceeding.
3.(A). Connect the Water Softener to the power supply. Program time of day, day of week and hardness. For twin
or triple water softeners interconnecting wiring should be connected before powering up. Wires will be labeled as
to which unit they are to be plugged. The interconnecting wires are designed to all plug in and are keyed to only fit
to the port in which they go. Also be sure to plug and secure meter cables. ( For a twin a single wire comes out of
the main control valve and splits to 1 and 2. 1 is wired to the short meter cable that plugs into the main control and
2 gets wired to the long meter cable that connects to unit number two. All meter cables connect to outlet of valve.)
CONSULT THE PROVIDED SERVICE MANUAL TO PERFORM THE FOLLOWING STEPS:
4.Advance the Control Valve to the Backwash Position. To do this push and hold regeneration button for 5 seconds
5.(A). SLOWLY open the Inlet Valve when C1is showing on logix controller. Do NOT open the Inlet Valve com-
pletely. (The incoming water is now being forced to the bottom of the tank, up through the media, and out the
drain.) Disconnect power until all air is purged.
NOTE: If the tank(s) was not filled with water before valves were installed (recommended) you
*
will hear air coming out the drain line.
CAUTION: If media begins to come out of the drain, close the inlet valve even further. Media
*
should never come out of the drain line.
6.Let the water run from the Drain Line for about 5 minutes, or until drain water is clear.
