CLASSROOM INFORMATION: MOLECULAR BIOLOGY LT 1
EQ UIP MENT
Projector
•
2 data projectors
•
2 screens for
projector output
LI GHTI N G
Use the light switches near the entrance to adjust the lighting as needed.
LEC TERN HEI GHT
To adjust the lectern height as needed, hold down the ꓥ or ꓦ button on the left-hand side of the lectern.
DATA PROJ EC TOR
Projector positions are indicated as if you're facing the teaching wall.
1. SETTING UP THE SCREENS
Use the Screen Left and Screen Right dials near the entrance to set the screens at the required height.
2. OPERATING THE PROJECTORS
•
Left projector: On the lectern Crestron control panel, press the top row POWER button to turn the projector
on/off.
•
Right projector: On the lectern Crestron control panel, press the bottom row POWER button to turn the
projector on/off.
3. SELECTING INPUTS
Use the lectern Crestron control panel to select inputs for the left and right projectors:
Input
Classroom PC
Laptop
Document camera
HDMI laptop / device
Last updated: 21/01/2022
Lectern
•
Classroom PC with mouse, keyboard and optical drive
•
Crestron control panel
•
Laptop and HDMI input panel
•
Audio volume control dials
•
Document camera
•
Pull-out trays on sides of the lectern
Note:
Projectors may take a minute to warm up before you can use them. If they've recently been
switched off, wait a few minutes before switching them on.
Instructions
•
Left projector: Press the top row PC button.
•
Right projector: Press the bottom row PC button.
•
Left projector: Connect your laptop to the lectern's input panel (instructions
below), then press the top row LAPTOP button.
•
Right projector: Connect your laptop to the lectern's input panel (instructions
below), then press the bottom row LAPTOP button.
•
Left projector: Open the document camera (instructions below) then press the top
row DOC CAMERA button.
•
Right projector: Open the document camera (instructions below), then press the
bottom row DOC CAMERA button.
•
Left projector: Connect your laptop / HDMI device to the lectern's input panel
(instructions below), then press the top row HDMI button.
•
Right projector: Connect your laptop / HDMI device to the lectern's input panel
(instructions below), then press the bottom row HDMI button.
MOLECULAR BIOLOGY LT1
Staff card access-controlled safe
•
1 lapel mic with rechargeable
body pack
•
VGA cable
•
HDMI cable
•
Audio cable
•
Network cable
Page 1 of 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F17 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AVer F17

Summary of Contents for AVer F17

  • Page 1 CLASSROOM INFORMATION: MOLECULAR BIOLOGY LT 1 EQ UIP MENT Projector Lectern Staff card access-controlled safe • • Classroom PC with mouse, keyboard and optical drive 1 lapel mic with rechargeable • 2 data projectors • body pack Crestron control panel •...
  • Page 2 4. USING THE CLASSROOM PC The classroom PC is built into the lectern and is accessible by using the classroom PC control panel on the right-hand side of the lectern. Press the ꓥ button to open the screen, keyboard and mouse. When you're done, press the ꓦ button to close these items.
  • Page 3 MICR OP HONE This classroom is equipped with a hearing loop – which enhances audio quality for hearing-impaired audience members. To ensure that the hearing loop functions correctly, please use a microphone when conducting your lecture. 1. Take the lapel mic with its body pack out of the safe. 2.
  • Page 4 OCUMENT CAMERA US ER INSTRUCTIONS F17 ( SOFTWARE INSTRUCTIONS 2016) AST UPDATED EBRUARY Last updated: 21/01/2022 MOLECULAR BIOLOGY LT1 Page 4 of 9...

  • Page 5: Table Of Contents

    Table of contents Control the document camera ..................6 Set up your display ........................ 6 Basic setup ............................. 6 Advanced display settings ......................6 Manipulate your image......................7 Manipulate your image ........................7 Hide parts of your image ........................ 7 Emphasise parts of your image.......................

  • Page 6: Control The Document Camera

    Control the document camera 1. On the lectern Crestron control panel, select PC for the projector(s) that need to show the document camera output. 2. Basic operations: Use the buttons on the document camera control panel. 3. Advanced features: Open Sphere 2 on classroom PC desktop.

  • Page 7: Manipulate Your Image

    Manipulate your image Manipulate your image Click Camera Control. 2. Click each icon to adjust your display image as required – e.g. freeze, rotate 90 , zoom. Hide par ts of your image Click Presentation Tools. Click Visor. 3. Drag the visor to move or resize it. Click Menu to adjust visor transparency.

  • Page 8: Capture, View And Copy Images And Video

    • Series of images at custom-defined intervals 3. View images 1. On the classroom PC, open Documents – Aver – Media Library – Picture. Double-click each image to open it. 4. Show images side by side 1. Click the Side by Side tab near the top of screen.

  • Page 9: Record Video

    4. Use the recording controls to Pause or Stop recording. 6. Save images and video onto your own media 1. On the classroom PC, open Documents – Aver – Media Library. 2. Copy Picture and Video folders to your flash drive*.
