- Page 1 Electric Wheelchair USER MANUAL support@vocic.com BEFORE using the product, read this manual carefully and save for future reference.
- Page 2 If you have any other questions or valuable suggestions, please send to: support@vocic.com, we look forward to hearing from you, thank you！ Distributor: MATESIDE GLOBAL US INC.
-
Page 3: Table Of Contents
Content 1. Introduction........................1 2. Quick reference Guide....................1 3. Specification........................2 4. Practice before operation....................3 5. Safety instruction......................4 6. Terminology........................7 7. Joystick controller operation..................7 8. Rear wheel clutch fork....................10 9. Fold your wheelchair....................10 10. Adjust the controller and armrest................11 11. -
Page 4: Introduction
7. Rear wheel 2. Battery 5. Armrest 8. Motor 3. Charging port 6. Handlebar 9. Front wheel If you have any questions, please contact us: support@vocic.com. 2. Quick reference Guide 1. Remove the wheelchair and spare parts from its packaging. -
Page 5: Specification
3. Grasp the handlebar and pull the seat cushion frame outwards with your other hand. 4. Sit on the seat and lie down, or push the handle to ground. Confirm the fold button is locked. If you have any questions, please contact us: support@vocic.com. 3. Specification Model name... -
Page 6: Practice Before Operation
Failure to follow the instructions below may result in serious injury or damage to the electric wheelchair. If you have any questions, please contact us: support@vocic.com. 4. Practice before operation Before venturing onto the roads, find an open area such as a park and ask a friend to accompany you until you have mastered the power chair’... -
Page 7: Safety Instruction
1、 Sudden movement 2、 Operation direction is not controlled 3、 Brake failure If you have any questions, please contact us: support@vocic.com. 5. Safety instructions • Do not carry passengers. • Do not drive across a slope. • Do not drive under the influence of alcohol. - Page 8 Make sure there are no obstacles behind when braking; We recommend that the speed is the lowest when reversing. Avoid emergency braking, irregular shaking or emer- gency turning. Keep your arms on or inside the armrest and keep your feet on the footrest. Do not climb curbs that are more than 4 cm high.
- Page 9 ■ Precautions when driving on slopes: Driving on a slope is much more dangerous than driving on a flat surface. Please note the following as falling or losing control will result in serious harm to users and others. Do not climb slopes that exceed 6°. When climbing a slope, do not revere slope as you may cause a rollover.
-
Page 10: Terminology
Do not exit the wheelchair if facing up or down a slope. Stop the wheelchair before getting on and off. If you have any questions, please contact us: support@vocic.com. 6. Terminology Joystick: The device used to "move" the power chair. - Page 11 ■ The operation of the controller Try to avoid knocking the controller, especially the joystick. Do not beat the controller and the joystick while traveling. Do not hit the controller. When operating the wheelchair, ensure that the control system is safe and reliable. ■...
- Page 12 Press the power button Both indicators will light up. ■ Turn off the power Press the power button The indicator light will go off. ■ Joystick The main function of the joystick is to control the speed and direction of the wheelchair. The further the joystick is moved from a central position, the faster the wheelchair runs.
-
Page 13: Rear Wheel Clutch Fork
The controller is faulty Replace the controller short sounds If you have any questions, please contact us: support@vocic.com. 8. Rear wheel clutch fork When the wheelchair is in the electric operation state (power mode), only the con- troller can be used to move the wheelchair. The wheelchair cannot be pushed by hand, and this will prevent the wheels from rolling. -
Page 14: Adjust The Controller And Armrest
11. Remove the battery Step 1： Pull out the power plug. Step 2: Hold down the locking catch to disengage the battery from the frame and pull out the battery compartment. If you have any questions, please contact us: support@vocic.com. -
Page 15: Battery Application
12. Battery application The electric wheelchair uses a 24 voltage battery. It is a good idea to carry a replace- ment 24V12AH battery, in case you need to charge the one in use. This is a mainte- nance-free sealed lithium battery. The batteries are designed to handle deep discharges. -
Page 16: Guidance And Manufacturer' S Declaration
■ Battery cable: Check the battery cables to make sure they are not corroded. ■ Clean your wheelchair with a damp cloth: Do not use water to clean your wheelchair. 13. Guidance and Manufacturer’ s Declaration Below cables information are provided for EMC reference. Max. - Page 17 ■ EMI Compliance Table (Table 1) Table 1 - Emission Phenomenon Compliance Electromagnetic environment RF emissions CISPR 11 Group 1, ClassB Home healthcare environment Harmonic distortion IEC 61000-3-2 Class A Home healthcare environment Voltage fluctuations and flicker IEC 61000-3-3 Compliance Home healthcare environment ■...
-
Page 18: After-Sales Service
RF fields 80%AM at 1kHz 14. After-sales Service Once you purchase with VOCIC, you are covered by an 1-year warranty and lifetime after-sales service. Our 24/7 after-sales service is always available to answer any questions you may have during installation and use. - Page 19 Your Home Rehabilitation Partner Instagram Facebook Youtube...
