Summary of Contents for Electrolux FRIGIDAIRE FPGF3685LS
- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FRIGIDAIRE FPGF3685LS Owner's Manual Shop genuine replacement parts for FRIGIDAIRE FPGF3685LS Find Your FRIGIDAIRE Gas Range Parts - Select From 27 Models -------- Manual continues below --------...
-
Page 2: Table Of Contents
All about the & Care Gas Range of your TA B L E O F C O N T E N T S Welcome & Congratulations ........2 Setting Oven Controls .......... 13 Important Safety Instructions .........3 Care & Cleaning (Cleaning Chart) ......21 Features at a Glance ..........7 Care &... -
Page 3: Welcome & Congratulations
WELCOME & CONGRATULATIONS Congratulations on your purchase of a new appliance! At Product Registration Electrolux Home Products, we are very proud of our Register Your Product product and are completely committed to providing you with the best service possible. Your satisfaction is our The PRODUCT number one priority. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using this appliance. WARNING Save these instructions for future reference. • All appliance can tip. WARNING • Injury to persons could result. • Install anti-tip bracket packed with If the information in this manual is not followed your appliance. - Page 5 IMPORTANT SAFETY INSTRUCTIONS • Do Not Use Water or Flour on Grease Fires. WARNING Smother the fi re with a pan lid, or use baking soda, a dry chemical or foam-type extinguisher. Stepping, leaning, sitting or pulling down on the •...
- Page 6 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT INSTRUCTIONS FOR USING IMPORTANT SAFETY INSTRUCTIONS FOR YOUR COOKTOP USING YOUR OVEN • Know which knob controls each surface heating • Use Care When Opening Oven Door—Stand to the unit. Always turn the knob to the LITE position when side of the appliance when opening the door of a hot igniting the burner.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS GROUNDING INSTRUCTIONS • Clean in the self-cleaning cycle only the parts of the appliance listed in this Owner’s Guide. Before For personal safety, the cooktop must be properly using the self-cleaning cycle of the appliance, remove grounded. For maximum safety, the power cord must be all utensils or foods from the appliance.
-
Page 8: Features At A Glance
FEATURES AT A GLANCE Your built-in range Features: Electronic oven control with kitchen timer. Burner valve & knob. Oven vent Interior oven light. Self-clean interior oven. Adjustable interior oven rack(s). 3-piece handle. Storage drawer. 14 000 BTU Surface burner. 10. 9 500 BTU Surface burner. 11. -
Page 9: Surface Cooking
SURFACE COOKING Use Proper Cookware Using a wok Cookware should have fl at bottoms that make good contact Woks with fl at bottoms suitable for use on your cooktop with the entire surface heating element. Check for fl atness are available in most cookshop or hardware stores by rotating a ruler across the bottom of the cookware (See (Figure 3). - Page 10 SURFACE COOKING Canning Tips & Information 1. Use tested recipes and follow instructions carefully. CAUTION Check with your local Cooperative Agricultural Extension Service or a manufacturer of glass jars for Canning can generate large amounts of steam. Use the latest canning information. extreme caution to prevent burns.
-
Page 11: Setting Surface Controls
SETTING SURFACE CONTROLS Placement of Burner Bases and Caps Placement of Burner Grates Your Cooktop is equipped with three different sizes of burners: Place grate over burner pans. Make sure that the groove Power Burner, Standard Burner and Simmer Burner. under grate fi... - Page 12 SETTING SURFACE CONTROLS Operating the Gas Surface Controls: Setting Proper Surface Burner Flame Size 1. Place cooking utensil on surface burner. For most cooking, start on the highest control setting and 2. Push the surface control knob down and turn then turn to a lower one to complete the process.
-
Page 13: Before Setting Oven Controls
BEFORE SETTING OVEN CONTROLS Oven vent location Arranging oven racks ALWAYS ARRANGE OVEN RACKS WHEN THE OVEN IS Each oven has its own vent as shown below (Figure COOL (PRIOR TO OPERATING THE OVEN). Always use 1). When the oven is ON, warm air is released through oven mitts when using the oven. -
Page 14: Setting Oven Controls
SETTING OVEN CONTROLS Control pad features READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become familiar with the various features and functions of the oven as described below. Detailed instructions for each feature and function follow later in this Use & Care Guide. 1. - Page 15 SETTING OVEN CONTROLS SETTING THE CLOCK SETTING SILENT CONTROL OPERATION The DELAY START pad control the Silent Control NOTE operation feature. When choosing a function, a beep will be heard each time a pad is pushed. If desired, the Note: The time of day must fi rst be set in order to control can be programmed for silent operation.
- Page 16 SETTING OVEN CONTROLS SETTING MINUTE TIMER SETTING BAKE 1. Press the Timer On . Off pad. The oven can be programmed to bake at any 2. Press the Up arrow pad to increase or Down arrow temperature from 170°F to 550°F. pad to decrease the time in one minute increments.
- Page 17 SETTING OVEN CONTROLS SETTING BROIL To set a Broil of 550°F: 1. Place the food on a broiler pan insert. DO NOT use the Broiling is a method of cooking tender cuts of meat by direct heat under the broil element of the oven. Be sure broiler pan without the insert.
- Page 18 SETTING OVEN CONTROLS SETTING BAKE TIME AND DELAY START The Bake Time and Start Time pads operate the features that will turn the oven ON and OFF at the times you select in advance. The oven can be programmed to start immediately and shut off automatically (timed bake) or to begin baking at a later time with a delayed start (Delay start).
- Page 19 SETTING OVEN CONTROLS SETTING THE SABBATH FEATURE (for use on the Jewish Sabbath & Holidays) The BAKE TIME and DELAY START pads are used to 7. Press and hold both the BAKE TIME and DELAY set the Sabbath feature. The Sabbath feature may only START pads for at least 3 seconds.
- Page 20 SETTING OVEN CONTROLS SELF-CLEANING A self-cleaning oven cleans itself with high temperatures (well above normal cooking temperatures) which eliminate soils completely or reduces them to a fi ne powdered ash you can wipe away with a damp cloth. DO HAND CLEAN FRAME IMPORTANT Adhere to the following cleaning precautions:...
- Page 21 SETTING OVEN CONTROLS SETTING QUICK CLEAN OR SELF-CLEAN Stopping or Interrupting a Quick Clean or Self Clean Cycle CYCLE TIME LENGTH If it becomes necessary to stop or interrupt a self clean The Quick Clean and Self Clean pads control the Self- cycle: Cleaning feature.
-
Page 22: Care & Cleaning (Cleaning Chart)
CARE & CLEANING (Cleaning Chart) Cleaning various parts of your appliance Before cleaning any part of the appliance, be sure all controls are turned off and the appliance is COOL. REMOVE SPILLOVERS AND HEAVY SOILING AS SOON AS POSSIBLE. REGULAR CLEANING WILL REDUCE THE NUMBER OF MAJOR CLEANING LATER. -
Page 23: Care & Cleaning
CARE & CLEANING Ceramic glass cooktop cleaning & IMPORTANT maintenance Damage to the ceramic glass cooktop may occur if you Consistent and proper cleaning is essential to use an abrasive type scratch pad. Only use cleaning maintaining your Ceramic glass cooktop. products that have been specifi... - Page 24 CARE & CLEANING Cleaning Burner Heads, Caps & Grates Surface The cooktop is designed to make cleaning easier. Because Burner the gas Burners are sealed, cleanups are easy when Grate spillovers are cleaned up immediately. The cooktop, Burner Heads and Caps should be routinely cleaned.
- Page 25 CARE & CLEANING Removing and replacing the main oven door WARNING CAUTION Flammable materials should not be stored in an oven, near surface elements or in the storage drawer. This The door is heavy. For safe, temporary storage, lay includes paper, plastic and cloth items, such as cookbooks, the door fl...
-
Page 26: Before You Call
BEFORE YOU CALL (Solutions to Common Problems) Oven baking For best cooking results, heat the oven before baking cookies, breads, cakes, pies or pastries, etc. There is no need to preheat the oven for roasting meat or baking casseroles. The cooking times and temperatures needed to bake a product may vary slightly from your previously owned appliance. - Page 27 BEFORE YOU CALL (Solutions to Common Problems) IMPORTANT Before you call for service, review this list. It may save you time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this appliance. OCCURRENCE POSSIBLE CAUSE/SOLUTION Range is not level.
- Page 28 BEFORE YOU CALL (Solutions to Common Problems) OCCURRENCE POSSIBLE CAUSE/SOLUTION Metalmarks. Sliding or scraping of metal utensils on cooktop surface. Do not slide metal utensils on cooktop surface. Use a ceramic-glass cooktop cleaning cream to remove the marks. "Cooktop Cleaning - Ceramic Glass Cooktop Models" section under General Cleaning. Scratches or Coarse particles such as salt or sand between cooktop and utensils can cause scratches.
-
Page 29: Major Appliance Warranty
MAJOR APPLIANCE WARRANTY Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.
