Laversab 6500-HA User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
To buy, sell, or trade in this product please click on the link below:
https://www.avionteq.com/Laversab-6500-HA-Air-Data-Test-Set.aspx
www.avionteq.com
MODEL 6500-HA Rev. F2
USER'S MANUAL
LAVERSAB INC.,
505 GILLINGHAM LANE
SUGAR LAND TX , 77478
(281) 325-8300
FAX: (281) 325 8399
Email: aservice@laversab.com
Document Number : 9100 REV.F2
Date: Mar.9, 2010.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6500-HA and is the answer not in the manual?

Questions and answers

Related Manuals for Laversab 6500-HA

Summary of Contents for Laversab 6500-HA

  • Page 1 To buy, sell, or trade in this product please click on the link below: https://www.avionteq.com/Laversab-6500-HA-Air-Data-Test-Set.aspx www.avionteq.com MODEL 6500-HA Rev. F2 USER'S MANUAL LAVERSAB INC., 505 GILLINGHAM LANE SUGAR LAND TX , 77478 (281) 325-8300 FAX: (281) 325 8399 Email: aservice@laversab.com Document Number : 9100 REV.F2...
  • Page 2 Inc. warrants products of its own factory against defects of material or workmanship for a period of one year from date of sale. Liability of Laversab Inc. under this warranty shall be limited to replacing, free of charge (FOB Houston, Texas), any such parts proving defective within the period of this warranty, but Laversab Inc.
  • Page 3 COPYRIGHT NOTICE Copyright (c) 2010 onwards by Laversab Inc. All rights reserved. The content of this manual may not be reproduced in any form by any means, in part or in whole, without the prior written permission of Laversab Inc.

  • Page 4: Revision History

    REVISION HISTORY Document No. Release Date Description 9100 Rev F2 03/09/2010 6500-HA Rev F2 User’s Manual...
  • Page 5 WARNING THE 6500-HA USES LINE VOLTAGES FOR ITS OPERATION WHICH ARE POTENTIALLY DANGEROUS. IMPROPER OPERATION OF THIS EQUIPMENT MAY RESULT IN PERSONAL INJURY OR LOSS OF LIFE. HENCE THE EQUIPMENT DESCRIBED IN THIS MANUAL SHOULD BE OPERATED ONLY BY PERSONNEL TRAINED IN PROCEDURES THAT WILL ASSURE SAFETY TO THEMSELVES, TO OTHERS AND TO THE EQUIPMENT.

  • Page 6: Table Of Contents

    Section 2: Controls and Connections ................ 2 2.1 Front Panel ....................... 2 2.2 Rear Panel ........................7 Section 3: Understanding the 6500-HA ..............9 3.1 Start Up ........................9 3.2 Main Operating Screen ..................11 3.2.1 Displayed Parameters ................... 11 3.2.2 Target Value Entry...
  • Page 7 TABLE OF CONTENTS (contd.) 6.2 General Notes ......................46 6.3 Ps Calibration ......................47 6.4 Pt Calibration ......................48 Section 7: Maintenance ....................52 Section 8: Communication Interface ................53 8.1 RS232 Serial Interface ....................53 8.2 IEEE-488 Interface ....................53 8.3 Communication Syntax ...................

  • Page 8: Introduction

    C. The 6500-HA is fully RVSM compliant. The 6500-HA allows the user to control altitude in feet or meters, climb in feet per minute or meters per minute, airspeed in knots, mach, mph and kmph. It also allows the user to control EPR on the pitot output.

  • Page 9: Controls And Connections

    CONTROLS AND CONNECTIONS Note: Pt = Pitot and Ps = Static FRONT PANEL The front panel of the 6500-HA is shown in Figure 2.1 The various components of the front panel are described below. Power ON/OFF switch This is a Push On / Push Off switch. In the depressed position the switch in ON. This switch is used to connect AC power to the unit.
  • Page 12 There are five function keys just below the display. NEXT SCREEN and PREVIOUS SCREEN are used to move between the different operating screens of the 6500-HA. At present there are only three upper level operating screens : Main, Calibrate and Self test.
  • Page 13 The ENTER key is used to accept numeric entries and also select units and modes. TARGET VALUE KEYS : There are typically 3 parameters that the 6500-HA controls - Altitude, Climb and Airspeed. Each parameter has its own target value key. The Pt/AIRSPEED key is used to select Pt or Airspeed target value entry, the Ps RATE/CLIMB key is used to select Climb value entry, and the Ps/ALTITUDE key is used to select Ps or Altitude value entry.

  • Page 14: Rear Panel

    For more information on Mode Selection please refer to Section 3.2.4. REAR PANEL The rear panel of the 6500-HA is shown in Figure 2.2 The various components of the front panel are described below. Vacuum Port (2 each) These ports are used for connecting a vacuum supply to the 6500-HA. A vacuum supply of 0.3 inHg absolute or lower is ideal, and must be connected to both vacuum ports for proper...
  • Page 15 IEEE-488 port If the “IEEE” option is provided on the 6500-HA, a standard 24-pin female IEEE-488 interface connector is available on the rear panel. Remote communication with the 6500-HA is possible through this interface. For more details on using this interface, please refer to Section 8.

  • Page 16: Understanding The 6500-Ha

    Before actually using the 6500-HA to perform certain tasks, it is important to understand how to use the 6500-HA to make it do what you want. This section explains everything about the information that you see on the display, what it means, and...
  • Page 17 Main Leak mode Leak Operating Screen Screen Function Select Function Select Screens (2) IEEE address View Limits Password Change Limits Change knots rate Execute profile (Return to Main) Setup Profile Height Correction Set Ground Go to Ground Encoder Next Screen Password Calibration Next...

  • Page 18: Main Operating Screen

    Function Select screens are used only a few times during normal operation and also when first setting up the 6500-HA. The Calibrate screen is used only once a year by the calibration facility. During normal operation, the two screens that are used the most are the Main Operating screen (Main Screen) and the Leak Screen.
  • Page 19 The two values (1005 and 0) that appear below it are in these units. Units: knots Feet/min Feet Actual: 101.2 3500 1005 Target: 20.0 3000 Parameter 3. Climb Units: Unit of measurement for displaying the rate of change of the Static output, or Climb.
  • Page 20 This is the value that you command the 6500-HA to achieve on the Pitot output (Pt test port). In the sample screen below, the 6500-HA has been commanded to achieve a pressure of 20.0 knots on the Pitot output. The Pitot “Target” value is meaningful only when the Pitot output is in the “Control”...
  • Page 21 “Actual” value in the current Pitot units. The pressure is not being changed by the 6500-HA. In this mode, the Pitot valve inside the 6500-HA that is used to change the pressure at the Pitot output is pneumatically isolated from the Pitot output. In the Measure mode, the Pitot “Target”...
  • Page 22 “Actual” value in the current Static units. The pressure is not being changed by the 6500-HA. In this mode, the Static valve inside the 6500-HA that is used to change the pressure at the Static output is pneumatically isolated from the Static output. In the Measure mode, the Static “Target”...
  • Page 23 Static half Units: knots Feet/min Feet Actual: 101.2 3500 1005 Target: 20.0 3000 The Main operating screen will be used almost all the time during normal operation for commanding target values, viewing actual values, setting units and modes. Error Messages: The Main screen is also used to display error conditions as they occur.

  • Page 24: Target Value Entry

    Use the numeric keys to enter the value. Use the +/- key to change the sign of the value. The 6500-HA will beep on every key entry, and it will beep for a longer time period if extra invalid digits are entered. It is not necessary to enter the decimal point and the digit after the decimal point if that digit is “0”.
  • Page 25 Remote unit and the main unit. Please abort and contact the factory. If GO is pressed after ENTERing the value, the 6500-HA will try to achieve this new target value ONLY IF the Pitot output is in the CONTROL mode. Therefore, it is desired that both Pitot and Static values be entered so that both are blinking before the GO key is pressed.

  • Page 26: Units Selection

    Target Value Jog Each of the three target values can be jogged up or down in small increments by using the arrow keys. This is done to help the operator achieve a perfect reading on the instrument in the aircraft, by bumping the set-point in small increments. To jog a value, select the value by pressing the appropriate target value key and then use the arrow keys.
  • Page 27 Target: 0.064 3000 The unit selection will not become effective until the GO key is pressed. The 6500-HA will return to the old units if the CANCEL key is pressed. . Static Units: There are four Ps units to choose from: Feet, Ps inHg (Psin), meters, and mbar (Psmb).

  • Page 28: Mode Selection

    10.000 29.054 The unit selection will not become effective until the GO key is pressed. The 6500-HA will return to the old units if the CANCEL key is pressed. . It must be noted that the units change does not perform a conversion between the units of feet/minute or meters/minute to Ps inHg/min or Ps mbar/min.
  • Page 29 4 of the display, with the cursor under “MEAS”. Units: knots Feet/min Feet Actual: 101.2 3500 1005 Target: 20.0 3000 Pt mode : MEAS, LEAK, CTRL Move the cursor to the desired mode and then press ENTER. The selected mode is displayed on the screen and blinks until the GO key is pressed.
  • Page 30 Since the controlling portion of the 6500-HA is isolated from the output during Measure or Leak modes, it will usually be at a pressure quite different from that at the output. Simply introducing the controlling section into the pneumatic system connected to the output will cause a surge in pressure (or vacuum) at the output.

  • Page 31: Leak Screen

    Following the Equalization process, only when the actual value on the Static output is less than 2000 feet from Ground and the Pitot output is less than 150 knots, the 6500-HA will automatically inject a small vacuum on the Static output and a small pressure on the Pitot output.
  • Page 32 Until the first minute has elapsed it shows “WAIT”. While in the Static Leak Screen, if the leak ever exceeds 2000 ft/min, the 6500-HA will automatically trip out of the Leak mode and revert back to Control mode. It will then display a message as follows: Static leak exceeds 2000 ft/min.

  • Page 33: Timed-Leak Screen

    Pressing the CANCEL key allows you to exit from the Leak Screen, back to the Main Operating Screen. If the mode prior to entering the Leak mode was Control then the 6500-HA will revert back to Control mode on exiting the Leak Screen.
  • Page 34 100.0 knots 0 ft/min. 15000 feet 0:00 To accept the setting of the 1 leak-timer and move the arrow to the 2 leak-timer, press ENTER. The screen will appear as below. Change the 2 leak-timer value if desired, using the Arrow keys. The leak-timer value must be changed before the elapsed time reaches 58 seconds.
  • Page 35 How the Timed-Leak screen is updated: The first line of the screen, which shows the current Actual values, is updated every 0.25 seconds. The elapsed time is updated every second. Assuming that the leak-timers are set to 1, 2 and 3 minutes, when the elapsed time reaches 1:02 (2 seconds after the elapsed time reaches the first leak-time) , the leak screen will be updated and appear as shown below.

  • Page 36: Self Test Screen

    As part of the start up procedure, it is recommended that a Self Test be performed on the 6500-HA. Before performing the Self Test you must follow the start up procedure explained in section 3.1. The Main Operating Screen must be displayed on the Remote unit. There should be no errors displayed on line 4 of the display.

  • Page 37: Function Select Screen

    ROM OK RAM OK Ps measurement system OK Pt measurement system OK After the pump section test has passed successfully, the screen is cleared and the status of the remaining tests is displayed as shown below. Pump section OK Ps control system OK Pt control system OK.

  • Page 38: Function 0: Ieee Address

    3.5.0 FUNCTION 0 : IEEE ADDRESS This function allows the user to enter a valid IEEE-488 address for the 6500-HA. This address is meaningful only if the “IEEE” option is provided on the 6500-HA. A valid address between 1 and 30 may be entered on the screen shown below.

  • Page 39: Function 2: Set Limits

    If the target value exceeds any of the limits, an error is generated. The Actual values are also checked when the 6500-HA is in the “Control” mode. If any of these limits is exceeded by a pre-defined amount, an error will be generated and the 6500-HA will revert to “Measure”...
  • Page 40 this limit is 500.0 2. Min. knots : This limits is usually negative and it defines the maximum “Negative Qc” that the airspeed instruments (UUT) can tolerate. In most cases it should be set to about “-200.0” since almost all airspeed indicators can tolerate at least that much negative Qc. Setting it any closer to “0.0”...

  • Page 41: Function 3: Set Knots Rate

    This indicates that the current profile point is ready for execution and awaiting the “GO” key to be pressed. When the “GO” key is pressed, the 6500-HA will execute the profile point, i.e. it will change to Control mode and move towards the desired targets.

  • Page 42: Function 5: Setup Profiles

    3.5.5 FUNCTION 5: SETUP PROFILES This function is used to load profiles into the 6500-HA from a PC. A full explanation of how to load profiles into the 6500-HA is provided in Section 4.. The following screen will come up when Function 5 is selected.

  • Page 43: Function 7: Set Ground

    The “Set Ground” function is used to indicate to the 6500-HA the ambient “Ground” pressure. Before connecting the 6500-HA to the UUT, just after the Self Test has been performed, it is recommended that this function be invoked. The Pitot and Static ports must still be open to ambient when using this function.

  • Page 44: Function 9: Encoder

    If an altitude encoder is electrically connected to the Encoder interface connector on the rear panel of the 6500-HA (not shown in Fig. 2.2) and is pneumatically connected to the Ps output of the 6500-HA, then the 10-bit code on line 2 and flight level on line 3 will correspond to the altimeter reading.

  • Page 45: Profiles

    4.1 WHAT IS A PROFILE. A profile is a set of up to 50 points that tell the 6500-HA what you would want it to do at each point. Each point consists of 7 parameters: 1) Pitot units, 2) Pitot mode, 3) Pitot target value, 4) Static units, 5) Static mode, 6) Static target value and 7) Static rate (Climb) target value.
  • Page 46 Rate target value In the sample profile, Row 3, which is the first point in the profile, tells the 6500-HA to go in Control mode to 100 knots on the Pitot side, and in Control mode to 0 feet at 6000 feet/min on the Static side.

  • Page 47: Creating A Profile

    12 characters. On Row 2, middle cell, replace “11” with a profile number between 1 and 20 that you would like this profile to be saved as, in the 6500-HA. Do not change row 2 right-most cell. In rows 3 through 50, change the cells as per the points you want to generate in your test.

  • Page 48: Setting Up Hyperterminal

    Your profile has been created. 4.3 SETTING UP HYPERTERMINAL You download a profile into the 6500-HA using the Hyperterminal program. At first you need to setup Hyperterminal. You only need to do this once.

  • Page 49: Downloading A Profile

    To verify that the 6500-HA file is setup in Hyperterminal, select “All Programs” from the desktop, select “Accessories”, select “Communications”, select “Hyperterminal”. The “6500-HA” icon should appear. If it does not appear then you will need to repeat steps 1 and 2 above.

  • Page 50: Executing A Profile

    PC as your profile. 4.5 EXECUTING A PROFILE On the 6500-HA, select Function 4: Execute profile. On line 4 on the Main screen, a profile number is required to identify the profile. This number is x.y where x is the profile number and y is the point number within that profile.
  • Page 51 50 points can be loaded as profile 1 and the remaining 30 points can be loaded as profile 2. When profile 1 has been completed at point 1.50, the 6500-HA will stay at that point until the next command. The user can start profile 2.1 and execute the 51st point and continue...

  • Page 52: Typical Use

    This section assumes that the user has read Section 3 and understood the functioning of the 6500-HA. Please do not follow the sequence shown below without first reading Section 3. The following steps show a typical use of the 6500-HA for checking aircraft instruments.

  • Page 53: Calibration

    4.0 inHg abs. The 6500-HA has a drift of typically 0.005 %FS per year. Therefore it needs to be calibrated once a year to perform adequately as a calibration standard for air data equipment. To...

  • Page 54: Ps Calibration

    Step 2. Turn on the 6500-HA and allow it to warm up for about 30 minutes. Change the units to “PsinHg” on the Static side and “PtinHg” on the Pitot side. Refer to section 3.2.3 on how to change units.

  • Page 55: Pt Calibration

    Step 2. Turn on the 6500-HA and allow it to warm up for about 30 minutes. Change the units to “PsinHg” on the Static side and “PtinHg” on the Pitot side. Refer to section 3.2.3 on how to change units.
  • Page 56 Step 4. Generate a pressure of 100.000 inHg absolute, allow the pressure to stabilize for 2 minutes and take the reading on the Pt port (PtinHg) of the 6500-HA. This is the second of your “Before” calibration adjustment reading. It will indicate the zero plus slope drift since the previous calibration.
  • Page 57 Step 8. On the keypad of the remote unit, press “PREV SCREEN”. The display will return to the Main Screen. If you press “CANCEL” the calibration adjustment will become void. Step 9. Turn the 6500-HA OFF, wait 30 seconds and then turn it back ON. The calibration adjustment is now complete for the Pt port.
  • Page 58 Model: 6500-HA-HA Serial#: 74678 Full scale: Ps: 38 inHg Pt: 100 inHg Last Calibrated date: 10/10/01 _______________________________________________________________________ CALIBRATION RESULTS STATIC PRESSURE (Ps): TEST POINT AS FOUND AS LEFT DEVIATION inHg inHg inHg 1. Vacuum 1.0001 1.0000 0.0001 2. Fullscale 38.0002 38.0000...

  • Page 59: Maintenance

    SECTION 7 MAINTENANCE Scheduled maintenance of the 6500-HA includes calibration once a year. The calibration procedure is described in Section 6. In addition to calibration, there is only one other item that requires regular maintenance : replacing the fan intake filter as required.

  • Page 60: Communication Interface

    Connectors” cover on the top panel. This interface supports the following IEEE-488 functions. Source Handshake Acceptor Handshake Basic Talker Basic Listener Service Request Device Clear The IEEE-488 address of the 6500-HA can be changed using Function ‘0’ as described in Section 3.5.0.

  • Page 61: Communication Syntax

    Line Feed <LF>. To get data from the 6500-HA the unit must be addressed to Talk. Prior to asking the 6500- HA to Talk, the data to be sent by the 6500-HA must be specified through a command. For the 6500-HA to understand the command it must be in the Listen mode.
  • Page 62 Command Type Description PU=n Read/ Set Pt units as per following: units knots mach Pt inHg Qc inHg Pt mb Qc mb kmph SU=n Read/ set Ps units as follows: units Feet Ps inHg meters Ps mb PM=n Read/Set Pt mode to Measure (1), Leak (2), control (3) SM=n Read/set Ps mode to Measure (1), Leak (2), Control (3) Read current error ;...
  • Page 63 Command Type Description Command to cancel current settings IE=n Read/set IEEE address C1=n Read/set Pt vacuum calibration point C2=n Read/set Pt fullscale calibration point C3=n Read/set Ps vacuum cal. point C4=n Read/set Ps fullscale calibration point Activate new calibration points after new values have been entered for either C1 and C2, or C3 and C4.

  • Page 64: Appendix A: Error Codes

    APPENDIX A ERROR CODES All errors are displayed on line 4 of the display when the 6500-HA is in the Main screen. An error must be acknowledged before any other key entries are accepted. The error may be acknowledged either by pressing the CANCEL or the CLR key.

  • Page 65: Appendix B: Specifications

    APPENDIX B SPECIFICATIONS Static Output Pressure function range: 0.1 to 38 inHg resolution: 0.0001 inHg accuracy: 0.001 inHg Altitude function range: -4000 ft. to 100,000 ft. resolution: 1 foot accuracy: 1 ft. @ 0 ft. 3 ft. @ 35,000 ft. 6 ft.

  • Page 66: Appendix C: Repair And Return Policies

    APPENDIX C REPAIR AND RETURN POLICIES If it is determined that the product is defective, please call Laversab customer service department: (281) 325-8300 or fax (281) 325-8399 or e-mail aservice@laversab.com for further assistance. Before shipping any equipment to Laversab for repair, please call the customer service department at (281) 325-8300 or fax (281) 325-8399 or e-mail to aservice@laversab.com.
