- Page 1 Viking Installation Guide Electric Induction Rangetops Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA...
-
Page 2: General Information
IMPORTANT: PLEASE READ AND FOLLOW • Before beginning, please read these instructions completely WARNING and carefully. • Do not remove permanently affixed labels, warnings, or E E L L E E C C T T R R I I C C A A L L G G R R O O U U N N D D I I N N G G plates from product. - Page 3 SPECIFICATIONS-ELECTRIC RANGETOP Description VCRT300 VIRT300 Overall Width 29 7/8” (75.9 cm) Overall Height from BASE HEIGHT ADDITIONS TO BASE HEIGHT Bottom To top of glass frame To top of island trim - add 1 1/4” (3.2 cm) 7 7/8” (20.0 cm) To top of backguard - add 6”...
- Page 4 PROXIMITY TO CABINET INSTALLATION 1. This rangetop may be installed directly adjacent to existing 36” (91.4 cm) high base cabinets. 2. The rangetop CANNOT be installed directly adjacent to sidewalls, tall cabinets, tall appliances, or other side vertical surfaces above 36” (91.4 cm) high. There must be a minimum of 6” (15.2 cm) side clearance from the rangetop to such combustible surfaces above the 36”...
- Page 5 INTERIOR CABINET CLEARANCES FOR PROPER AIR FLOW D D E E T T A A I I L L E E D D V V I I E E W W O O F F B B O O T T T T O O M M S S U U P P P P O O R R T T 2 3/4”...
- Page 6 FINAL PREPARATION 1. Some stainless steel parts may have a plastic protective wrap which must be peeled off. All stainless steel body parts should be wiped with hot, soapy water and with a liquid cleaner designed for this material. If build-up occurs, do not use steel wool, abrasive cloths, cleaners, or powders!! If it is necessary to scrape stainless steel to remove encrusted materials, soak with hot, wet cloths to loosen the material, then use a wood or nylon scraper.
- Page 7 WIRING DIAGRAM ELECTRIC INDUCTION/RADIENT RANGETOP BLACK RED/BLK RED/BLK YEL/RED YEL/RED WH/RED 1500 WATT L.R. ELEM. RED/BLK CHASSIS GROUND GREEN WH/RED POWER LINE CONDITIONER J4 J3 (H2) (H1)a (H1)b POWER BOARD JOUT1 SMALL COIL BLACK JOUT2 RED/BLK TEMP CONTROL SMALL COIL POTENTIOMETER REAR EMI BOARD...
- Page 8 Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For more product information call 1-888-VIKING1 (845-4641) or visit the Viking Web site at vikingrange.com (PS0506VR) F20115...
