ASUS VIVOBOOK K6502VJ / VU / VV / VJQ
Repair Manual
IMPORTANT NOTICE:
This document is intended for ASUS Authorized Service Providers only. Performing any repairs without authorization will void
warranty. ASUS will not be liable for any damages that may occur while performing any procedures provided in this guide.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Asus VIVOBOOK K6502VJ
Summary of Contents for Asus VIVOBOOK K6502VJ
- Page 1 Repair Manual IMPORTANT NOTICE: This document is intended for ASUS Authorized Service Providers only. Performing any repairs without authorization will void warranty. ASUS will not be liable for any damages that may occur while performing any procedures provided in this guide.
- Page 3 Service Overview • ASUS is not responsible for direct, indirect, intentional o unintentional damages resulting from improper installation and operation. • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs.
- Page 4 Pre-repair checklist • Read the entire manual before starting any service procedures and follow all instructions. • Back up the data on your device. • Place your device on a clean and stable surface. • Turn off your device. • Disconnect all connected peripherals and cables.
- Page 5 ASUS VIVOBOOK K6502VJ VU VV VJQ OVERVIEW Front View Top View Bottom View ❶ Array microphones ❷ Ambient light sensor ❸ Camera ❹ Camera indicator ❺ Webcam shield ❻ Display panel ❼ Microphone off indicator ❽ Keyboard ❾ Capital lock indicator Touchpad ❿...
- Page 6 Components Top View LCD COVER KEYBOARD MODULE CARD READER BOARD SSD SHIELDING ANTENNA MAIN LCD BEZEL BOTTOM CASE WLAN CARD MAIN BOARD WLAN MYLAR TOUCHPAD ZIF MYLAR LCD Panel(OLED) THERMAL MODULE ASSY HINGE EDP IPS CABLE FP FFC EDP PLED CABLE LCD Panel(IPS) IO BOARD BATTERY(50W SKU)
- Page 7 Components Bottom View LCD COVER (OLED) KEYBOARD MODULE TOUCHPAD MODULE LCD BEZEL MAIN BOARD BATTERY(50W/70W SKU) MEMORY LCD COVER (IPS) BOTTOM CASE LCD Panel(OLED) SD BOARD THERMAL MODULE ASSY DDR SHIELDING WLAN CARD LCD PANEL(IPS) IO BOARD LCD MODULE Back...
- Page 8 Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
- Page 9 K6502VJ VU VV VJQ Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the notebook. Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade Thermal Material G500 Thermal Grease Plastic Tweezers Use a pair of tweezers to remove/insert/tidy cables.
-
Page 10: Bottom Case
BOTTOM CASE Disassembly Notice Step 1 : Remove the screw *9pcs. Assembly Notice Step 2 : Use plastic blade to pry the BOTTOM CASE. ➢ Please keep pace with the color of screws when you change them. Screws Spec Torque (kgf-cm) SCREW M2*4L 2.0 ±... - Page 11 DISCONNECT BATTERY CONNECTOR (50W BATTERY SKU) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to avoid IC damage. Step 1 : Use the non-conductive pry tool to push iron sheet.
- Page 12 DISCONNECT BATTERY CONNECTOR (70W BATTERY SKU) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to avoid IC damage. Step 1 : Use the non-conductive pry tool to push iron sheet.
- Page 13 BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to avoid IC damage. Step 1 : Remove the screw *5pcs (50W/70W SKU). Screws Spec Torque(kgf-cm)
- Page 14 MB BRACKET Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screw *4pcs ( for 50W/70W SKU). Screws Spec Torque (kgf-cm) Step 2 : Remove the MB BRACKET and MB BRACKET R. 2.0 ±...
- Page 15 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screw *1pc and then remove the SSD. Torque (kgf-cm) Screws Spec Step 2 : Remove the SSD SHIELDING and then remove the SSD. 2.0 ±...
- Page 16 MEMORY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Use the plastic blade to pry the DDR SHIELDING. Front Step 2 : Remove the DDR SHIELDING and Memory. There is an absorber that is pasted on the Remove DDR SHIELDING.
- Page 17 WLAN CARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Release the WLAN MYLAR. Torque (kgf-cm) Screws Spec Step 2 : Disconnect the MAIN ANTENNA and AUX ANTENNA. 2.0 ± 0.2 SCREW M2*2.5 Step 3 : Remove the screw *1pc and then remove the WLAN CARD.
- Page 18 SPEAKER & ANTENNA Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the Speaker connector. Step 2 : Tidy the cables. Assembly Notice Step 3 : Remove the MAIN ANTENNA and AUX ANTENNA. Step 4 : Remove the Speaker.
- Page 19 FAN & THERMAL MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screw *5pcs. Screws Spec Torque(kgf-cm) Step 2 : Remove the Thermal Module. 2.0 ± 0.2 SCREW M2*3L Step 3 : Disconnect and release the EDP Cable. 2.0 ±...
-
Page 20: Card Reader Board
MAIN BOARD & IO BOARD & CARD READER BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the FP FFC, TP TO MB FFC, KEYBOARD FFC, BACKLIGHT FPC, SD FFC, Screws Spec Torque (kgf-cm) MB TO USB FFC. -
Page 21: Main Board
MAIN BOARD Mainboard connector placement MB TO USB FFC EDP CABLE FP FFC SD FFC WLAN CARD BL FPC TP FFC BATTERY SPEAKER Keyboard FFC Back... -
Page 22: Touchpad Module
TOUCHPAD & KEYBOARD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the MB TO USB FFC, SD FFC, FP FFC. Screws Spec Torque (kgf-cm) Step 2 : Release the TP CONDUCTIVE TAPE, TP TO MB FFC and ZIF MYLAR. 2.0 ±... -
Page 23: Lcd Bezel
LCD BEZEL Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the hinge cap *1pcs. Step 2 : Use the non-conductive pry tool to pry and remove the LCD BEZEL. The GLASS SKU need not disassemble the bezel. - Page 24 LCD MODULE (GLASS SKU) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. For GLASS SKU, The below parts have been as the LCD MODULE. The HINGE CAP is included in LCD MODULE. Please book the LCD MODULE if one of parts is damaged except HINGE CAP.
- Page 25 LCD PANEL & CAMERA FOR IPS & OLED SKU Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screw *6pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove the hinge *2pcs. 2.0 ±...
- Page 26 LCD PANEL ASSEMBLY NOTICE Assembly Notice Please be sure to pull out adapter and disconnect the battery. Please follow the green mark to tidy EDP cable. When reuse the LCD PANEL: for the SKU that bottom side of LCD BEZEL has the adhesive Please use the fingertip to clean the residual glue on PANEL or BEZEL.
