- Page 1 Frost Free Technical Manual 410L | 401L | 610L | 601L...
-
Page 2: Table Of Contents
R290 specification ......................... 15 8.2. Personal protective equipment.................... 16 8.3. First aid when using R290, immediate measures ............16 8.4. Eye injuries ..........................16 8.5. Injuries from swallowing liquid refrigerant ................. 16 Novum Warranty Terms and Conditions ................17 Rev. 1.0 – 15/08/2024... -
Page 3: Technical Data
1. Technical data 1.1. Specifications Model 401L/410L 601L/610L Technical Data Gross content litre Net content according to EN 23953 litre Total display area (TDA) according to Eco-design Directive m² 0.55 Classification according to EN 23953 Energy class according to Eco-design Directive Ambient temperature range °C... -
Page 4: 401L/601L Dimensions
1.2. 401L/601L dimensions 1.3. 410L/610L dimensions Rev. 1.0 – 15/08/2024... -
Page 5: Transport & Handling
3.2. Product loading • Novum cabinets are conservators in nature and can be used to store and display previously frozen food. • Do not load the cabinet with non-frozen foods or try to freeze products in the cabinet. -
Page 6: Care And Maintenance
4. Care and maintenance • All below recommendations are standard requirements and may need to be done more frequently depending of store conditions. • The below are manufacturer recommendations and do not override local regulations. 4.1. Monthly checks • Inspect the area behind the cabinet and remove any debris. •... -
Page 7: Cassette/Condenser Cleaning Procedure
5. Refit the side grille. 6. Reconnect power supply. * Tools for cleaning the condenser are available at Novum. Contact spareparts@novum.ie Rev. 1.0 – 15/08/2024... -
Page 8: Cassette Removal Procedure
4.5. Cassette removal procedure 2. Remove the front grille 3. Disconnect from controller Disconnect cabinet from 2 screws. the 2 green connectors. mains supply ensure safety of operations. 4. Set aside the front grille. 5. Remove transportation 6. Disconnect power supply bolt. -
Page 9: Cassette Installation Procedure
4.6. Cassette installation procedure 1. Slide in the cassette. This is 2. Lock the 2 latches and 3. Reconnect power supply very important to make sure make sure the cassette is and temperature sensor the gasket is properly sealing flush and latches are fully and tidy excess cable. -
Page 10: Troubleshooting
5. Troubleshooting Symptom Status Cause Action 1. Check product temp, if above -12°C, move product. 2. Check plug connected socket. 3. Check plug is connected to Critical No power back of cabinet. 4. Check breaker is not tripped No display on distribution panel. -
Page 11: Diagrams
6. Diagrams 6.1. Refrigeration circuit Rev. 1.0 – 15/08/2024... -
Page 12: Cassette Wiring Diagram
6.2. Cassette wiring diagram 6.3. LED wiring diagram Rev. 1.0 – 15/08/2024... -
Page 13: Spare Parts
7. Spare Parts 7.1. 401L/601L cabinet assembly 401L part 601L part Item number Description number number False floor 015.6FF.001 Buffer (white) 006.410.146 006.610.347 Kick strip 006.4FF.083 006.6FF.083 Grille (white) 006.6FA.024/124 Frost Free cassette 230V 003.6FF.101 Side grille (white) 006.6FF.111 Short dividers 015.6FA.005 LED driver 018.601.042... -
Page 14: 410L/610L Cabinet Assembly
7.2. 410L/610L cabinet assembly 410L part 610L part Item number Description number number Long divider 015.6FA.006 Buffer (white) 006.410.146 006.610.347 Kick strip 006.4FF.083 006.6FF.083 Grille (white) 006.6FA.024/124 Frost Free cassette 230V 003.6FF.101 Side grille (white) 006.6FF.111 LED driver 018.601.042 Short divider 015.6FA.005... -
Page 15: Frost Free Cassette Assembly
7.3. Frost Free cassette assembly Item number Description Part number Condenser fan 003.111.424 Condenser 003.6FA.022 Evaporator 003.6FA.026 Evaporator fan 003.6FF.301 Filter dryer 003.6FA.020 Solenoid coil and valve 003.6FA.019 Compressor Embraco EMC3134U 230V 003.610.841 Controller probe 018.8AD.002 Cassette gasket 003.CASS.007 Rev. 1.0 – 15/08/2024... -
Page 16: Safety Instructions R290 Refrigerant
8. Safety instructions R290 refrigerant 8.1. R290 specification Composition: Propane CH3CH2CH3 (R290) Molecular mass: 44.1 kg/kmol Colour: colorless Odour: faint Decomposition temperature: unknown Vapour density: approx. 1.9 kg/m at 25°C heavier than air collects at floor level Handling Ensure good room ventilation at floor level as well. Use only grounded apparatus. Take measures against electrostatic charge. -
Page 17: Personal Protective Equipment
8.2. Personal protective equipment Safety shoes, antistatic and non-combustible clothes, protective gloves and eye protection are to be provided for every person concerned with maintenance, repair and recovery and to be used by them. A self-contained breathing apparatus should always be used under unclear circumstances. -
Page 18: Novum Warranty Terms And Conditions
/ or by third parties to carry out maintenance as provided in the operating instructions. Use of unfit tools and equipment (as deemed by Novum) by the customer and / or by non- approved third parties. Replacement of any consumable item or accessory. These included but not limited to: plugs, cables, batteries, light bulbs, starters, covers, filters, dividers, baskets, shelves. - Page 19 Contact Novum (Overseas) Ltd The Novum Building Clonshaugh Technology & Business Park Dublin 17 Ireland +353 1 803 6400 www.novum.ie Spare Parts: spareparts@novum.ie Warranty and technical support: support@novum.ie Rev. 1.0 – 15/08/2024...
