resideo PROSIXSMOKS-EU Installation And Setup Manual

The PROSIXSMOKS-EU is a combination indoor wireless smoke detector with a siren (intrusion sounder) and is intended for use
with Control Panels that support SiX™ series devices. This detector will trigger its sounder and LED when fire is detected and will
sound when other detectors in the same installation detect a threat.
Note: Installation shall be performed in accordance with local regulations.
ENROLLING
The detector must be enrolled in the Control Panel before it can be used. Enrollment is conducted through the AlarmNet 360™
cloud-based management platform. The detector enrolls as a sensor but does not require a "Device" or "Response" type.
To enroll the detector, perform the following:
Note: For detailed programming instructions refer to the Installation Instructions for the Control Panel with which this detector is
used.
1. From AlarmNet 360:
• Select "SENSORS"
• Select "ADD SENSOR"
• Select "LEARN" and wait for the Control Panel to be in learning mode.
2. Carefully remove (and discard responsibly) the battery tab to activate the detector and begin the enrollment process for the
smoke zone. (If already powered, press the Test button to enroll).
3. Attach to the detector to the rear mounting plate.
4. The Green LED flashes rapidly during enrollment (up to about 20 seconds). The detector sends data and the Control Panel
registers the detector.
Note: Enrollment time varies depending on the signal strength between the detector and the panel.
5. Enrollment is confirmed when the green LED is on for 3 seconds and the detector chirps.
6. Select Save and enable/disable the smoke services as desired.
If the detector is not successfully registered during the enrollment period, the LED will go out and the detector will be turned off.
Activate the tamper or press the test button to restart the enrollment process.
MOUNTING CONSIDERATIONS
During installation, please ensure that all country-specific regulations and guidelines
are followed (such as British BS5839-6 or German DIN14676). If in doubt, verify all
mounting considerations with your local Fire Service.
Note: Before mounting the detector permanently, conduct a sensor test (see the
Control Panel instructions) to verify adequate signal strength and adjust the detector
location and orientation as necessary with the Red LED towards the escape route.
The detector can be mounted on a ceiling or on a wall.
•
Hot smoke rises and spreads out, so a central ceiling position is the
recommended location. The air is "dead" and does not move in corners,
therefore the detector must be mounted away from any "Dead Air Space"
corners [A].
•
Mount the detector at least 50 cm from walls and corners [B].
•
Mount the detector 30-60 cm from the apex of the ceiling [C].
•
If ceiling mounting is impractical, smoke detectors may be mounted on a wall,
provided the top of the detector is between 15 and 30 cm below ceiling [D].
IMPORTANT! Do not attach the detector to removable ceiling panels. Attach the
detector across panel support.
Installation and Setup Guide
PROSIXSMOKS-EU
Wireless Smoke Detector/Siren
