ENGINEERING DATA BOOK
High Static Pressure Duct VRF IDU
MIH200T1N18 (KPDUF-200 DN5.0)
MIH252T1N18 (KPDUF-252 DN5.0)
MIH280T1N18 (KPDUF-280 DN5.0)
MIH400T1N18 (KPDUF-400 DN5.0)
MIH450T1N18 (KPDUF-450 DN5.0)
MIH560T1N18 (KPDUF-560 DN5.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KPDUF-200 DN5.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigicoll KPDUF-200 DN5.0

Summary of Contents for Frigicoll KPDUF-200 DN5.0

  • Page 1 ENGINEERING DATA BOOK High Static Pressure Duct VRF IDU MIH200T1N18 (KPDUF-200 DN5.0) MIH252T1N18 (KPDUF-252 DN5.0) MIH280T1N18 (KPDUF-280 DN5.0) MIH400T1N18 (KPDUF-400 DN5.0) MIH450T1N18 (KPDUF-450 DN5.0) MIH560T1N18 (KPDUF-560 DN5.0)

  • Page 2: Table Of Contents

    VRF Indoor Units High Static Pressure Duct 1 Specifications .................... 4 2 Dimensions ....................6 3 Unit Placement ..................6 4 Piping Diagrams ..................10 5 Wiring Diagrams ..................11 6 Capacity Tables ..................13 7 Electrical Characteristics ................14 8 Sound Levels ...................

  • Page 3: Specifications

    VRF Indoor Units 1 Specifications MIH200T1N18 (KPDUF-200 DN5.0) / MIH252T1N18 (KPDUF-252 DN5.0) / MIH280T1N18 (KPDUF-280 DN5.0) Table 1.3: specifications MIH280T1N18 ( MIH200T1N18 MIH252T1N18 Model name KPDUF-280 DN5.0) (KPDUF-200 DN5.0) DN5.0) (KPDUF-252 DN5.0) Power supply 1-phase, 220-240V, 50Hz 20.0 25.2 28.0...
  • Page 4 VRF Indoor Units MIH400T1N18 (KPDUF-400 DN5.0) / MIH450T1N18 (KPDUF-450 DN5.0) / MIH560T1N18 (KPDUF-560 DN5.0) Table 1.4: specifications MIH400T1N1 MIH450T1N18 MIH560T1N18 Model name (KPDUF-400 DN5.0) (KPDUF-450 DN5.0) (KPDUF-560 DN5.0) Power supply 1-phase, 220-240V, 50Hz 40.0 45.0 56.0 Capacity 136.5 153.6 191.1 Cooling kBut/h 1850...

  • Page 5: Dimensions

    VRF Indoor Units 2 Dimensions 2.1 Unit Dimensions MIH200T1N18 (KPDUF-200 DN5.0) /MIH252T1N18 (KPDUF-252 DN5.0) /MIH280T1N18 (KPDUF-280 DN5.0) Figure 2.2: dimensions (unit: mm) Capacity (kW) 5/8-18 UNF 20. 0Ĥ kW Ĥ 22. 4 3/4-16 UNF 22. 4(kW Ĥ 33. 5...
  • Page 6 VRF Indoor Units MIH400T1N18 (KPDUF-400 DN5.0) / MIH450T1N18 (KPDUF-450 DN5.0) / MIH560T1N18 (KPDUF-560 DN5.0) Figure 2.3: dimensions (unit: mm) Capacity (kW) 3/4-16 UNF 33. 5$kW Ĥ 40. 0 7/8-14 UNF 40. 0$kW Ĥ 56. 0...

  • Page 7: Unit Placement

    VRF Indoor Units 3 Unit Placement 3.1 Placement Considerations Unit placement should take account of the following considerations: § Units should not be installed in the following locations: Ÿ Where exposure to direct radiation from a high-temperature heat source or to interference from a source of electromagnetic radiation may occur.
  • Page 8 VRF Indoor Units 3.2 Space Requirements MIH200T1N18 (KPDUF-200 DN5.0) / MIH252T1N18 (KPDUF-252 DN5.0) / MIH280T1N18 (KPDUF-280 DN5.0) MIH400T1N18 (KPDUF-400 DN5.0) / MIH450T1N18 (KPDUF-450 DN5.0) / MIH560T1N18 (KPDUF-560 DN5.0) Figure 3.2: High Static Pressure Duct space requirements (unit: mm) Bottom view...

  • Page 9: Piping Diagrams

    VRF Indoor Units Notes for installers and service engineers 1. The distance between the indoor unit and the roof (B) shall be greater than 50mm to install the air duct. 2. The motor and fan can be maintained from the indoor unit top or the air outlet. If maintenance is performed from the indoor unit top, the distance between the indoor unit and the roof must be larger than 600mm.

  • Page 10: Wiring Diagrams

    VRF Indoor Units 5 Wiring Diagrams MIH200T1N18 (KPDUF-200 DN5.0) / MIH252T1N18 (KPDUF-252 DN5.0) / MIH280T1N18 (KPDUF-280 DN5.0) MIH400T1N18 (KPDUF-400 DN5.0) / MIH450T1N18 (KPDUF-450 DN5.0) / MIH560T1N18 (KPDUF-560 DN5.0) Figure 5.2: Duct wiring diagram...
  • Page 11 VRF Indoor Units Legend Code Name Code Name XS XP connectors Inlet Air Temp. Sensor Steam pipe temperature sensor* Gas Pipe Temp. Sensor CS-SW Water level switch Fresh air inlet temperature sensor* Electronic expansion valve ALARM Alarm output Anion Sterilization module DC Fan motor Liquid Pipe Temp.

  • Page 12: Capacity Tables

    6 Capacity Tables 6.1 Cooling Capacity Table Table 6.1: High Static Pressure Duct cooling capacity Indoor air temperature (°C WB/DB) 14/20 16/23 18/26 19/27 20/28 22/30 24/32 Model MIH200T1N18 (KPDUF-200 DN5.0) 17.7 16.1 18.9 16.5 19.8 16.8 20.0 16.3 20.2 15.8 20.8 15.1...

  • Page 13: Electrical Characteristics

    Table 8.1: High Static Pressure Duct electrical characteristics Power supply Indoor Fan Motor Model Volts Rated power Min. volts Max. volts output (W) MIH200T1N18 220-240 8.19 6.55 (KPDUF-200 DN5.0) MIH252T1N18 220-240 8.19 6.55 (KPDUF-252 DN5.0) MIH280T1N18 220-240 8.19 6.55 (KPDUF-280 DN5.0) MIH400T1N18 220-240 12.98...

  • Page 14: Sound Levels

    Sound pressure levels are measured 1.4m below the unit in an anechoic chamber. During in-situ operation, sound pressure levels may be higher as a result of ambient noise. 8.2 Octave Band Levels Figure 8.8: MIH200T1N18 (KPDUF-200 DN5.0) octave band levels Figure 8.9: MIH224T1N18 octave band levels NR-70 NR-70...
  • Page 15 VRF Indoor Units Figure 8.12: MIH335T1N18 octave band levels Figure 8.13: MIH400T1N18 (KPDUF-400 DN5.0) octave band levels NR-70 NR-60 NR-50 NR-70 NR-40 NR-60 NR-30 NR-50 NR-20 NR-40 NR-10 NR-30 NR-0 NR-20 NR-10 NR-0 31,5 63 125 250 500 1000 2000 4000 8000 31,5 63 125 250 500 1000 2000 4000 8000 Octave band center frequency (Hz)

  • Page 16: Fan Performance

    √ Constant Airflow Notes: The above is only an example. If you choose other controllers, please refer to their instructions for setting. 9.2 Constant Airflow mode 9.2.1 Fan performance diagram Figure 9.7: MIH200T1N18 (KPDUF-200 DN5.0) Figure 9.9: MIH252T1N18 (KPDUF-252 DN5.0)
  • Page 17 VRF Indoor Units Figure 9.10: MIH280T1N18 (KPDUF-280 DN5.0) Figure 9.12: MIH400T1N18 (KPDUF-400 DN5.0) Figure 9.13: MIH450T1N18 (KPDUF-450 DN5.0) Figure 9.14: MIH560T1N18 (KPDUF-560 DN5.0) 9.2.2 How to Read the Diagram (Constant Airflow mode) The vertical axis is the External Static Pressure (Pa) while the horizontal axis represents the Air Flow (m /h).
  • Page 19 9.3 Constant Speed mode 9.3.1 Set external static pressure parameters ①In the main interface, press " " +" " for 3 seconds at the same time, and the main interface will display "CC". Press the "▲" and "▼" to select the indoor unit ("n00-n63" is displayed, and the last two digits are the indoor unit addresses).
  • Page 21 9.3.2 Fan performance diagram Figure 9.21: MIH200T1N18 (KPDUF-200 DN5.0) Figure 9.23: MIH252T1N18 (KPDUF-252 DN5.0) Figure 9.24: MIH280T1N18 (KPDUF-280 DN5.0) Figure 9.26: MIH400T1N18 (KPDUF-400 DN5.0) Figure 9.27: MIH450T1N18 (KPDUF-450 DN5.0) Figure 9.28: MIH560T1N18 (KPDUF-560 DN5.0)
  • Page 22 VRF Indoor Units 9.3.3 How to Read the Diagram (Constant Speed mode) The vertical axis is the External Static Pressure (Pa) while the horizontal axis represents the Air Flow (m /h). The characteristic curve for the “SH”, “M” and “SL” fan speed control. The Air Flow decreases with the increase of the external static pressure.
  • Page 23 T-V8T1HEU Ver. 2023-7...
